Ford Mondeo Owner's Manual page 198

Fuse Ampere rating
F2 5
F3
70
F3
80
F4 60
F5 60
F5 70
F6 7.5
F6 10
F6 20
F7 5
F8 10
F8 20
F8 15
F9 10
F9 5
F9 7.5
Fuses
Vaporiser glow plug monitoring (2.0L Duratorq-TDCi
Stage V and 2.2L Duratorq-TDCi Stage V)
Engine cooling fan - twin fan (2.3L Duratec-HE and
1
2.2L Duratorq-TDCi automatic)
Electric hydraulic power steering (EHPAS) (1.6L
1
Duratec-16V Ti-VCT Stage V, 1.6L EcoBoost SCTi and
2.0L Duratorq-TDCi)
Glow plugs
Engine cooling fan (1.6L Duratorq-TDCi, 2.0L Duratorq-
TDCi, 2.0L Duratorq-TDCi Stage V, 2.2L Duratorq-TDCi
manual, 1.6L Duratec-16V Ti-VCT Stage V, 2.0L
Duratec-HE, 2.3L Duratec-HE, 2.0L EcoBoost SCTi)
Engine cooling fan - twin fan (1.6L EcoBoost SCTi)
HEGO sensor (1.6L Duratorq-TDCi)
HEGO sensors 1, CMS sensor, Oxygen sensor (engine
management)
Vaporiser glow plug (2.0L Duratorq-TDCi Stage V, 2.2L
Duratorq-TDCi Stage V)
Relay coils
Powertrain control module, Fuel metering unit, MAF
sensor, fuel rail pressure control valve (engine
management).
Powertrain control module (2.0L EcoBoost SCTi and
2.0L Duratorq-TDCi Stage V)
Powertrain control module (1.6L EcoBoost SCTi, 1.6L
Duratorq-TDCi and 2.2L Duratorq-TDCi Stage V)
MAF Sensor, Fuel Injectors, Variable Intake Valve,
Variable Exhaust Valve, ignition coils (engine
management).
Fuel pump vaporiser (2.0L Duratorq-TDCi Stage V)
MAF Sensor, EGR bypass Valve , Fuel pump vaporiser
(2.2L Duratorq-TDCi Stage V) (engine management)
196
Circuits protected
