Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 7 Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury. Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.
Page 8 For additional information, please contact the Truck Body Builders Advisory Service at 1–877–840–4338. Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance...
Page 9 Using your vehicle as a stationary power source (PTO) Refer to the Driving chapter for more information and guidelines for operating a vehicle equipped with an aftermarket power take-off system. Middle East/North Africa vehicle specific information For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide;...
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Child Seat Tether Anchor Anti-Lock Brake System Powertrain Malfunction Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist...
Page 11 Vehicle Symbol Glossary Power Windows Front/Rear Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus) Introduction...
Page 12: Instrument Cluster
Instrument Cluster Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 13 Electronic throttle control (if equipped): Illuminates when the engine has defaulted to a ’limp-home’ operation. Report the fault to a dealer at the earliest opportunity. Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service Engine Soon warning light to come on, refer to Fuel filler cap in the...
Page 14 Instrument Cluster Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt. Charging system: Illuminates when the battery is not charging properly. Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).
Page 15: Gauges
Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened. Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.
Page 16 Instrument Cluster Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 17 Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range, have the vehicle’s electrical system checked as soon as possible. Engine oil pressure gauge: Indicates engine oil pressure.
Page 18: Entertainment Systems
Entertainment Systems Entertainment Systems AM/FM STEREO (IF EQUIPPED) 1. Seek: Press to find the next listenable station down/up the frequency band. 2. Tune: Press to manually adjust the radio frequency down/up. 3. AM/FM: Press to choose a frequency band in radio mode. REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 19 4. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns. 5. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels. 6. Tone: Press TONE until the desired level —...
Page 20: Am/Fm Stereo Cassette
Entertainment Systems AM/FM STEREO CASSETTE (IF EQUIPPED) 14 15 16 17 VOL - PUSH ON BASS TREB SEEK SCAN TUNE 1. Balance: Press to shift sound to the left/right speakers. 2. Fade: Press to shift sound to the rear/front speakers. 3.
Page 21 4. Tape AMS: In tape mode, press and hold to activate Automatic Music Search (allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection). Then, press REW (for the beginning of the current selection) or FF (to advance to the next selection).
Page 22: Am/Fm Stereo With Cd
Entertainment Systems 13. AM/FM: Press to choose a frequency band in radio mode. 14. Bass: Press decrease/increase the bass output. 15. Treble: Press decrease/increase the treble output. 16. EJ (Eject): Press to eject a tape. 17. Cassette door: Insert a cassette into the cassette door. AM/FM STEREO / SINGLE CD RADIO (IF EQUIPPED) 14 15 16 17 18 VOL - PUSH ON...
Page 23 1. Balance: Press to shift sound to the left/right speakers. 2. Fade: Press to shift sound to the front/rear speakers. 3. SCN (Scan): Press to hear a brief sampling of all listenable stations or CD tracks. Press again to stop. 4.
Page 24 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed.
Page 25: Am/Fm Stereo With In-Dash Six Cd
felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information. PREMIUM IN-DASH SIX CD SOUND SYSTEM (IF EQUIPPED) DISC SHUF SCAN TUNE LOAD PUSH ON 12 11 1. Seek: Press and release SEEK for previous/next strong station, or track of the...
Page 26 Entertainment Systems 5. Eject: Press to eject a CD. Press and hold to eject all loaded discs. If disc is not removed, it will reload into the system. Works with the ignition on or off. 6. Bass: Press BASS; then press to decrease/increase the bass output.
Page 27 Show TYPE: Displays the station’s call letters format. Shuffle: With a CD playing, press to play tracks in a random order. Press MENU until SHUF appears in the display. Use SEL to select SHUF DISC, SHUF TRAC or SHUF OFF. Compression: With a CD playing, this feature brings soft and loud CD passages together for a more consistent listening level.
Page 28 Entertainment Systems 14. Load: Press LOAD to load a CD in the system. The display will read SELECT SLOT. Select the desired memory preset slot (1–6). The display will then read LOAD CD. Partially load the CD label side up and the system will pull the CD in. LOADING CD# will appear in the display.
Page 29 1. SEEK: Press and release SEEK for previous/next strong station or track. 2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection. When MP3 selection text is shown on the message display, its corresponding text indicator (Fi, So, Ar, or AL) is shown in the elapsed time display.
Page 30 Entertainment Systems 7. Select: Use with Bass, Treble, Balance, Fade and other menu selections. 8. Balance: Press BAL; then press to shift sound to the left/right speakers. Fade: Press FADE; then press to shift sound to the rear/front speakers. 9. Menu: Press MENU and SEL to access AUTOSET, Speed sensitive volume and Setting the clock.
Page 31 13. FOLDER : Press to access the previous MP3 directory. 14. FF(Fast forward): In CD/MP3 mode, press until desired selection is reached. 15. REW(Rewind): In CD/MP3 mode, press until desired selection is reached. 16. SAT (if equipped): Your radio comes equipped with Satellite Ready capability.
Page 32 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 33 PREMIUM SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SIX CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED) 1. SEEK: Press and release SEEK for previous/next strong station or track. 2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection.
Page 34 Entertainment Systems 3. AUX: Press to toggle between the current playing media and DVD (if equipped). 4. MUTE: Press to MUTE playing media; press again to return to playing media 5. EJ: Press to eject a CD. Press EJ and a memory preset to eject a specific disc.
Page 35 Folder/Track Mode: In MP3 mode, press MENU until MODE appears in the display. Use SEL to toggle between FOLDER (only tracks within selected folder are accessible) or TRACK (all tracks on disc are accessible) MODE. 10. REPEAT: Press to repeat the current CD/MP3 track.
Page 36 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 37 RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz RADIO RECEPTION FACTORS There are three factors that can affect radio reception: •...
Page 38 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 39: Climate Controls
Climate Controls HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 40: Manual Heating And Air Conditioning
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 41 To aid in side window defogging/demisting in cold weather: 1. Select MIX. 2. Set the temperature control to maintain comfort. 3. Set the fan speed to HI. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. REAR FAN SPEED ADJUSTMENT (IF EQUIPPED) The rear fan controls adjust the volume of air circulated in the rear...
Page 42: Lights
Lights Lights HEADLAMP CONTROL • The first position turns on the parking, tail, license plate and side marker lamps. • The outer position turns on the headlamps. Battery saver The battery saver will turn off the courtesy lamps in 10 minutes if a door is left open and the key is not in the ignition.
Page 43 Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Lamp (DRL) system does not activate the tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision. High beams Push the lever toward the instrument panel to activate.
Page 44 Lights HEADLAMP AIM ADJUSTMENT The headlamps are designed to be mechanically aimed, but can also be aimed visually by doing the following: 1. Park your vehicle on a level surface about 25 feet (7.6 meters) away from a vertical plain surface (3).
Page 45 • Aerodynamic: Locate the vertical adjuster (2) for each headlamp. Adjust the aim by turning the adjuster control either clockwise (to adjust up) or counterclockwise (to adjust down). • Sealed beam: Locate the vertical adjuster (1) for each headlamp. Adjust the aim by turning the adjuster control either clockwise (to adjust up) or counterclockwise (to adjust...
Page 46: Turn Signal Control
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Cargo and dome lamps with rear headliner Rear cargo lamps equipped with an ON/OFF/DOOR control will light when: •...
Page 47: Bulb Replacement
Front and rear courtesy/reading lamps The dome portion of the lamp, the center light, can be turned on when the headlamp control is rotated fully counterclockwise or when any door is opened. The reading lamp portion, the two outer lights, can only be toggled on and off at the lamp.
Page 48 Lights Replacing headlamp bulbs (aerodynamic) 1. Make sure headlamp switch is in the OFF position and open the hood. 2. Push each clip tab toward the engine compartment and lift upward to the stop position, then remove the headlamp assembly. 3.
Page 49 Replacing headlamp bulbs (sealed beam) 1. Make sure headlamp switch is in the OFF position and open the hood. 2. Remove the two headlamp screws and bezel from the headlamp housing. 3. Remove the four headlamp bulb retaining screws and the retaining ring.
Page 50 Lights Replacing high-mount brakelamp bulbs The interior cargo lamp (if equipped), on vehicles without a rear headliner, will have to be removed from under the high-mount brakelamp assembly located inside the vehicle. Then: 1. Remove the two screws from the high-mount brakelamp assembly and lift the lamp from the vehicle.
Page 51 Replacing tail lamp/turn/backup lamp bulbs 1. Turn the headlamp switch to the OFF position and then remove the four screws and the lamp assembly from vehicle. 2. Rotate bulb socket counterclockwise and remove from lamp assembly. 3. Carefully pull the bulb straight out of the socket and push in the new bulb.
Page 52: Driver Controls
Driver Controls Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
Page 53: Steering Wheel Adjustment
TILT STEERING WHEEL To adjust the steering wheel: 1. Pull and hold the steering wheel release control toward you. 2. Move the steering wheel up or down until you find the desired location. 3. Release the steering wheel release control. This will lock the steering wheel in position.
Page 54 Driver Controls Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: 1. Place Velcro hook onto side of aftermarket transmitter opposite of actuator control. 2. Place the transmitter into storage compartment, control down.
Page 55 Compass The compass display is contained in the overhead console. The vehicle heading is displayed as one of N, NE, E, SE, S, SW, W and NW. The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in or on the vehicle may also affect compass accuracy.
Page 56 Driver Controls • Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles. • The compass is now calibrated. CELL PHONE USE The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs.
Page 57: Power Windows
Always keep the power point caps closed when not being used. POWER WINDOWS (IF EQUIPPED) Do not leave children unattended in the vehicle and do not let children play with the power windows. They may seriously injure themselves. When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.
Page 58 Driver Controls Standard mirror The spotter mirror only can be tilted from top to bottom. Move the lower mirror manually up/down to increase side and rear visibility. Apply pressure only in the center of the spotter mirror along the top or bottom edges to adjust the tilt feature.
Page 59: Speed Control
The telescoping feature (if equipped) allows the mirror to extend approximately 3.15 inches (80 mm). This feature is especially useful to the driver when towing a trailer. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal.
Page 60 Driver Controls Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 30 mph (48 km/h). Increasing speed while using speed control There are two ways to set a higher speed:...
Page 61 • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACCEL control. Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicle’s previously set speed.
Page 62: Locks And Security
Locks and Security Locks and Security KEYS The key operates all locks on your vehicle. You should always carry a second key with you in a safe place in case you require it in an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start.
Page 63 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The typical operating range for your remote entry transmitter is approximately 33 feet (10 meters). A decrease in operating range could be caused by: •...
Page 64 Locks and Security Sounding a panic alarm Press to activate the alarm. Press the control again, or turn the ignition to the 1 (ACCESSORY) or 4 (ON) position to deactivate the alarm. Note: The panic alarm will only operate when the ignition is in the 2 (LOCK) or 3 (OFF) position.
Page 65 Note: Replacement of the battery will not cause the remote transmitter to become deprogrammed from your vehicle. The remote transmitter should operate normally after battery replacement. Replacing lost remote entry transmitters If you would like to have your remote entry transmitter reprogrammed because you lost one, or would like to buy additional remote entry transmitters, you can either reprogram them yourself, or take all remote entry transmitters to your authorized dealer for...
Page 66 Locks and Security Illuminated entry The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm. The illuminated entry system will turn off the interior lights if: • the ignition switch is turned to the 4 (ON) or 1 (ACCESSORY) position, or •...
Page 67: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 68 Seating and Safety Restraints Pull lever up to adjust seatback. Using the manual lumbar support The lumbar support control is located on the inboard side of the driver’s seat. Turn the lumbar support control clockwise to increase firmness. Turn the lumbar support control counterclockwise to increase softness.
Page 69 Seating and Safety Restraints Press to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. Quick release captains chair (7 passenger configuration second row only) To remove the seat: 1.
Page 70 Seating and Safety Restraints Stow the tongue end of the detachable anchor. 2. Pull the seat latch handle, then pull the seat toward the right side of the vehicle to disengage four pins from the floor mount. 3. Remove the seat. To install the seat: Check to see that the seat and seatback is latched securely in position.
Page 71 Seating and Safety Restraints REAR SEATS Accessing the 3rd, 4th and 5th row seats (if equipped) To make access to the 4th and 5th row seats easier, attach the 3rd and 4th row passenger side seat belts to the trim panel by using the snaps attached to the seat belt webbing and the trim panel.
Page 72 Seating and Safety Restraints 2. Pull the LH/RH seat latch handles, located under the seat, rearward to release the latch hook ends from the front strikers. 3. Move the seat rearward and lift the seats rear hooks away from the rear strikers prior to lifting the front hooks out from the front strikers.
Page 73: Safety Restraints
Seating and Safety Restraints SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips. To reduce the risk of injury, make sure children sit in the back seat where they can be properly restrained.
Page 74 Seating and Safety Restraints Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them. Combination lap and shoulder belts 1.
Page 75 Seating and Safety Restraints Automatic locking mode When to use the automatic locking mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. This mode should be used any time a child safety seat is installed in a passenger front or outboard rear seating position (if equipped).
Page 76 Seating and Safety Restraints How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. After any vehicle collision, the safety belt systems at all outboard seating positions (except the driver position, which does not have this feature) must be checked by a qualified technician to verify that the automatic locking retractor feature for child seats is still...
Page 77 Seating and Safety Restraints Front safety belt height adjustment The driver and front seat outboard positions are equipped with a height adjuster. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To adjust the shoulder belt height, push the button and slide the height adjuster up or down.
Page 78 Seating and Safety Restraints Shorten and fasten the belt when not in use. Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If...
Page 79 Seating and Safety Restraints If... The driver’s safety belt is not buckled approximately 5 seconds after the safety belt warning light has turned off... The driver’s safety belt is buckled while the safety belt indicator light is illuminated and the safety belt warning chime is sounding...
Page 80 Seating and Safety Restraints Reasons given... “I was in a hurry” “Seat belts don’t work” “Traffic is light” “Belts wrinkle my clothes” “The people I’m with don’t wear belts” “I have an air bag” “I’d rather be thrown clear” Do not sit on top of a buckled safety belt to avoid the Belt Minder chime.
Page 81 Seating and Safety Restraints Deactivating/activating the BeltMinder feature Read steps 1 - 5 thoroughly before proceeding with the deactivation/activation programming procedure. The BeltMinder feature can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that: • the parking brake is set •...
Page 82 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 83: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag.
Page 84 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Modifying or adding equipment to the front end of the vehicle...
Page 85 Seating and Safety Restraints Children and air bags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 86 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder or sodium compounds which may irritate the skin and eyes, but none of the residue is toxic.
Page 87: Child Restraints
Seating and Safety Restraints Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system. Refer to Air bag readiness section in the Instrument Cluster chapter. Routine maintenance of the air bag is not required.
Page 88 • forward-facing child safety seats can be used in the center of the three-passenger 2nd row bench seat only if a top tether strap is used; • Ford recommends placing forward-facing safety seats in the 2nd row and using top tether straps for added protection.
Page 89 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 90 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 91 Seating and Safety Restraints Follow all instructions provided by the manufacturer of the booster seat. Never put the shoulder belt under a child’s arm or behind the back because it eliminates the protection for the upper part of the body and may increase the risk of injury or death in a collision. Never use pillows, books, or towels to boost a child.
Page 92 80 pounds (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
Page 93 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 94 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 95 Seating and Safety Restraints Attaching safety seats with tether straps Children should be placed in the rear in an appropriate child safety seat that is properly secured to the vehicle. When using forward-facing child safety seats in vehicles with only two seating positions so the forward-facing child safety seat cannot be placed in the rear of the vehicle, move the passenger seat as far back from the instrument panel as possible.
Page 96 Seating and Safety Restraints 1. Position the child safety seat on the front right-hand passenger seat. 2. Adjust the front right-hand passenger seat full forward. 3. Route the child safety seat tether strap over the back of the front right-hand passenger seat as shown. 4.
Page 97 Seating and Safety Restraints 5. Adjust the front right hand passenger seat to the full rearward position. 6. Install the child safety seat tightly using the LATCH anchors or safety belts. Follow the instructions in this chapter. 7. Tighten the child safety seat tether strap according to the manufacturer’s instructions.
Page 98 Seating and Safety Restraints 1. Position the child safety seat on the second row left hand or right hand bucket seat. 2. Route the child safety tether strap over the back of the left hand or right hand second row bucket seat.
Page 99 Seating and Safety Restraints 2. Route the child safety tether strap over the back of 3–Passenger bench seat. 3. Clip the tether strap hook to the tether bracket mounted under rear rail of seat cushion frame. 4. Install the child safety seat tightly using the LATCH anchors or safety belts.
Page 100 Seating and Safety Restraints Your vehicle may be equipped with LATCH anchors for child seat installation at the seating positions marked with the child seat symbol: • Five passenger crew van • Seven passenger wagon • Eight passenger wagon • Twelve passenger wagon REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 101 Seating and Safety Restraints • Fifteen passenger wagon represents LATCH anchors. represents tether strap anchors. Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
Page 102 Seating and Safety Restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat.
Page 103: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 104 Tires, Wheels and Loading VEHICLE CHARACTERISTICS How your vehicle differs from other vehicles SUV and trucks can differ from some other vehicles in a few noticeable ways. Your vehicle may • Higher – to allow higher load carrying capacity and to allow it to travel over rough terrain without getting hung up or damaging underbody components.
Page 105 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 106: Tire Information
Tires, Wheels and Loading The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 107: Tire Inflation
(including spare, if equipped). Inflate all tires to the inflation pressure recommended by Ford Motor Company. REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 108 (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge.
Page 109 higher than the manufacturer’s recommended cold inflation pressure which can be found on either the tire label or certification label which is located on the B-Pillar or the edge of the driver’s door. The cold inflation pressure should never be set lower than the recommended pressure on the tire label or certification label.
Page 110 Tires, Wheels and Loading Tire inflation information All tires with Steel Carcass Plies (if equipped): This type of tire utilizes steel cords in the sidewalls. As such, they cannot be treated like normal light truck tires. Tire service, including adjusting tire pressure, must be performed by personnel trained, supervised and equipped according to Federal Occupational Safety and Health Administration (OSHA) regulations.
Page 111: Changing Tires
Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 112 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 113 To remove the spare tire: 1. Open the rear doors and remove the thumb screw and anti-theft bracket. If finger pressure will not remove the thumb screw, use the lug wrench to loosen the screw. 2. Remove the access plug under the left door.
Page 114 Tires, Wheels and Loading 4. Apply the parking brake and turn the engine off. 5. Block the wheel that is diagonally opposite the tire you are changing. On E-450 vehicles, the parking brake is on the transmission. Therefore, the vehicle will not be prevented from moving when a rear wheel is lifted, even if the parking brake is applied.
Page 115 • the jack is located in the rear right-hand side of the cargo area. 7. Use the tapered end of the lug nut wrench to unscrew wheel ornaments attached by retaining screws. Remove any wheel trim. Insert the tapered end of the lug nut wrench behind wheel covers or hubcaps and twist off.
Page 116 Tires, Wheels and Loading • Never use the front or rear differential as a jacking point. Rear axle jacking points - All models except E-350 Dual Rear Wheel (DRW) and E-450: Rear axle jacking points - E-350 Dual Rear Wheel (DRW) and E-450: REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002),...
Page 117 Front axle jacking points: Place the jack under the pin on the front surface of the front axle. Do not place the jack under or on the steering linkage. • Raise the jack until the wheel is completely off the ground. (Turn jack handle clockwise if your vehicle is equipped with a screw-type jack or pump the jack...
Page 118 Tires, Wheels and Loading • 8-lug wheel Never use wheels or lug nuts different than the original equipment as this could damage the wheel or mounting system. This damage could allow the wheels to come off while the vehicle is being driven. 6.
Page 119: Lug Nut Torque
E-250, E-350 and E-450: 9/16–18 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. On all two-piece flat wheel nuts, apply one drop of motor oil between the flat washer and the nut. Do not apply motor oil to the wheel nut threads or the wheel stud threads.
Page 120 Tires, Wheels and Loading When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the front disc brake hub and rotor that contacts the wheel. Installing wheels without correct metal-to-metal contact at the wheel mounting surfaces can cause the wheel nuts to loosen and the wheel to come off while the vehicle is in motion, resulting in loss of control.
Page 121 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. 6. 95: Indicates the tire’s load index. It is an index that relates to how much weight a tire can carry.
Page 122 Tires, Wheels and Loading 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 123 13. Maximum Permissible Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on either the tire label or certification label which is located on the B-Pillar or the edge of the driver’s door.
Page 124 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 125 TIRE CARE Improper or inadequate vehicle maintenance can also cause tires to wear abnormally. Here are some of the important maintenance items: Tire wear Measure and inspect the tire tread on all your tires periodically. Advanced and unusual tire wear can reduce the ability of tread to grip the road in adverse (wet, snowy, etc.) conditions.
Page 126 If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment. Have a qualified technician at a Ford or Lincoln/Mercury dealer check the wheel alignment periodically.
Page 127 The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. Tire rotation Rotating your tires at the recommended interval (as indicated in the Scheduled Maintenance Guide that comes with your vehicle) will help your tires wear more evenly, providing better tire performance and longer tire life.
Page 128 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln/Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 129: Vehicle Loading
SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
Page 130 Tires, Wheels and Loading Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 131 GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the driver’s door or B-Pillar.
Page 132 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 133 Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX pounds” on your vehicle’s placard. 2.
Page 134 Tires, Wheels and Loading • Another example for your vehicle with 1400 pounds of cargo and luggage capacity. You and one of your friends decide to pick up cement from the local home improvement store to finish that patio you have been planning for the past 2 years. Measuring the inside of the vehicle with the rear seat folded down, you have room for 12-100 pound bags of cement.
Page 135: Trailer Towing
TRAILER TOWING Your vehicle may tow a class I, II or III trailer, provided the maximum trailer weight is less than or equal to the maximum trailer weight listed for your engine and rear axle ratio on the following charts. GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum...
Page 136 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) .E-250 Regular Van (8600 GVWR) 11000 4.6L 4.10 (4990) 13000 5.4L 3.73 (5897) E-250 Regular Van (Crew) (8600 GVWR) 11000 4.6L 4.10 (4990) 13000...
Page 137 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Regular Van (Crew) (9500 GVWR) 12000 5.4L 3.55 (5443) 13000 5.4L 4.10 (5897) 15000 6.8L 3.73 (6804) 17700 6.8L 4.10 (7711) E-350 Extended Van (9400 GVWR) 12000...
Page 138 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Regular Wagon (7–passenger) (8600 GVWR) 13000 5.4L 3.73 (5897) E-350 Regular Wagon (7–passenger) (8700 GVWR) 15000 6.8L 3.73 (6804) 17700 6.8L 4.10 (7711)
Page 139 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Extended Wagon (12–passenger) (9300 GVWR) 12000 5.4L 3.55 (5443) 13000 5.4L 4.10 (5897) 15000 6.8L 3.73 (6804) 17700 6.8L 4.10 (7711) E-350 Extended Wagon (15–passenger) (9100 GVWR) 12000...
Page 140 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Cutaway (138” wheelbase, dual rear wheel) (10700 GVWR) 13000 5.4L 4.10 (5897) 18500 6.8L 4.10 (8391) E-350 Cutaway (158” wheelbase, dual rear wheel) (11500 GVWR) 13000 5.4L...
Page 141 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Stripped Chassis (138” wheelbase) (10000 GVWR) 13000 5.4L 4.10 (5897) 18500 6.8L 4.10 (8391) E-350 Stripped Chassis (158” wheelbase) (10000 GVWR) 13000 5.4L 4.10...
Page 142 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-450 Cutaway (176” wheelbase) (14050 GVWR) 20000 6.8L 4.56 (9072) E-450 Stripped Chassis (158” wheelbase) (14050 GVWR) 18500 6.8L 4.56 (8391) E-450 Stripped Chassis (176”...
Page 143 Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury. Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle.
Page 144 Tires, Wheels and Loading Using a step bumper (if equipped) The rear bumper is equipped with an integral hitch and only requires a ball with a one inch (25.4 mm) shank diameter. The bumper has a 5,000 lb. (2,270 kg) trailer weight and 500 lb. (227 kg) tongue weight capacity. If it is necessary to relocate the trailer hitch ball position, a frame-mounted trailer hitch must be installed.
Page 145 • If you will be towing a trailer frequently in hot weather, hilly conditions, at GCW, or any combination of these factors, consider refilling your rear axle with synthetic gear lube. Refer to the Maintenance and specifications chapter for the lubricant specification.
Page 146: Recreational Towing
If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, the drive shaft will have to be removed. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 147: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 148 Driving Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Do not start your vehicle in a closed garage or in other enclosed areas.
Page 149 • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). • Turn the key to 4 (ON) without turning the key to 5 (START). Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced.
Page 150 Driving Starting the engine 1. Turn the key to 4 (ON) without turning the key to 5 (START). 2. Turn the key to 5 (START), then release the key as soon as the engine starts. Excessive cranking could damage the starter. Note: If the engine does not start within five seconds on the first try, turn the key to 3 (OFF), wait 10 seconds and try again.
Page 151: Brakes
BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by a qualified service technician. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by a qualified service technician.
Page 152 Driving Parking brake To set the parking brake (1), press the parking brake pedal down until the pedal stops. To release, pull the lever (2). Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park). The BRAKE warning lamp will illuminate and will remain illuminated until the parking brake...
Page 153 A high crown in the road or high crosswinds may also make the steering seem to wander/pull. TRACTION-LOK AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface. Under normal conditions, the Traction-Lok axle functions like a standard rear axle.
Page 154 Driving shift rearward. As a result, the van has less resistance to rollover and handles differently from other commonly driven passenger vehicles, making it more difficult to control in an emergency situation. Placing any load on the roof also raises the center of gravity and increases the potential for rollover.
Page 155: Transmission Operation
• If the vehicle goes from one type of surface to another (i.e., from concrete to gravel) there will be a change in the way the vehicle responds to a maneuver (steering, acceleration or braking). Again, avoid these abrupt inputs. AUTOMATIC TRANSMISSION OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents...
Page 156 Driving Understanding the gearshift positions of the 4–speed automatic transmission This vehicle is equipped with an adaptive Transmission Shift Strategy. Adaptive Shift Strategy offers the optimal transmission operation and shift quality. When the vehicle’s battery has been disconnected for any type of service or repair, the transmission will need to relearn the normal shift strategy parameters, much like having to reset your radio stations when your vehicle battery has been disconnected.
Page 157 N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through four. Overdrive can be deactivated by pressing the transmission control switch on the end of the gearshift...
Page 158 Driving • Selecting 2 (Second) at higher speeds will cause the transmission to downshift to second gear at the appropriate vehicle speed. 1 (First) • Provides maximum engine braking. • Allows upshifts by moving gearshift lever. • Will not downshift into 1 (First) at high speeds; allows for 1 (First) when vehicle reaches slower speeds.
Page 159 To put your vehicle in P (Park): • Come to a complete stop • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle.
Page 160 Driving Tow/Haul delays upshifts to reduce frequency of transmission shifting. Tow/Haul also provides engine braking in all forward gears when the transmission is in the D (Overdrive) position; this engine braking will slow the vehicle and assist the driver in controlling the vehicle when descending a grade.
Page 161 Understanding the shift positions of the 5–speed automatic transmission (if equipped - diesel engines only) P (Park) This position locks the transmission and prevents the rear wheels from turning. To put your vehicle in gear: • Start the engine • Depress the brake pedal •...
Page 162 Driving D (Drive) without Overdrive D (Drive) without Overdrive can be activated by pressing the transmission control switch (TCS) on the end of the gearshift lever. • This position allows for all forward gears except overdrive. • The OFF lamp on the gearshift lever is illuminated.
Page 163 Forced downshifts • Allowed in D (Drive) with Overdrive or D (Drive) without Overdrive. • Depress the accelerator to the floor. • Allows transmission to select an appropriate gear. If your vehicle goes off the edge of the pavement • If your vehicle goes off the edge of the pavement, slow down, but avoid severe brake application, ease the vehicle back onto the pavement only after reducing your speed.
Page 164 For extended duration stationary PTO operation (beyond 10 minutes) diesel engine is recommended, and further consult your aftermarket PTO installer. A more complete description of PTO operation is discussed in the Ford Truck Body Builders Layout Book, found at www.fleet.ford.com/truckbbas.
Page 165: Roadside Emergencies
50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...
Page 166: Hazard Flasher Switch
1–800–665–2006. Motorhome customers in the U.S and Canada should contact 1–800–444–3311. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140.
Page 167 Except for commercial stripped chassis vehicles, this switch is located in the front passenger’s footwell, by the kick panel. On commercial stripped chassis vehicles, this switch is located on a bracket above the brake pedal. To reset the switch: 1. Turn the ignition OFF. 2.
Page 168: Passenger Compartment Fuse Panel
Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
Page 169 To remove a fuse use the fuse puller tool provided on the fuse panel cover. The fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus) Roadside Emergencies Passenger Compartment Fuse Panel Description 4–Wheel Anti–lock Brake System...
Page 170 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating — — — REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus) Passenger Compartment Fuse Panel Description Brake-shift interlock, Daytime Running Lamps (DRL) module Multi-function switch, Turn signals Radio capacitor(s), Ignition coil, Powertrain Control Module (PCM) diode, PCM power relay Wiper control module...
Page 171: Power Distribution Box
Fuse/Relay Fuse Amp Location Rating — — — — — — — 20A circuit breaker — 20A circuit breaker Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads.
Page 172 Roadside Emergencies Always disconnect the battery before servicing high current fuses. Always replace the cover to the power distribution box before reconnecting the battery or refilling fluid reservoirs. If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and Specifications chapter. The high-current fuses are coded as follows.
Page 173 Fuse/Relay Fuse Amp Location Rating 60A** 40A** 50A** 30A** 60A** 60A** 20A** 50A** 30A** — 50A** 60A** 50A** 60A** 30A** 60A** — 20A* — 20A* 10A* — — — REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus) Roadside Emergencies Power Distribution Box Description...
Page 174: Relay Modules
Roadside Emergencies Fuse/Relay Fuse Amp Location Rating — — — — — — — — * Mini fuses ** Maxi fuses Relay modules Instrument panel relay module The instrument panel relay module is located behind the radio in the center of the instrument panel. Have a certified technician or your dealer service this module, if required.
Page 175 Engine compartment relay module The engine compartment relay module is located in one of two places depending on which type of engine your vehicle is equipped with: • Gasoline engine: driver side of the engine compartment above the brake master cylinder. •...
Page 176: Jump Starting
Roadside Emergencies JUMP STARTING YOUR VEHICLE The following procedure is for vehicles equipped with a gasoline engine; if your vehicle is equipped with a diesel engine, refer to the 6.0L Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for the proper jump starting procedure.
Page 177 Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 178 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 179 Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected.
Page 180 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 181: Wrecker Towing
Ford recommends your vehicle be towed with a wheel lift or flatbed. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 182: Customer Assistance
Center at the number below. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 183 Away from home–motorhome service If you own a motorhome built on a Ford Chassis and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps above, contact the Ford Motorhome Customer Assistance Center to find an authorized dealership or service location to help you.
Page 184 THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes. • available free to owners and lessees of qualifying Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford...
Page 185 What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 186 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 187 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 188 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
Page 189 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 190: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 191: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 192 Cleaning • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area. The paint sealant will “gray” or stain the parts over time. •...
Page 193 ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 194 Cleaning WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, tree sap, or other organic contamination.
Page 195: Underbody Preservation
INTERIOR For fabric, carpets, cloth seats and safety belts: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Motorcraft Extra Strength Upholstery Cleaner (ZC-41). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 196 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 197: Maintenance And Specifications
Maintenance and Specifications Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 198 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located in the center top of the grill.
Page 199: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT Engine compartment component locations Refer to the 6.0 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for diesel engine component locations. 1. Windshield washer fluid reservoir 2. Engine oil filler cap 3.
Page 200: Engine Oil
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 201 Maintenance and Specifications 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable.
Page 202 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 203: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates and only for frame mounted deep cycle auxiliary batteries, check the battery electrolyte level.
Page 204 Maintenance and Specifications Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 205 Maintenance and Specifications 7. Drive the vehicle to complete the relearning process. • The vehicle may need to be driven 10 miles (16 km) or more to relearn the idle and fuel trim strategy. • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
Page 206 Maintenance and Specifications • Enables calibrated gauges to work properly. When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 207 • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (U.S., except CA and OR), VC-7–B (CA and OR only), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
Page 208 Maintenance and Specifications For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool. Add the proper mixture of coolant and water to the “FULL COLD” level. For all other vehicles which have a coolant degas system with a pressurized cap, or if it is necessary to remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant.
Page 209 Maintenance and Specifications Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
Page 210 Maintenance and Specifications • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate protection at the temperatures in which you drive. Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection.
Page 211: Fuel Information
Maintenance and Specifications operation and the engine will run rough. Remember that the engine is capable of completely shutting down automatically to prevent engine damage, therefore: 1. Pull off the road as soon as safely possible and turn off the engine. 2.
Page 212 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 213 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 214 Maintenance and Specifications Choosing the right fuel Use only UNLEADED FUEL. The use of leaded fuel is prohibited by law and could damage your vehicle. Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based additives. Studies indicate that these additives can cause your vehicle’s emission control system to deteriorate more rapidly.
Page 215 Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 216 Maintenance and Specifications Filling the tank The advertised fuel capacity of the fuel tank on your vehicle is equal to the rated refill capacity of the fuel tank as listed in the Refill capacities section of this chapter. The advertised capacity is the amount of the indicated capacity and the empty reserve combined.
Page 217 Maintenance and Specifications 5. Follow one of the simple calculations in order to determine fuel economy: Calculation 1: Divide total miles traveled by total gallons used. Calculation 2: Multiply liters used by 100, then divide by total kilometers traveled. Keep a record for at least one month and record the type of driving (city or highway).
Page 218 Maintenance and Specifications Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy. • Use recommended engine oil. Refer to Lubricant specifications in this chapter. •...
Page 219 Guide are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 220 Maintenance and Specifications Please consult your Warranty Guide for complete emission warranty information. On board diagnostics (OBD-II) Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD-II). This OBD-II system protects the environment by ensuring that your vehicle continues to meet government emission standards.
Page 221 Maintenance and Specifications Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature. Once started, do not turn off the engine until the above driving cycle is complete. CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid.
Page 222 Maintenance and Specifications 5. Recheck the fluid level on the dipstick. Do not add fluid if the level is between the arrows in the FULL COLD range. 6. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the FULL COLD range.
Page 223 Maintenance and Specifications 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.
Page 224 Maintenance and Specifications High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 225 Maintenance and Specifications Automatic transmission fluid filter (if equipped) The TorqShift automatic transmission is equipped with a serviceable external fluid filter mounted on the driver’s side of the transmission. Refer to the Scheduled Maintenance Guide for service intervals. To replace the transmission filter: 1.
Page 226: Air Filter(S)
Maintenance and Specifications AIR FILTER MAINTENANCE Refer to the scheduled maintenance guide for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Motorcraft air filter element listed. Refer to Motorcraft part numbers in this chapter. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 227: Part Numbers
Refer to the Scheduled Maintenance Guide for the appropriate intervals for changing the PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 228: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Name Brake fluid Motorcraft High Performance DOT 3 Motor Vehicle Brake Fluid Engine Motorcraft SAE oil-gasoline 5W-20 Premium engine (includes Synthetic Blend filter change) Motor Oil (US) Motorcraft SAE 5W-20 Super Premium Motor...
Page 229 Maintenance and Specifications Fluid Ford Part Name Engine Motorcraft coolant-gasoline Premium Gold engine Engine Coolant (yellow-colored) Engine Refer to the Power Stroke Direct Injection Turbo coolant-diesel Diesel Owner’s Guide Supplement. engine Power steering Motorcraft fluid MERCON ATF REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002),...
Page 230 Maintenance and Specifications Fluid Ford Part Name Rear axle SAE 75W-140 Synthetic Rear Axle Lubricant SAE 75W-140 Synthetic Rear Axle Lubricant SAE 90 Hypoid Gear Oil (axles shown are all limited slip) SAE 80W-90 Premium Rear Axle Lubricant REVIEW COPY...
Page 231 Maintenance and Specifications Fluid Ford Part Name Fuel tank Transmission Motorcraft fluid MERCON V Motorcraft MERCON SP Windshield Motorcraft washer fluid Premium Windshield Washer Concentrate Add the coolant type originally equipped in your vehicle. If your vehicle’s rear axle is filled with a synthetic rear axle lubricant it is considered lubricated for life.
Page 232 Fill 1/4 inch to 9/16 inch (6 mm to 14 mm) below bottom of fill hole. Add 4 oz. (118 ml) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118–A, for complete refill of 8.8 inch and 9.75 inch Traction-Lok axles.
Page 233: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Item Ford part name Brake fluid Motorcraft High Performance DOT 3 Motor Vehicle Brake Fluid Door Silicone weatherstrips Lubricant Engine coolant Motorcraft Premium Gold Engine Coolant (yellow-colored) Engine Motorcraft SAE oil-gasoline 5W-20 Premium engine Synthetic Blend...
Page 234 Maintenance and Specifications Item Ford part name Automatic Motorcraft transmission MERCON V (4R70/75 E) Automatic Motorcraft transmission MERCON SP TorqShift (5–speed) Disc brake Motorcraft caliper rails Silicone Brake Caliper Grease and Dielectric Compound Parking brake Motorcraft assembly MERCON (E-450 Super...
Page 235 Maintenance and Specifications Item Ford part name Dana Limited SAE 90 Hypoid Slip Axles Gear Oil M60 (M248) E-250/350 M70FF (M267FF) E-350 M70HD (M273HD) E-450 Dana SAE 80W-90 conventional Premium Rear axles Axle Lubricant M60 (M248) E-250/350 M70FF (M267FF) E-350...
Page 236 Add 4 oz. (118 ml) of Additive Friction Modifier XL-3 or equivalent for complete refill of Visteon Traction-Lok rear axles. Add 8 oz. (237 ml) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118-A for complete refill of Dana Limited Slip rear axles. ENGINE DATA 4.6L V8...
Page 237 Maintenance and Specifications VEHICLE DIMENSIONS Van/wagon models E-150 – Inches (mm) (1) Overall height 80.7 (2050) (2) Track front/rear 69.4 (1763)/ 67.2(1707) (3) Overall width (excluding mirrors) (4) Wheelbase (5) Overall length Regular van: 211.8. (5381) REVIEW COPY 2005 Econoline (eco), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus) E-250 –...
Page 238 Maintenance and Specifications Cutaway/commercial stripped chassis models E-350 – inches (mm) E-Super Duty – (1) Overall height Refer to Body Builder for specifications. (2) Track front/rear Cutaway: 69.4 (1763) SRW: 72.1 (1831) DRW: 73.2 (1859) Stripped Chassis: 69.4 (1763) SRW: 66.4 (1687) DRW: 73.2 (1859) (3) Overall width Refer to Body Builder for specifications.
Page 239 Maintenance and Specifications VEHICLE IDENTIFICATION NUMBER Complete Ford built vehicles The vehicle identification number is attached to your vehicle in the following places: • On the metal tag attached to the top of the instrument panel on the driver’s side.
Page 240: Accessories
In addition, each accessory is made from high quality materials and meets or exceeds Ford’s rigorous engineering and safety specifications. Ford Motor Company will repair or...
Page 241 Splash guards Step bars Tonneau covers Wheels Interior style Consoles Electrochromatic compass/temperature interior mirrors Floor mats Leather wrapped steering wheels Scuff plates Speed control Lifestyle Bedliners and bedmats Bed tents Bike racks Cargo organization and management Diamond plate accessories Rear seat entertainment systems Mobile-ease hands-free communication system Toolboxes Towing mirrors...
Page 242 Amateur Radio Antennas in the area of the driver’s side hood. • Electrical or electronic accessories or components that are non-Genuine Ford Accessories added to the vehicle by the dealer or the owner may adversely affect battery performance and durability. REVIEW COPY...
Page 243: Index
Index Accessory delay ...57 Air bag supplemental restraint system ...83 and child safety seats ...85 description ...83 disposal ...87 driver air bag ...85 indicator light ...87 operation ...85 passenger air bag ...85 Air cleaner filter ...226–227 Ambulance packages ...8 Antifreeze (see Engine coolant) ...205 Anti-lock brake system (see Brakes) ...151...
Page 244 ...205 refill capacities ...209, 228 specifications ...233, 236 Cruise control (see Speed control) ...59 Customer Assistance ...165 Ford accessories for your vehicle ...196 Ford Extended Service Plan ...188 Getting assistance outside the U.S. and Canada ...188 Getting roadside assistance ...165 Getting the service you need ...182...
Page 245 refill capacities ...228 specifications ...233, 236 Exhaust fumes ...150 Fail safe cooling ...210 Fluid capacities ...228 Four-Wheel Drive vehicles preparing to drive your vehicle ...153 Fuel ...211 calculating fuel economy ...215 cap ...213 capacity ...228 choosing the right fuel ...214 comparisons with EPA fuel economy estimates ...218 detergent in fuel ...215...
Page 246 Index headlamps, flash to pass ...43 instrument panel, dimming ...43 interior lamps ...46 replacing bulbs ...47–51 Lane change indicator (see Turn signal) ...46 Lights, warning and indicator ...12 anti-lock brakes (ABS) ...151 Load limits ...129 Loading instructions ...134 Lubricant specifications ...233, 236 Lug nuts ...119 Lumbar support, seats ...68 Mirrors...
Page 247 AM/FM/CD ...23 AM/FM/In-dash 6 CD ...27, 30, 34 AM/FM/Tape ...20 Spare tire (see Changing the Tire) ...112 Spark plugs, specifications ...227, 236–237 Special notice ...9 ambulance conversions ...8 diesel-powered vehicles ...7 utility-type vehicles ...7 Specification chart, lubricants ...233, 236 Speed control ...59 Starting your vehicle ...147–148, 150 jump starting ...176...

This manual is also suitable for:

2005 econoline

Ford 2005 E-150 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Table of Contents

Related Manuals for Ford 2005 E-150

Summary of Contents for Ford 2005 E-150

This manual is also suitable for:

Table of Contents
