Replacing Foglamp Bulbs; Replacing Tail Lamp/Turn/Backup Lamp Bulbs - Ford 2005 Excursion Owner's Manual

Lights

Replacing foglamp bulbs

1. Make sure the headlamp switch is
in the OFF position and then rotate
the foglamp bulb counterclockwise
and remove from foglamp (the rear
side of the foglamp is shown).
2. Disconnect the electrical
connector from the foglamp bulb.
Install the new bulb in reverse order.

Replacing tail lamp/turn/backup lamp bulbs

1. Make sure the headlamp switch is
in the OFF position and remove the
four screws and the lamp assembly
from vehicle.
2. Rotate bulb socket
counterclockwise and remove from
lamp assembly.
3. Carefully pull the bulb straight
out of the socket.
Install the new bulb(s) in reverse order.
