TRANS. = Transposer

With the TRANS. Thumb piston in combination with the - and the + piston it is possible to
transpose the organ. This means the organ can be tuned some steps higher or lower. The
adjusted setting can be stored in the memory. When the organ is switched on this programmed
TRANS. will be chosen automatically. If desired you can always change the programmed
transposer setting again.
The memory of the transposer adjustment is protected so that it cannot be erased when you
switch off the organ or when you unplug the organ from the main power.
You are able to transpose the organ 3 half steps lower and 3 half steps higher. The adjusted
transposer setting you can read in the display.
M e m :
T r a n s : – 2
The transposer can be adjusted as follows:
1. Push thumb piston TRANS. As long as the light in the thumb piston lights up you can adjust
the pitch.
2. Adjust the desired transposer position by pushing the - or the + piston one or more times.
3. After some seconds the lights of the piston TRANS. as well as the - and the + piston will be
switched off automatically.
The transposer setting has not been stored and will be erased when you switch off the organ.
You may program a transposer setting as follows:
1. Make the memory accessible by turning the MEMORY LOCK a quarter turn to the right. The
SET piston will light up to indicate the memory can be accessed.
2. Push the TRANS. piston. As long as the light of the TRANS. piston remains lighting up you
can change the volume setting.
3. Adjust the desired transposer setting by pushing the - or + piston as many times as
necessary to reach the desired pitch.
4. Push the SET piston when the right pitch level has been reached. As long as you push the
SET piston a P will show up in the display to indicate that the chosen pitch setting is being
programmed.
M e m : P 6
T r a n s : – 2
The programming into the memory can be done only if the piston TRANS. lights up. After
some seconds the lights of the TRANS. as well as the - and + pistons will switch off
automatically.
