QuickSpecs
Overview
Front View:
Front View:
Front View:
Front View:
1.
Dual Hot Plug Redundant Power Supplies (one standard
with 1P Models, requires optional RPS for redundancy)
2.
Up to Six Available I/O Slots: 3 Standard PCI-Express x4
and 1 Standard 64-bit/133MHz PCI-X. Optional
Mezzanine adds Two Hot Plug 64-bit/133MHz PCI-X or
two X4 PCI Express, or one X8 PCI Express
3.
4U (7" Height) Rack Form Factor
4.
Server Lifting Handles
5.
Ships with HP Smart Array P400/256MB Controller.
Optional 512MB Battery Backed Write Cache (BBWC ships
standard with 2P models)
6.
Universal Tool-less "Snap In" Sliding Rail Solution
7.
Systems Insight Display
8.
Support for up to 8 Small Form-Factor (SFF) SAS or Serial
ATA (SATA) drives
9.
Support for up to Two Slimline Drives (Ejectable, DVD/CD-
RW Drive standard, Floppy Drive optional with all models)
10.
One front video port.
11.
Two front accessible USB 2.0 ports. Two rear accessible
USB 2.0 ports (all bootable).
12.
Front Panel LED Display (internal and external health, Two
Network Port Status, Unit ID light) and Power Button
13.
Front accessible Processor drawer (allows access to
Processors and Processor Power Modules)
14.
Support for up to four Dual-Core 64-bit Intel® Xeon®
Processors
15.
Quick release levers for fast server access
16.
Front accessible Hot Plug RAID Memory
DA - 12473
North America — Version 37 — June 11, 2008
HP ProLiant DL580 Generation 4 (G4)
HP ProLiant DL580 Generation 4 (G4)
HP ProLiant DL580 Generation 4 (G4)
HP ProLiant DL580 Generation 4 (G4)
Rear View:
Rear View:
Rear View:
Rear View:
1.
PCI-Express x4 slot
2.
PCI-Express x4 slot
3.
PCI-Express x4 slot
4.
PCI-Express x4 slot
5.
PCI-X slot
6.
Optional Mezzanine adds 2 PCI-X/133 or 2 PCI-E x4 or 1
PCI-E x8
7.
Optional Mezzanine adds 2 PCI-X/133 or 2 PCI-E x4 or 1
PCI-E x8
8.
Optional redundant power supply
9.
Power supply
10.
Unit Identification LED
11.
Integrated Lights-Out 2 (iLO2) NIC
12.
Mouse port
13.
Keyboard port
14.
Video port
15.
2 USB ports
16.
Serial port
17.
Multifunction Gigabit NIC port
18.
Multifunction Gigabit NIC port
Page 1

Advertisement

loading

Related Manuals for HP DL580

Summary of Contents for HP DL580

  • Page 1 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Overview Front View: Front View: Front View: Front View: Rear View: Rear View: Rear View:...

  • Page 2: What's New

    At A Glance The ProLiant DL580 G4 server is an enterprise class, 4 socket server designed for maximum scalability and high availability. Its innovative chassis offers unsurpassed flexibility and serviceability in a versatile, rack-optimized form factor. Based upon the latest industry standard processing, memory, I/O and networking technologies, the ProLiant DL580 G4 provides the highest levels of performance demanded by today's compute intensive applications.
  • Page 3 Warranty: Warranty: Protected by HP Services and a worldwide network of resellers and service providers. Three-year Next Business Day, on- site limited global warranty. Certain restrictions and exclusions apply. Pre-Failure Notification on processors, memory, and SAS hard drives. SATA hard drives have a one-year warranty.

  • Page 4: Standard Features

    NOTE: Dual-Core 7030 Model only. Upgradeability Upgradeability Upgradeability Upgradeability HP ProLiant DL580 G4 servers with Intel Xeon 7041 and 7030 processors can be upgraded with Intel® Xeon® 71x0 processors. All ProLiant DL580 G4 servers can support up to 4 processors. Chipset Chipset Chipset Chipset Industry Standard Intel®...
  • Page 5 NOTE: NOTE: NOTE: 64 GB achieved with use of four memory cartridges and sixteen 4 GB PC2-3200 Memory Modules. The HP ProLiant DL580 G4 will accept both single rank and dual rank DIMMs in all sockets. Network Controller Network Controller...
  • Page 6 PCI Express expansion slot. The HP ProLiant DL580 G4 Server can support up to two x4-x8 PCI Express bus expander boards. The bus expander can only be installed in expansion slots 5 and 7 to convert the adjacent lower-numbered expansion slot to a PCI Express x8 expansion slot.
  • Page 7 Increases overall controller performance NOTE: NOTE: NOTE: NOTE: Safely transport your write cache data to another HP ProLiant DL580 G4 in the data center by removing the BBWC Enabler and Smart Array P400 Controller Memory Module simultaneously (connected by short cable). Storage...
  • Page 8 HP Insight Control Environment installs and licenses the following components by default using a wizard- based integrated installer: HP Systems Insight Manager...
  • Page 9 HP Insight Control management suites and most HP ProLiant Essentials include a one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates.
  • Page 10 LAN media and adapters, and application processes. The following is a quick summary of HP Serviceguard for Linux features and support. For the most recent list of Linux distributions & kernels, servers and storage supported with Serviceguard for Linux, see the Serviceguard for Linux Certification Matrix, available at: http://www.hp.com/go/sglx/info.
  • Page 11 NOTE: HP Serviceguard for Linux products for HP ProLiant and select 3rd party x86 class servers include one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. For more information about this service, please visit: http://www.hp.com/services/swsupport.
  • Page 12 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Standard Features Advanced ECC, the server is protected against correctable memory errors. The server will provide notification if the level of correctable errors exceeds a predefined threshold rate.
  • Page 13 Smart Array P400 Controller with optional Battery Backed Write Cache (BBWC) Enabler provides transportable data protection and increases overall controller performance. Up to 512MB Battery Backed Write Cache protection optional on HP ProLiant DL580 G4 (512MB BBWC ships standard with 2P models).
  • Page 14 NOTE: For a more complete and up-to-date listing of supported OSs and versions, please visit our OS Support Matrix at: http://www.hp.com/go/supportos. NOTE: NOTE: NOTE: NOTE: For an up-to-date listing of the latest drivers available for the HP ProLiant DL580, please see: http://www.hp.com/support. NOTE: NOTE: NOTE: NOTE: For more Linux OS support &...
  • Page 15 URL: www.hp.com/servers/dl580-g4. Rack Mounting Rack Mounting Rack Mounting Rack Mounting HP ProLiant DL580 G4 rack models provide tool-free support for racks with square or round mounting Requirements Requirements Requirements Requirements holes (including Compaq/HP 7000, 9000, 10000, HP/E series and H9 series) with an adjustment range from 24"...
  • Page 16 Whether an SMB, or large global corporation, HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.
  • Page 17 Space-constrained corporate data centers and service providers With up to 1.168TB of internal storage, 16 DIMM sockets and PCI-Express or hot-plug PCI-X mezzanine options; the HP ProLiant DL580 G4 packs the storage, memory, and I/O you need in a versatile, 4U chassis...
  • Page 18 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Models NOTE: NOTE: NOTE: NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory Integrated Models"...
  • Page 19 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Models Diskette Drive Diskette Drive Diskette Drive Diskette Drive None ship standard (optional Ejectable Slimline Floppy Drive)

  • Page 20: Configuration Information - Factory Integrated Models

    NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.
  • Page 21 Step 3: Choose Additional Factory Integratable Options High Performance Model High Performance Model High Performance Model High Performance Model The HP ProLiant DL580 G4 Performance Packs include the latest performance Options Options Options Options technologies and enterprise class availability features pre-installed for convenience and value.
  • Page 22 NOTE: NOTE: NOTE: The HP ProLiant DL580 G4 utilizes up to four Memory Expansion Boards that support up to four DIMMs each. These memory boards are Front accessible providing unsurpassed levels of memory protection as well as scalability for the most memory- intensive applications.
  • Page 23 The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service. One certificate is shipped for each license.
  • Page 24 NOTE: Customer will receive a printed license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.
  • Page 25 Dual-Core 64-bit Intel® Xeon® 7140M Processor (3.40 GHz, 150Watts, 800MHz 430816-B21 FSB) NOTE: NOTE: NOTE: NOTE: This processor option kit supports the HP ProLiant DL580 G4 and the HP ProLiant ML570 G4. Dual-Core 64-bit Intel® Xeon® 7130M Processor (3.20 GHz, 150 Watts, 800MHz 430817-B21 FSB) NOTE:...
  • Page 26 NOTE: NOTE: NOTE: The HP ProLiant DL580 Generation 4 Server can support up to two x4-x8 PCI Express bus expander boards. The bus expander can only be installed in expansion slots 5 and 7 to convert the adjacent lower-numbered expansion slot to a PCI Express x8 expansion slot.
  • Page 27 HP Smart Array P600/256 BBWC Controller 337972-B21 NOTE: NOTE: NOTE: NOTE: The Smart Array P600 Controller supports internal and external Serial Attached SCSI and Serial ATA drives. It is supported in all HP ProLiant DL580 G4 Models. 512MB DDR BBWC Upgrade 372538-B21 NOTE: NOTE: NOTE: NOTE: For Smart Array P600 Controller only.
  • Page 28 For recommended tape drive offerings for this ProLiant server see the following: USB Tape Drives USB Tape Drives USB Tape Drives USB Tape Drives HP StorageWorks 1U USB Rack-Mount Kit with one DAT 160 USB Tape Drive AG703A SAS Tape Drives SAS Tape Drives SAS Tape Drives...
  • Page 29 For an up-to-date listing of the latest O/S and software support details for HP Ultrium tape drives, please visit: http://www.hp.com/go/connect. Rack-Mount Tape Drive Enclosures Rack-Mount Tape Drive Enclosures...
  • Page 30 HP StorageWorks D2D130 Backup System with Data Protector Express Software Kit EH951A NOTE: NOTE: NOTE: NOTE: 3TB of Disk Storage. HP StorageWorks D2D130 Backup System with LTO-3 Ultrium 920 SAS Tape Drive EH952A NOTE: NOTE: NOTE: NOTE: 3TB of Disk Storage.
  • Page 31 HP Serviceguard for Linux Options Options Options Options HP Serviceguard Linux x86 Server License & Media including One Year 24x7 Software 463831-B21 Support & Updates HP Serviceguard Linux Oracle Single Instance Database Toolkit x86 Cluster License & 463833-B21 Media including One Year 24x7 Software Support & Updates HP Serviceguard Linux Extension for SAP (SGeSAP/LX) x86 Server License &...
  • Page 32 Linux. For detailed compatibility information please see: http://h18006.www1.hp.com/storage/saninfrastructure/hba.html HP StorageWorks FC2142SR 4Gb PCI-e HBA A8002A HP StorageWorks FC2242SR Dual Channel 4 Gb PCI-e HBA A8003A HP StorageWorks FC1142SR 4Gb PCI-e HBA AE311A HP StorageWorks FC1242SR Dual Channel 4 Gb PCI-e HBA AE312A HP StorageWorks FC2143 4Gb PCI-X 2.0 -to-Fibre Channel HBA...
  • Page 33 HP Rack 5000 Series HP Rack 5000 Series HP Rack 5000 Series NOTE: NOTE: NOTE: NOTE: Please see the HP Rack 5642 QuickSpecs for additional part numbers and (Graphite Metallic) Technical Specifications such as height, width, depth, weight, and color: http://h18000.www1.hp.com/products/quickspecs/12074_na/12074_na.html NOTE: NOTE:...
  • Page 34 NOTE: For additional information regarding Rack Cabinets, please see the following URL: http://www.hp.com/go/rackandpower. HP Rack 10000 Series HP Rack 10000 Series HP Rack 10000 Series HP Rack 10000 Series HP Rack S10614 (14U) Rack Cabinet – Shock Pallet 292302-B22 (Graphite Metallic) NOTE: NOTE: NOTE: NOTE: xxxxxx-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels).
  • Page 35 373035-B21 NOTE: NOTE: NOTE: NOTE: Cat5e cables are required to connect Interface Adapters to Console Switches. Cat5e cables can be found at the following URL: http://www.hp.com/go/kvm. HP 1x4 Console Switch AF611A PS2 Server Console Cable, 6 ft, 2 pack AF612A...
  • Page 36 Support Plus Support Plus Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech U4619E support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic Support Plus 24 Support Plus 24 Support Plus 24...
  • Page 37 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Memory HP ProLiant DL580 G4 2P Models HP ProLiant DL580 G4 2P Models HP ProLiant DL580 G4 2P Models...
  • Page 38 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Memory Maximum Memory Summary Maximum Memory Summary Maximum Memory Summary Maximum Memory Summary Standard Memory Board (Slots)
  • Page 39 NOTE: NOTE: NOTE: The HP ProLiant DL580 G4 utilizes up to four Memory Expansion Boards that support up to four DIMMs each. These memory boards are Front accessible providing unsurpassed levels of memory protection as well as scalability for the most memory-intensive applications. See Memory Configuration Diagram.

  • Page 40: Drive Support

    NOTE: NOTE: The HP ProLiant DL580 G4 can support a maximum of two Slimline drives (ejectable). Additional configuration settings may be required if running 2 Diskette Drives. When running 1 diskette drive, the top bay is the default location, but can be changed with additional configuration settings.
  • Page 41 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Storage External Storage External Storage External Storage External Storage Quantity Quantity Quantity Quantity Position Position...
  • Page 42 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Storage DAT 72 DAT 160 DLT VS160 SDLT 600 1U Rack-Mount Kit 3U Rack-Mount Kit...

  • Page 43: Power Specifications

    To drill down to calculators: Click on: "ProLiant Servers" Click on the Server of interest. Example: DL580 G4 Click on: "Power Calculator" link. (You may need to scroll down to see it) There are certain Dual-Core, lowline, max configurations that are not supported. All highline configurations are supported.

  • Page 44: Technical Specifications

    QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Technical Specifications System Unit Rack System Unit Rack System Unit Rack System Unit Rack Chassis Footprint...
  • Page 45 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Technical Specifications 24X Max (or higher) IDE 24X Max (or higher) IDE 24X Max (or higher) IDE...
  • Page 46 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Technical Specifications CD-ROM Mode-2 data disc CD Audio disc CD-Extra CD-RW CD-R CD Text PhotoCD...
  • Page 47 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Technical Specifications Dimensions Dimensions Dimensions Dimensions (HxWxD, maximum) 0.5 x 5.04 x 5.1 in (12.7 x 128 x 129.4 mm)
  • Page 48 QuickSpecs HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) HP ProLiant DL580 Generation 4 (G4) Technical Specifications Smart Array P400 Smart Array P400 Smart Array P400 Smart Array P400 Disk Drive and Enclosure...
  • Page 49 Intel, the Intel logo, Xeon and Xeon Inside are trademarks of Intel Corporation in the U.S. and other countries. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

This manual is also suitable for:

Proliant dl580 generation 4Proliant dl580 g4
