Tune - Johannus Rembrandt 200 User Manual

The volume can be adjusted as follows:
1. Push the VOL. Piston. As long as the light of the VOL. piston remains lighting up you can
change the volume setting.
2. Adjust the desired volume by pushing the - or + piston as may times as necessary to reach
the desired volume.
3. After some seconds the lights of the VOL. As well as the - and + pistons will switch off
automatically.
4. This volume setting has not been programmed and you will loose it as soon as you switch
off the organ.
A volume setting can be programmed as follows:
1. Make the memory accessible by turning the MEMORY LOCK a quarter turn to the right. The
SET piston will light up to indicate the memory can be accessed.
2. Push the VOL. Piston. As long as the light of the VOL. piston remains lighting up you can
change the volume setting.
3. Adjust the desired volume by pushing the - or + piston as many times as necessary to reach
the desired volume.
4. Push the SET piston when the right volume level has been reached. As long as you push the
SET piston a P will show up in the display to indicate that the chosen volume setting is being
programmed.
M e m : P 6
T r a n s :
The programming into the memory can be done only if the piston VOL. lights up. After some
seconds the lights of the VOL. as well as the - and + pistons will switch off automatically.
5. Close the memory by turning the key switch MEMORY LOCK a quarter turn to the left and
eventually remove the key from the switch. The light in the SET piston will go off to indicate
that the memory is not accessible anymore.
The volume setting has been stored in the memory. Every time the organ will be switched on
from now on the in the memory programmed volume setting will be chosen automatically.

TUNE

The standard pitch for musical instruments is A=440Hz.
You can change the pitch with the TUNE piston in combination with the - and + pistons in steps
of 1 Hz. From 426 Hz (a quarter step lower than the std pitch) until 454 Hz (a quarter step higher
than the std pitch). An adjusted pitch can be programmed into the memory. When the organ is
switched on this programmed pitch will be chosen automatically. If desired you can always
change the programmed volume setting again.
The memory of the pitch adjustment is protected so that it cannot be erased when you switch
off the organ or when you unplug the organ from the main power.
JOHANNUS JOHANNUS
User's Manual
V o l : 1 2 T u n e : 4 4 0
0 C r e s c e n d o : O f f
Rembrandt 200, 300, 2000 and 3000 AGO
16
