Page 1 Heater only Manual heating and air conditioning Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Locks and Security Keys Locks 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 2: Table Of Contents
Driving Starting Brakes Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Jump starting Wrecker towing Customer Assistance Reporting safety defects (U.S. only) Cleaning 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 6 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 7 Your vehicle is not equipped with a snowplowing package. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Middle East/North Africa vehicle specific information...
Page 8 Brake Fluid - Anti-Lock Brake System Non-Petroleum Based Powertrain Malfunction Speed Control Master Lighting Switch Hazard Warning Flasher Fog Lamps-Front Fuse Compartment Fuel Pump Reset Windshield Wash/Wipe Windshield Rear Window Defrost/Demist Defrost/Demist 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 9 Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System Engine Air Filter Passenger Compartment Jack Air Filter Check fuel cap Low tire warning 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 10: Instrument Cluster
Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Check Engine warning light to come on. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 11 ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 12 Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 13 (the key is not in the ignition) and the driver’s door is opened. Door ajar warning chime: Sounds when any door is opened (or not fully closed). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 14: Gauges
Never remove the coolant reservoir cap while the engine is running or hot. Odometer: Registers the total miles (kilometers) of the vehicle. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 15 The arrow near the fuel pump icon indicates which side of the vehicle the fuel filler door is located. Refer to Filling the tank in the Maintenance and Specifications chapter for more information. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 16: Entertainment Systems
Bass: Press AUDIO to decrease/increase the bass setting. Treble: Press AUDIO to decrease/increase the treble setting. Balance: Press AUDIO to adjust the audio between the left and right speakers. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 17 If the volume is set above a certain level, and the ignition is turned off, the volume will come back to a “nominal” listening level when the ignition is turned back on. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 18: Am/Fm Stereo Single Cd/Mp3 System
4. MENU: Press MENU repeatedly to toggle through the following modes and use to make adjustment in those modes. Autoset: Press MENU set the strongest local radio stations for AM/FM1/FM2 without losing 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 19 To recall a previously set station, press the desired memory preset button briefly. 11. SEEK/TRACK: Press to access the previous/next ( ) strong station. In CD mode, press to advance to the previous/next ( track. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 20 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 21: Am/Fm Stereo Cassette, Cd/Mp3 Sound System
3. MUTE: Press to mute the playing media. Press again to return to the playing media. 4. MENU: Press MENU repeatedly to toggle through the following modes and use to make adjustment in those modes. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 22 Dolby Laboratories Licensing Corporation. 5. TUNE: Press to manually go down/up ( ) the radio frequency and also to select various settings in menu mode. 6. Tape eject: Press to eject the tape. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 23 In MP3 directory mode, press to select the next/previous track in the current directory. 16. Scan: In radio mode, scan through the available stations. In tape mode, you may set SCAN on or 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 24 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 25 Press MENU adjust the hours/minutes. Press CLK to display the time when the ignition is off. 5. MUTE: Press to mute the playing media. Press again to return to the playing media. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 26 9. SHUFF (Shuffle): Press to play the tracks on the current CD/MP3 in random order. In MP3 directory mode, press to play the tracks within the current directory in random order. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 27 LOAD and select the slot number by pressing the memory preset buttons. Press and hold LOAD to autoload up to six discs. 19. CD slot: Insert a CD, label side up. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 28: Tremor Iv Cd/Mp3 Audio System
Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 29 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Press TUNE again to disengage. BASS: Press TUNE to decrease/increase the bass levels. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 30 13. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. To select a preset station, press the desired memory preset button. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 31 AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 32 • Expose discs to direct sunlight or heat sources for extended periods of time. • Insert more than one disc into each slot of the CD changer magazine. • Clean using a circular motion. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 33 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 34: Climate Controls
• Remove any snow, ice or leaves from the air intake area at the base of the windshield. To aid in side window defogging/demisting in cold weather: 1. Select 2. Adjust the temperature control to maintain comfort. 3. Set the fan speed to the highest setting. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 35: Manual Heating And Air Conditioning
• Under normal weather conditions, do not leave the air flow selector in MAX A/C or OFF when the vehicle is parked. This allows the vehicle to “breathe” using the outside air inlet vents. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 36 To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 37: Lights
The Daytime Running Light (DRL) System does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 38 Move the control up or down to adjust the intensity of the panel lighting. Move the control to the full upright position, past detent, to turn on the interior lamps. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 39 (4). If the top edge of the high intensity area is not even with the horizontal line, follow the next step to adjust 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 40: Turn Signal Control
TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 41: Bulb Replacement
Function Number of Trade number bulbs Park/turn(front) 3457AK (amber) Side marker lamps Headlamps 9007 Foglamps (if equipped) 9145 Hi-mount brakelamp 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 42 2. At the back of the headlamp, pry up the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward. 3. Disconnect the electrical connector from the bulb by pulling rearward. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 43 OFF position and then open the hood. 2. At the back of the headlamp, pry up the two retainer pins to release the headlamp assembly from the vehicle and pull headlamp forward. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 44 5. Carefully pull bulb straight out of socket and push in the new bulb. 6. Install the bulb socket in lamp assembly by turning clockwise. Install the new bulb in reverse order. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 45 3. Rotate bulb socket counterclockwise turn and remove from lamp assembly. 4. Carefully pull the bulb straight out of the socket Install the new bulb(s) in reverse order. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 46 2. Twist the socket counterclockwise and remove. 3. Carefully pull the bulb straight out of the socket. Install the new bulb(s) in reverse order. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 47: Driver Controls
Replace wiper blades at least once per year for optimum performance. Poor wiper quality can sometimes be improved by cleaning the wiper blades, refer to Windows and wiper blades in the Cleaning chapter. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 48 Compartment Fuse Panel in the Roadside Emergencies chapter for fuse ratings in your vehicle. To prevent the battery from being discharged, do not use the power point longer than necessary when the engine is not running. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 49: Power Windows
One touch down Allows the driver’s window to open fully without holding the control down. Press completely down on AUTO and release quickly. Press again to stop. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 50: Mirrors
Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release 2. Accelerate to the desired speed. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 51 Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 30 mph (48 km/h). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 52 • Press the speed control OFF control. • Turn OFF the ignition. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 53 CARGO AREA FEATURES Cargo area shade (if equipped) Your vehicle may be equipped with notches in the side trim panels that are used for a cargo area shade. See your dealer for more information. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 54 The bed extender should always be kept in the stowed position with the tailgate closed when not in use. When driving the vehicle off road, the bed extender should be in the stowed position and the tailgate closed. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 55 Note: Remove and store the bed extender when not in use. To install the bed extender, follow the removal procedure in reverse order. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 56: Locks And Security
• weather conditions, • nearby radio towers, • structures around the vehicle, or • other vehicles parked next to your vehicle. Your vehicle is equipped with a remote entry system which allows you to: 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 57 Note: The panic alarm will only operate when the ignition is in the OFF or ACC position. Replacing the battery The remote entry transmitter uses one coin type three-volt lithium battery CR2032 or equivalent. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 58 How to reprogram your remote entry transmitters You must have all remote entry transmitters (maximum of four) available before beginning this procedure. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 59 • they have been turned on with the dimmer control, or • any door is open. The battery saver will shut off the interior lamps after several minutes if they are left on accidentally. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 60: Seating And Safety Restraints
Lift the release bar to move seat forward or backward. Ensure that the seat is locked into place. Pull lever located at the side of the seat cushion up to adjust seatback. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 61 Passenger side rear access Pull up on the recliner handle. The seat will lean forward. Lift the release bar to move the seat forward to access the rear area of the cab. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 62: Safety Restraints
SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 63 2) Never swing the safety belt around your neck over the inside shoulder. 3) Never use a single belt for more than one person. On four-door SuperCab vehicles, do not open the rear door when the rear safety belt is still buckled. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 64 In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 65 “automatic locking retractor” feature for child seats is still functioning properly. In addition, all safety belts should be checked for proper function. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 66 Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front outboard passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 67 Adjusting the front center seat and rear center facing jump seat lap belts (if equipped) The lap belt does not adjust automatically. The lap belt should fit snugly and as low as possible around the hips, not across the waist. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 68 Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 69 The driver’s safety belt is buckled The BeltMinder feature will not before the ignition switch is turned activate. to the ON position... 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 70 “I’d rather be Not a good idea. People who are ejected are 40 thrown clear” times more likely to DIE. Safety belts help prevent ejection, WE CAN’T “PICK OUR CRASH”. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 71 3. At a moderate speed, buckle then unbuckle the safety belt three times, ending with the safety belt unbuckled. This can be done before or during BeltMinder warning activation. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 72 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 73: Air Bags
All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag supplemental restraint system (SRS) is provided. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 74 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln/Mercury dealer. The front passenger airbag is not designed to offer protection to an occupant in the center front seating position.
Page 75 See Passenger air bag on/off switch in this chapter. Rear facing child seats should NEVER be placed in the front seats unless the passenger airbag switch is turned off. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 76 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 77 A difficulty with the system is indicated by one or more of the following: • The readiness lights will either flash or stay lit. • The readiness lights will not illuminate immediately after ignition is turned on. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 78 2. When the ignition is turned to the ON position the OFF light illuminates briefly, momentarily PASSENGER AIRBAG shuts off and then turns back on. This indicates that the passenger air bag is deactivated. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 79 If the light fails to illuminate when the passenger air bag switch is in the OFF position and the ignition switch is in the On position, have the passenger air bag switch serviced at your Ford or Lincoln/Mercury dealer immediately.
Page 80 2. Child age 1 to 12. A child age 1 to 12 must ride in the front seat because: • the vehicle has no rear seat; 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 81 • the infant has a medical condition which, according to the infant’s physician, makes it necessary for the infant to ride in the front seat so that the driver can monitor the infant’s condition. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 82: Child Restraints
You are required by law to use safety restraints for children in the U.S. and Canada. If small children ride in your vehicle (generally children who are four years old or younger and who weigh 40 lb. [18 kg] or less), you 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 83 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the...
Page 84 (top of ear level) above the top of the seat. In this case, move the backless booster to another seating position with a higher seat back and lap/shoulder belts. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 85 Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a collision. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 86 36 kg (80 pounds) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
Page 87 Rear facing child seats should NEVER be placed in the front seats unless the passenger airbag switch is turned off. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 88 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 89 Contact the manufacturer of your child seat for information about ordering a tether strap. The tether anchors in your vehicle are located on the back of the front seat cushion. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 90 1. Position the child safety seat on the front seat cushion. 2. Route the child safety seat tether strap over the back of the seat. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 91 3. Locate the correct anchor for the selected seating position. The tether anchor is located on the rear lower portion of the passenger seat. 4. Clip the tether strap to the anchor. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 92 Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle. This type of child seat eliminates the need to use safety belts to attach 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 93 Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 94 The LATCH anchors are below the locator symbols on the seat back. Two plastic LATCH guides may be obtained at no charge from any Ford dealer (part number 1W4Z-54613F16–AA). They snap onto the LATCH lower anchor in the vehicle to help attach a child seat with rigid LATCH attachments.
Page 95: Tires, Wheels And Loading
A vehicle equipped with AWD or 4WD (when selected) has the ability to use all four wheels to power itself. This increases traction which may enable you to safely drive over terrain and road conditions that a conventional two-wheel drive vehicle cannot. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 96 All other things held equal, a shorter wheelbase may make your vehicle quicker to respond to steering inputs than a vehicle with a longer wheelbase. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 97 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 98 Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 99 INSPECTING AND INFLATING YOUR TIRES Safe operation of your vehicle requires that your tires are properly inflated. Remember that a tire can lose up to half of its air pressure without appearing flat. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 100 (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge.
Page 101 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the tire label or certification label which is located on the B-Pillar or the edge of the driver’s door.
Page 102 Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 103: Tire Information
Both of these spare tires are considered “temporary”. Replace these temporary emergency spare tires on the vehicle with a tire of the same size, speed rating and load carrying capacity as the other road tires as soon as possible. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 104 The spare tire will be equivalent to your road tires, although it may not have the same appearance (black-side wall instead of outlined-white letters). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 105 When connecting the jack handle, assemble the following: • one handle extension and one typical extension. To assemble, slide parts together. To disconnect, depress button and pull apart. • one wheel nut wrench. Depress button and slide together. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 106 To help prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 107 6. Position the jack according to the following guides and turn the jack handle clockwise until the tire is a maximum of 1 inch (25 mm) off the ground. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 108 Reinstall the lug nuts until the wheel is snug against the hub. Do not fully tighten the lug nuts until the wheel has been lowered. 9. Lower the wheel by turning the jack handle counterclockwise. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 109 6. Install the spare tire lock (if equipped) into the access hole above the rear bumper with the spare tire lock key (if equipped) and jack handle. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 110: Lug Nut Torque
20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt and foreign materials present on the mounting surfaces of the wheel and the surface of the front disc brake hub and rotor that contacts the wheel.
Page 111 These speed ratings may need to be adjusted for the difference in conditions. The ratings range from 81 mph (130 km/h) to 186 mph (299 km/h). These ratings are listed in the following chart. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 112 Refer to the tire label or the safety certification label, which is located on the B-Pillar or the edge of the driver’s door, for the correct tire pressure for your vehicle. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 113 The tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 114 4. Maximum Load Single lb. (kg) at psi (kPa) cold: Indicates the maximum load and tire pressure when the tire is used as a single; defined as two tires (total) on the rear axle. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 115: Tire Inflation
Here are some of the important maintenance items: Tire wear Measure and inspect the tire tread on all your tires periodically. Advanced and unusual tire wear can reduce the ability of tread to grip 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 116 Safety practices Driving habits have a great deal to do with your tire mileage and safety. • Observe posted speed limits • Avoid fast starts, stops and turns 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 117 If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment. Have a qualified technician at a Ford or Lincoln Mercury dealer check the wheel alignment periodically.
Page 118 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 119: Vehicle Loading
Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s weight ratings, with or without a trailer, from the vehicle’s Safety Certification Label and Tire Label: 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 120 Overloading or improperly loading your vehicle can contribute to loss of vehicle control and vehicle rollover. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 121 Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 122 Note: For trailer towing information refer to Trailer towing found in this chapter or the RV and Trailer Towing Guide provided by your dealership. GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 123 The GCW must never exceed the GCWR. Maximum Loaded Trailer Weight – is the highest possible weight of a fully loaded trailer the vehicle can tow. It assumes a vehicle with only 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 124 = 650 lb.). In metric units (635–340 (5 x 68) = 295 kg.) 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 125 Front or the Rear Gross Axle Weight Rating specified for your vehicle on the Certification label found on the edge of the driver’s door. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 126: Trailer Towing
- ft Regular Cab w/6’ box 2.3L 4800 (2177) 1600 (726) Equal to frontal area of vehicle 3.0L* 6000 (2722) 2640 (1197) 50 (4.64) 3.0L* 6000 (2722) 2500 (1134) 50 (4.64) Edge 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 127 The Ranger is capable of pulling the maximum trailer weight(s) as specified above. Certain states require electric trailer brakes for trailers over a specified weight. The Ranger vehicle electrical system is not equipped to accommodate electric trailer brakes. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 128 The Ranger is capable of pulling the maximum trailer weight(s) as specified above. Certain states require electric trailer brakes for trailers over a specified weight. The Ranger vehicle electrical system is not equipped to accommodate electric trailer brakes. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 129 Maximum trailer weight is shown. The combined weight of the completed towing vehicle (including hitch, passengers and cargo) and the loaded trailer must not exceed the Gross Combined Weight Rating (GCWR). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 130 (5 miles [8 km] or more), or when ambient temperatures exceed 100°F (37°C), vehicle speed should not exceed 45 mph (72 km/h) in both cases. For definition of terms used in this table, see Vehicle loading earlier in this chapter. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 131 Do not install a single or multi-clamp type bumper hitch, or a hitch which attaches to the axle. Underbody mounted hitches are acceptable if they are installed properly. Follow the towing instructions of a reputable rental agency. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 132 Addition of bracketry to either lower the ball hitch position or extend the ball hitch rearward will 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 133 Driving while you tow When towing a trailer: • Turn off the speed control. The speed control may shut off automatically when you are towing on long, steep grades. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 134 Launching or retrieving a boat Disconnect the wiring to the trailer before backing the trailer into the water. Reconnect the wiring to the trailer after the trailer is removed from the water. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 135: Recreational Towing
In addition, it is recommended that you follow the instructions provided by the aftermarket manufacturer of the towing apparatus if one has been installed. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 136 If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the front (4x4 only) and rear driveshafts. Ford recommends the driveshafts be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 137: Driving
When starting a fuel-injected engine, don’t press the accelerator before or during starting. Only use the accelerator when you have difficulty starting the engine. For more information on starting the vehicle, refer to Starting the engine in this chapter. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 138 1. Make sure all occupants buckle their safety belts. For more information on safety belts and their proper usage, refer to the Seating and Safety Restraints chapter. 2. Make sure the headlamps and electrical accessories are off. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 139 • Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: 1. Make sure the parking brake is set. 2. Push the clutch pedal to the floor. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 140 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 141: Brakes
BRAKE system warning light. Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 142 BRAKE warning lamp BRAKE illuminates with the parking brake released, have your brake system serviced immediately.) Parking brake To set the parking brake (1), press the parking brake pedal down until the pedal stops. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 143 Traction-Lok axle functions like a standard rear axle. The axle may exhibit a slight noise or vibration in tight turns with low vehicle speed. This is normal behavior and indicates the axle is working. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 144: Transmission Operation
1. Apply the parking brake, turn ignition key to LOCK, then remove the key. 2. Insert the key and turn it to OFF. Apply the brake pedal and shift to N (Neutral). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 145 This learning process could take several transmission upshifts and downshifts; during this learning process, slightly firmer shifts may occur. After this learning process, normal shift feel and shift scheduling will resume. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 146 D (Drive) without Overdrive D (Drive) with Overdrive can be deactivated by pressing the transmission control switch on the ON/OFF end of the gearshift lever. • This position allows for all forward gears except overdrive. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 147 • Allows transmission to select an appropriate gear. MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch The manual transmission has a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 148 2 - 3 19 mph (26 km/h) 8 mph (10 km/h) 3 - 4 28 mph (43 km/h) 12 mph (16 km/h) 4 - 5 (Overdrive) 40 mph (68 km/h) 16 mph (26 km/h) 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 149 2. Fully apply the parking brake, then shift into 1 (First). 3. Turn the ignition off. Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 150 This is normal and should be no reason for concern. Refer to Shifting to/from 4WD Low for proper operation. 4WD system indicator lights • 4x4 - Momentarily illuminates when the vehicle is started. Illuminates when 4H (4WD High) is engaged. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 151 1. Bring the vehicle to a complete stop 2. Depress the brake 3. On vehicles equipped with an automatic transmission, place the transmission in N (Neutral); on vehicles equipped with a manual transmission, depress the clutch. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 152 If your vehicle goes off the edge of the pavement • If your vehicle goes off the edge of the pavement, slow down, but avoid severe brake application, ease the vehicle back onto the 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 153 “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency. Excessive steering will result in less vehicle control, 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 154 Normal characteristics On some 4WD models, the initial shift from two-wheel drive to 4x4 while the vehicle is moving can cause some momentary clunk and ratcheting sounds. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 155 Driving through deep water may damage the transmission. If the front or rear axle is submerged in water, the axle lubricant should be replaced. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 156 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 157 Never drive with chains on the front tires of 4WD vehicles without also putting them on the rear tires. This could cause the rear to slide and swing around during braking. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 158 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 159: Roadside Emergencies
50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...
Page 160: Fuel Pump Shut-Off Switch
Roadside Emergencies Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140.
Page 161: Fuses And Relays
Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 162 A fuse puller tool is located near the top left corner of the fuse box; this tool will assist you in pulling the fuses out for inspection, if necessary. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 163 Right low beam headlamp Left low beam headlamp Windshield wipers/washer Radio (RUN/ACCY) Headlamp illumination indicator Restraints Control Module (RCM), PADI (Passenger Air bag Deactivation Indicator) Cluster air bag indicator Cluster (RUN/START), 4x4 module (RUN/START) 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 164 Headlamps (low and high beam) Radio — Accessory relay Brake pressure switch Climate control blower relay/blend doors, 4x4 module 4x4 module B+ Cigar lighter or power point, Diagnostic connector (OBD II) Power mirrors 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 165 To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and Specifications chapter. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 166 Interior fuse panel (SJB) — Not used 40A** Starter — Not used 40A** Ignition switch — Not used 30A** Powertrain Control Module (PCM), Engine sensors — Not used 30A** Blower motor (climate control) 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 167 — Not used 7.5A* Trailer tow (right turn) — Not used — Not used 15A* Heated Exhaust Gas Oxygen (HEGO) sensors, EVAP canister vent valve, Exhaust Gas Recirculation (EGR) stepper motor, Transmission 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 168 — Not used — Not used — Not used — Not used — PCM relay — Blower relay — A/C clutch solenoid relay — Not used * Mini Fuses ** Maxi Fuses 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 169 — Not used 40A** Starter — Not used 40A** Ignition switch — Not used 30A** Powertrain Control Module (PCM), Engine sensors — Not used 30A** Blower motor (climate control) — Not used 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 170 Trailer tow (right turn) — Not used — Not used 15A* Heated Exhaust Gas Oxygen (HEGO) sensors, EVAP canister vent valve, Exhaust Gas Recirculation (EGR) stepper motor, Transmission 7.5A* Trailer tow (left turn) 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 171: Jump Starting
This operation is considered normal and will not affect function or durability of the transmission. Over time, the adaptive learning process will fully update transmission operation. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 172 Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 173 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 174 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 175 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 176: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. On 4x2 vehicles, it is acceptable to tow the vehicle with the front wheels on the ground and the rear wheels off the ground.
Page 177: Customer Assistance
Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 178 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 179 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the...
Page 180 THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes. • available free to owners and lessees of qualifying Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford...
Page 181 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 182 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 183 4,600 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
Page 184 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 185: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 186: Cleaning
Liquid Wax (ZC-53-A), which is available from your dealer, or an equivalent quality product. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 187 • Do not spray a hot engine with cold water to avoid cracking the engine block or other engine components. • Spray Motorcraft Engine Shampoo and Degreaser (ZC-20) on all parts that require cleaning and pressure rinse clean. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 188 Cleaning • Cover the highlighted areas to prevent water damage when cleaning the engine. • 2.3L I4 engine • 3.0L V6 engine 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 189 INSTRUMENT PANEL AND CLUSTER LENS Clean the instrument panel with a damp cloth, then with a clean, dry cloth, or use Motorcraft Dash & Vinyl Cleaner (ZC-38-A). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 190 • Do not use household cleaning products, alcohol solutions, solvents or cleaners intended for rubber, vinyl and plastics, or oil/petroleum-based leather conditioners. These products may cause premature wearing of the clear, protective coating. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 191 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 192 Motorcraft Tire Clean and Shine (ZC-28) Motorcraft Triple Clean (U.S. only) (ZC-13) Motorcraft Ultra-Clear Spray Glass Cleaner (ZC-23) Motorcraft Vinyl Cleaner (Canada only) (CXC-93) Motorcraft Vinyl Conditioner (Canada only) (CXC-94) Motorcraft Wheel and Tire Cleaner (ZC-37–A) 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 193: Maintenance And Specifications
2. Turn off the engine and remove the key. 3. Block the wheels. Working with the engine on • Automatic transmission: 1. Set the parking brake and shift to P (Park). 2. Block the wheels. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 194 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood. 3. Lift the hood and support it with the prop rod. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 195: Engine Compartment
4. Transmission fluid dipstick (automatic transmission) 5. Engine oil filler cap 6. Brake fluid reservoir 7. Power distribution box 8. Clutch fluid reservoir (manual transmission) 9. Battery 10. Power steering fluid reservoir 11. Air filter assembly 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 196 4. Automatic transmission fluid dipstick (if equipped) 5. Engine oil dipstick 6. Brake fluid reservoir 7. Power distribution box 8. Clutch fluid reservoir (if equipped) 9. Battery 10. Power steering fluid reservoir 11. Air filter assembly 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 197 4. Engine oil dipstick 5. Brake fluid reservoir 6. Power distribution box 7. Clutch fluid reservoir (if equipped) 8. Battery 9. Power steering fluid reservoir 10. Air filter assembly 11. Engine coolant reservoir 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 198 Washer fluids containing non-methanol antifreeze agents should be used only if they provide cold weather protection without damaging the vehicle’s paint finish, wiper blades or washer system. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 199: Engine Oil
3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmission) or 1 (First) (manual transmission). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 200 Maintenance and Specifications • 2.3L I4 engine • 3.0L V6 engine 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 201 • If the oil level is below the lower hole or the MIN mark, add enough oil to raise the level between the two holes or between the MIN-MAX range. • 2.3L I4 engine 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 202 7. Put the indicator back in and ensure it is fully seated. Adding engine oil 1. Check the engine oil. For instructions, refer to Checking the engine oil in this chapter. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 203 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 204 Change your engine oil according to the appropriate schedule listed in the scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 205: Battery
Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 206 This operation is considered normal and will not affect function or durability of the transmission. Over time the adaptive learning process will fully update transmission operation to its optimum shift feel. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 207: Engine Coolant
50–50 mixture of coolant and water provides the following: • Freeze protection down to -34°F (-36°C). • Boiling protection up to 265°F (129°C). • Protection against rust and other forms of corrosion. • Enables calibrated gauges to work properly. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 208 Maintenance and Specifications • 2.3L engines • 3.0L and 4.0L engines 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 209 • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (U.S., except CA, OR and NM), VC-7–B (CA, OR and NM), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
Page 210 Maintenance and Specifications CXC-209 (Canada), meeting Ford specification WSS-M97B44–D with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine Coolant or any orange-colored extended life product with your factory filled coolant can result in degraded corrosion protection. • A large amount of water without engine coolant may be added, in case of emergency, to reach a vehicle service location.
Page 211 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 212 If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 213 4. Check the coolant level and replenish if low. Never remove the coolant reservoir cap while the engine is running or hot. 5. Restart the engine and take your vehicle to a service facility. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 214 If fuel is swallowed, call a physician immediately, even if no symptoms are immediately apparent. The toxic effects of fuel may not be visible for hours. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 215 • Keep sparks, flames and smoking materials away from fuel; • Stay outside your vehicle and do not leave the fuel pump unattended when refueling your vehicle — this is against the law in some places; 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 216 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 217 “Regular” unleaded gasoline because it may cause these problems to become more pronounced. If the problems persist, see your dealer or a qualified service technician. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 218 Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 219 1. Fill the fuel tank completely and record the initial odometer reading (in miles or kilometers). 2. Each time you fill the tank, record the amount of fuel added (in gallons or liters). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 220 Unnecessary shifting of this type could result in reduced fuel economy. • Warming up a vehicle on cold mornings is not required and may reduce fuel economy. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 221 Every new vehicle should have the EPA window sticker. Contact your dealer if the window sticker is not supplied with your vehicle. The EPA window sticker should be your guide for the fuel economy comparisons with other vehicles. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 222 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 223 I/M test with the Check engine/Service engine soon light on. If the vehicle’s powertrain system or its battery has just been serviced, the on-board diagnostics system is reset to a “not ready for I/M test” 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 224 Once started, do not turn off the engine until the above driving cycle is complete. CHECKING AND ADDING POWER STEERING FLUID • 2.3L I4 engine • 3.0L V6 engine 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 225 6. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the FULL HOT range. Be sure to put the dipstick back in the reservoir. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 226 If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Ford specification ESA-M6C25–A. Refer to Lubricant specifications in this chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 227 10. Fluid can be checked at ambient temperatures between 50–95°F (10–30°C). DO NOT ADD fluid until the transmission is at normal operating temperatures or the transmission will be overfilled. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 228 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 229 Maintenance and Specifications Use only fluid that meets Ford specifications. Refer to Lubricant specifications in this chapter. Checking and adding transfer case fluid (if equipped) 1. Clean the filler plug. 2. Remove the filler plug and inspect the fluid level.
Page 230: Air Filter(S)
7. Replace the air filter housing cover and secure the clamps. 8. Replace the air inlet tube and secure the clamp. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 231: Part Numbers
Refer to scheduled maintenance information for the appropriate intervals for changing the PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 232: Refill Capacities
DOT 3 Motor on reservoir Vehicle Brake Fluid Power steering Motorcraft 3.0L engine Fill to FULL fluid MERCON ATF HOT line on dipstick 2.3L and 4.0L Fill to MAX line engine on the reservoir 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 233 15.1 quarts with manual (14.3L) transmission 3.0L V6 engine 14.8 quarts with automatic (14.0L) transmission 4.0L V6 engine 13.7 quarts with manual (13.0L) transmission 4.0L V6 engine 13.2 quarts with automatic (12.5L) transmission 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 234 MERCON and MERCON V. Refer to the scheduled maintenance information to determine the correct service interval. Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and if equipped with an in-tank cooler. The amount 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 235: Lubricant Specifications
9/16 inch (6mm to 14mm) below the bottom of the filler hole. Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the requirements of Ford specification WSS-M2C930-A and the API Certification mark. LUBRICANT SPECIFICATIONS...
Page 236 Oil (Canada) Engine oil 4.0L engines XO-5W30-QSP WSS-M2C929–A Motorcraft SAE (US) and API 5W-30 Premium CXO-5W30-LSP12 Certification Synthetic Blend (Canada) Mark Motor Oil (US) Motorcraft SAE 5W-30 Super Premium Motor Oil (Canada) 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 237 MERCON ATF case fluid (4X4) and transmission fluid (manual) Automatic Motorcraft XT-5-QM MERCON V transmission MERCON V (5R44E and 5R55E) Motorcraft ZC-32–A WSB-M8B16–A2 Premium Windshield Windshield washer fluid Washer Concentrate 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 238 Maintenance and Specifications Add 118 ml (4 oz.) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 239 Maintenance and Specifications 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 240 Certification label may be located. The Certification label is located on the structure by the trailing edge of the driver’s door or the edge of the driver’s door. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 241 7. Assembly plant 8. Production sequence number Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped). 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 242 You can find a transmission/transaxle code on the vehicle certification label. The following table tells you which transmission or transaxle each code represents. Code Description Five-speed automatic (5R44E/5R55E) Five-speed manual (HD) Five-speed manual (R1) 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 243: Accessories
In addition, each accessory is made from high quality materials and meets or exceeds Ford’s rigorous engineering and safety specifications. Ford Motor Company will repair or...
Page 244 TracRac and accessories Trailer hitches, wiring harnesses and accessories Peace of mind First aid and highway safety kits Full vehicle covers Locking gas cap Navigation systems Remote start Vehicle security systems Keyless entry keypad 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 245 • Electrical or electronic accessories or components that are added to the vehicle by the dealer or the owner may adversely affect battery performance and durability. 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 246: Index
Battery ........205 interior ........190 acid, treating emergencies ..205 plastic parts ......189 jumping a disabled battery ..171 safety belts ......190 maintenance-free ....205 washing ........186 replacement, specifications ...231 waxing ........186 servicing ........205 wheels ........187 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 247 ......171 Cruise control Emergency Flashers ....160 (see Speed control) ....50 Emission control system ..222 Customer Assistance ....159 Engine ........238 Ford accessories for your cleaning ........187 vehicle ........191 coolant ........207 Ford Extended Service fail-safe coolant ......212 Plan ..........183 idle speed control ....205...
Page 248 Fuel pump shut-off switch ..160 interior ........38 Fuses ........161–162 Jack ..........103 positioning .......103, 106 Gas cap (see Fuel cap) ....216 storage ......103–105 Gas mileage Jump-starting your vehicle ..171 (see Fuel economy) ....218 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 249 Safety Belt Maintenance ....72 side view mirrors (power) ..50 Safety belts (see Safety Motorcraft parts ....218, 231 restraints) ......62, 64–66 Safety defects, reporting ..185 Safety restraints ....62, 64–66 Octane rating ......217 belt minder .......69 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 250 Turn signal ........40 Starting your vehicle ......137–138, 140 jump starting ......171 Steering wheel Vehicle dimensions ....238 tilting .........48 Vehicle Identification Number (VIN) ..........241 Vehicle loading ......119 Tilt steering wheel ......48 camper bodies ......158 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
Page 251 .........49 Windshield washer fluid and wipers ..........47 Warning lights (see Lights) ..10 checking and adding fluid ..198 Washer fluid ......198 replacing wiper blades .....47 Water, Driving through .....158 Wrecker towing ......176 2005 Ranger (ran) Owners Guide (post-2002-fmt) USA (fus)
