Page 1 R a m T r u c k 2 0 1 2 O W N E R ’ S M A N U A L C H A S S I S C A B...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of features Chrysler Group LLC shall be deemed to be deleted and the and equipment that are either standard or optional on this name Chrysler Canada Inc.
Page 3: Introduction
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 5: Table Of Contents
INTRODUCTION CONTENTS Introduction ......4 Van Conversions/Campers ....6 How To Use This Manual .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
Page 7 INTRODUCTION 5...
Page 8: Van Conversions/Campers
6 INTRODUCTION WARNINGS AND CAUTIONS also be supplied with your vehicle. If these instructions This Owner’s Manual contains WARNINGS against op- are missing, please contact your authorized dealer for erating procedures that could result in a collision or assistance in obtaining replacement documents from the bodily injury.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a accident resulting in serious injury or death. Vehicle Identification Number NOTE: It is illegal to remove or alter the VIN.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 General Information ....18 Wireless Ignition Node (WIN) —...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Lock The Doors ....23 Wind Buffeting ..... . . 39 Using The Panic Alarm .
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 Driver And Right Front Passenger Engine Break-In Recommendations ..78 Supplemental Restraint System (SRS) — Safety Tips ......78 Air Bag .
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS authorized dealer. Ask your authorized dealer for these numbers and keep them in a safe place. You can insert the Key Fob with Remote Keyless Entry (RKE) — double-sided standard blade key into the ignition switch If Equipped with either side up.
Page 15: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. Insert the square end of the key fob into the ignition switch located on the instrument panel and rotate to the desired posi- tion.
Page 16: Removing Key Fob From Ignition
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch Removing Key Fob From Ignition at the top of the Key Fob sideways with your thumb and Place the shift lever in PARK (if equipped with an then pull the key out with your other hand.
Page 17 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 (EVIC)/Personal Settings (Customer-Programmable WARNING! Features)” in “Understanding Your Instrument Panel” • Never leave children alone in a vehicle. Leaving for further information. unattended children in a vehicle is dangerous for a CAUTION! number of reasons.
Page 18: Key-In-Ignition Reminder
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key-In-Ignition Reminder Node (WIN) to prevent unauthorized vehicle operation. Opening the driver’s door when the Key Fob is in the Therefore, only Key Fobs that are programmed to the ignition and the ignition switch position is OFF or ACC, vehicle can be used to start and operate the vehicle.
Page 19: Replacement Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 If the Vehicle Security Light turns on during normal vehicle. Once a Key Fob is programmed to a vehicle, it vehicle operation (vehicle running for longer than 10 sec- cannot be programmed to any other vehicle. onds), it indicates that there is a fault in the electronics.
Page 20: Customer Key Programming
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • This device must accept any interference that may be NOTE: • When having the Sentry Key Immobilizer System received, including interference that may cause unde- serviced, bring all vehicle keys with you to an autho- sired operation.
Page 21: To Arm The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 condition which initiated the alarm is still present, the The Vehicle Security Alarm will also disarm if a pro- system will ignore that condition and monitor the re- grammed Sentry Key is inserted into the ignition maining doors and ignition.
Page 22: Illuminated Entry - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The illuminated entry system will not operate if the ILLUMINATED ENTRY — IF EQUIPPED The courtesy lights will turn on when you use the dimmer control is in the “dome defeat” position Remote Keyless Entry (RKE) transmitter to unlock the (extreme bottom position).
Page 23: Remote Unlock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 seconds to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on. Remote Key Unlock, Driver Door/All Doors First This feature lets you program the system to unlock either the driver’s door or all doors on the first press of the UNLOCK button on the RKE transmitter.
Page 24 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE than ten seconds. Then, press and hold the UNLOCK Flash Lamps With Remote Key Lock button while still holding the LOCK button. This feature will cause the turn signal lights to flash when the doors are locked or unlocked with the RKE transmit- 2.
Page 25: To Lock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 3. Test the feature while outside of the vehicle by press- Sound Horn With Remote Key Lock ing the LOCK/UNLOCK buttons on the RKE transmitter This feature will cause the horn to chirp when the doors with the ignition switch in the OFF position and the key are locked with the RKE transmitter.
Page 26: Using The Panic Alarm
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Test the feature while outside of the vehicle by press- The Panic Alarm will stay on for three minutes unless ing the LOCK button on the RKE transmitter with the you turn it off by either pressing the PANIC button a ignition switch in the OFF position and the key removed.
Page 27: Transmitter Battery Replacement
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 Transmitter Battery Replacement 3. To assemble the RKE transmitter case, snap the two The recommended replacement battery is one CR2032 halves together. battery. General Information NOTE: This device complies with Part 15 of the FCC rules and •...
Page 28: Remote Starting System - If Equipped
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If your RKE transmitter fails to operate from a normal How To Use Remote Start distance, check for these two conditions: All of the following conditions must be met before the engine will remote start: 1.
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 • Remote Start Aborted — Hood Ajar WARNING! • Remote Start Aborted — Fuel Low • Do not start or run an engine in a closed garage or • Remote Start Aborted — System Fault confined area.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If an engine fault is present or fuel level is low, the NOTE: To avoid unintentional shut downs, the system vehicle will start and then shut down in 10 seconds. will disable the one time press of the REMOTE START button for two seconds after receiving a valid Remote •...
Page 31: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 • For vehicles equipped with the Electronic Vehicle The Remote Start Comfort System can be activated and Information Center (EVIC), the message “Insert Key/ deactivated through the Electronic Vehicle Information Turn To On” will flash in the EVIC until you insert the Center (EVIC).
Page 32: Power Door Locks - If Equipped
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors when you drive as well as when you park and leave the vehicle. • Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.
Page 33: Automatic Door Locks Programmin
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 operate. A chime will sound if the Key Fob is in the Automatic Door Locks Programming — If ignition switch and a door is open, as a reminder to Equipped remove the Key Fob. The Automatic Door Locks feature can be enabled or disabled as follows: Automatic Door Locks —...
Page 34: Auto Unlock Doors
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Within 15 seconds, cycle the ignition switch between Auto Unlock Doors — If Equipped OFF and ON/RUN and then back to OFF position a This feature unlocks all of the doors of the vehicle when minimum of five times ending up in the ON/RUN either front door is opened.
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 2. Fasten your seat belt. (Fastening the seat belt will 6. A single chime will sound to indicate the feature has cancel any chimes that may be confusing during this been changed. programming procedure.) 7.
Page 36: Child-Protection Door Lock
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child-Protection Door Lock To use the system, open each rear door, use a flat blade To provide a safer environment for children riding in the screwdriver (or emergency key) and rotate the dial to rear seat, the rear doors (if equipped) of your vehicle engage and disengage the Child-Protection locks.
Page 37: Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WINDOWS WARNING! Power Windows – If Equipped Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the Child-Protection locks are engaged.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The control on the left front door panel has UP-DOWN WARNING! switches that give you fingertip control of all power windows. There is a single opening and closing switch on Never leave children alone in a vehicle. Leaving the front passenger door for passenger window control unattended children in a vehicle is dangerous for a and on the rear doors of the Crew Cab models.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 To stop the window from going all the way down during again to close the window. Any impact due to rough road the Auto-Down operation, pull up on the switch briefly. conditions may trigger the auto reverse function unex- pectedly during auto closure.
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Push the window switch down firmly to the second detent to open the window completely and continue to hold the switch down for an additional two seconds after the window is fully open. Window LOCKOUT Switch (4–Door Models Only) The window LOCKOUT switch on the driver’s door allows you to disable the window control on the rear...
Page 41: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 • Knee bolsters/blockers for front seat occupants Wind Buffeting Wind buffeting can be described as the perception of • All seat belt systems (except driver’s regular/Crew pressure on the ears or a helicopter-type sound in the Cab , first and second row center position for Crew ears.
Page 42: Lap/Shoulder Belts
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Please pay close attention to the information in this Research has shown that seat belts save lives, and they section. It tells you how to use your restraint system can reduce the seriousness of injuries in an accident. properly, to keep you and your passengers as safe as Some of the worst injuries happen when people are possible.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 WARNING! WARNING! (Continued) • Wearing a seat belt incorrectly is dangerous. Seat • It is dangerous to ride in a cargo area, inside or belts are designed to go around the large bones of outside of a vehicle.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch plate and pull out the belt.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 3. When the belt is long enough to fit, insert the latch WARNING! plate into the buckle until you hear a “click.” • A belt buckled into the wrong buckle will not protect you properly.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your WARNING! (Continued) abdomen. To remove slack in the lap belt portion, pull up • A belt that is worn under your arm is dangerous. on the shoulder belt.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed position. • A lap belt worn too high can increase the risk of If necessary, slide the latch plate down the webbing to allow the belt to retract fully.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Regular Cab Front Center Three Point Belt 1. The front center seat belt on the Regular Cab may be disconnected to open up utilization of the storage areas behind the front seats. The black latch plate can be detached from the black keyed seat belt buckle located on the inboard side of the passenger seat.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 WARNING! • If the black latch and black buckle are not prop- erly connected when the seat belt is used by an occupant, the seat belt will not be able to provide proper restraint and will increase the risk of injury in an accident.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • If the black latch and black buckle are not prop- erly connected when the seat belt is used by an occupant, the seat belt will not be able to provide proper restraint and will increase the risk of injury in an accident.
Page 51: Adjustable Upper Shoulder Belt Anchorage
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Adjustable Upper Shoulder Belt Anchorage As a guide, if you are shorter than average you will In the front row outboard seats, the shoulder belt can be prefer a lower position, and if you are taller than average adjusted upward or downward to help position the belt you will prefer a higher position.
Page 52: Seat Belts In Passenger Seating Positions
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Regular Cab WARNING! Left Center Right • A lap belt worn too loose or too high is dangerous. First Row • A belt worn too loose can allow you to slip down •...
Page 53: Automatic Locking Retractor Mode (Alr) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 activate the ALR. If the ALR is activated you will hear a 2. Grasp the shoulder portion and pull downward until ratcheting sound as the belt retracts. Allow the webbing the entire belt is extracted. to retract completely in this case and then carefully pull 3.
Page 54: Enhanced Seat Belt Use Reminder System (Beltalert )
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Seat Belt Use Reminder System (8 km/h), BeltAlert will chime once and illuminate the (BeltAlert ) Seat Belt Reminder Light, then will proceed to the BeltAlert is a feature intended to remind the driver to 96 second warning sequence.
Page 55: Seat Belts And Pregnant Women
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 2. Turn the ignition switch to the ON/RUN position (do Seat Belts And Pregnant Women not start the engine), and wait for the Seat Belt Reminder We recommend that pregnant women use seat belts Light to turn off.
Page 56: Driver And Right Front Passenger Supplemental Restraint System (Srs) - Air Bag
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Using a seat belt extender when not needed can increase the risk of injury in an accident. Only use the seat belt extender when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 57: Air Bag System Components
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 The Advanced Front Air Bags have a multistage inflator Air Bag System Components design. This allows the air bag to have different rates of Your vehicle may be equipped with the following air bag inflation based on the severity and type of collision.
Page 58: Advanced Front Air Bag Features
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Advanced Front Air Bag Features WARNING! (Continued) The Advanced Front Air Bag system has multistage • Do not put anything on or around the air bag driver and front passenger (if equipped) air bags. This covers or attempt to open them manually.
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 Here are some simple steps you can take to minimize the ride properly buckled up in the rear seat. Never allow risk of harm from a deploying air bag: children to slide the shoulder belt behind them or under their arm.
Page 60: Air Bag Deployment Sensors And Controls
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the air bag system in this vehicle needs to be modified Air Bag Deployment Sensors And Controls to accommodate a disabled person, contact the Customer Occupant Restraint Controller (ORC) Center. Phone numbers are provided under If You Need The ORC is part of a Federally regulated safety system Assistance .
Page 61 — for example, some pole colli- The ORC contains a backup power supply system that sions, truck underrides, and angle offset collisions. On may deploy the air bags even if the battery loses power or the other hand, depending on the type and location of it becomes disconnected prior to deployment.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the Advanced Front Air Bags, it signals the inflator units. WARNING! A large quantity of non-toxic gas is generated to inflate the Advanced Front Air Bags. Different air bag inflation Ignoring the Air Bag Warning Light in your instru- rates are possible, based on the collision type and sever- ment panel could mean you won’t have the air bags ity.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Enhanced Accident Response System NOTE: Front air bags will not deploy in all collisions. In the event of an impact causing air bag deployment, if This does not mean something is wrong with the air bag the communication network remains intact, and the system.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE bag inflation. These airborne particles may irritate the Maintaining Your Air Bag System skin, eyes, nose, or throat. If you have skin or eye WARNING! irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air.
Page 65: Air Bag Warning Light
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Air Bag Warning Light WARNING! (Continued) You will want to have the air bags ready to • Do not attempt to modify any part of your air bag inflate for your protection in a collision. The system.
Page 66: Event Data Recorder (Edr)
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Whether or not the driver and passenger safety belts NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint were buckled/fastened; Controller (ORC) may also be disabled. The air bags may •...
Page 67: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 To read data recorded by an EDR, special equipment is WARNING! required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, In a collision, an unrestrained child, even a tiny baby, such as law enforcement, that have the special equip- can become a projectile inside the vehicle.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE of child restraints can be used rearward-facing: infant children who weigh 20 to 40 lbs (9 to 18 kg) and who carriers and convertible child seats. Both types of are older than one year. These child seats are also held child restraints are held in the vehicle by the lap/ in the vehicle by the lap/shoulder belt.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 you make sure that you can install the child restraint in WARNING! the vehicle where you will use it before you buy it. • Rearward-facing child seats must never be used in •...
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the latch plate from the buckle, turn the latch plate Children Too Large For Booster Seats around, and insert the latch plate into the buckle Children who are large enough to wear the shoulder belt again.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Lower Anchors and Tether for CHildren (LATCH) Each vehicle is equipped with the child restraint anchor- age system called LATCH, which stands for Lower Anchors and Tether for CHildren. The LATCH system provides for the installation of the child restraint without using the vehicle seat belt, instead securing the child restraint using lower anchorages and upper tether straps...
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child restraint systems having attachments designed to NOTE: • When using the LATCH attaching system to install a connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection child restraint, please ensure that all seat belts not to the seat back tether anchorage have been available for being used for occupant restraints are stowed and out...
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Installing The Child Restraint System We urge you to carefully follow the directions of the manufacturer when installing your child restraint. Many, WARNING! but not all, restraint systems will be equipped with separate straps on each side, with each having a hook or Do not install child restraint systems equipped with connector, and a means for adjusting the tension in the...
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The chart below defines the seating positions with an WARNING! Automatic Locking Retractor (ALR) or a cinching latch Improper installation of a child restraint to the plate. LATCH anchorages can lead to failure of an infant or Regular Cab child restraint.
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Installing a Child Restraint with an ALR: Installing a Child Restraint with a Cinching Latch Plate: 1. To install a child restraint with ALR, first, pull enough 1. To install a child restraint with a cinching latch plate, of the seat belt webbing from the retractor to route it first, pull enough of the seat belt webbing from the through the belt path of the child restraint.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Restraint Tether Anchor WARNING! Child restraints having tether straps and hooks for con- nection to tether anchors have been available for some An incorrectly anchored tether strap could lead to time. In fact, many child restraint manufacturers will seat failure and injury to the child.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Tether Anchorage Points at the Right and Center Front Seat (Regular Cab - All Seats) 1. Place the child restraint on the seat and adjust the tether strap so that it will reach over the seat back under the head restraint to the tether anchor directly behind the seat.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Multiple Child Restraint Installation Sequence (Crew Cab — Rear Seats) Crew Cab 1. The tether straps loops are located between the rear glass and the rear seat. There is a tether strap loop located behind each seating position.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 3. Pass each tether strap hook under the head restraint and through the loop of webbing behind the child seat. 4. Route each tether strap to the anchor behind the center seat, and attach the hooks to the anchor loop. 5.
Page 80: Engine Break-In Recommendations
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transporting Pets The engine oil installed in the engine at the factory is a Air Bags deploying in the front seat could harm your pet. high-quality energy conserving type lubricant. Oil An unrestrained pet will be thrown about and possibly changes should be consistent with anticipated climate injured, or injure a passenger during panic braking or in conditions under which vehicle operations will occur.
Page 81: Exhaust Gas
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Exhaust Gas WARNING! • Do not leave children or animals inside parked WARNING! vehicles in hot weather. Interior heat build-up may Exhaust gases can injure or kill. They contain carbon cause serious injury or death. monoxide (CO), which is colorless and odorless.
Page 82: Safety Checks You Should Make Inside The Vehicle
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Whenever a change is noticed in the sound of the exhaust Front seat belt assemblies must be replaced after a system, when exhaust fumes can be detected inside the collision. Rear seat belt assemblies must be replaced after vehicle, or when the underside or rear of the vehicle is a collision if they have been damaged (i.e., bent retractor, damaged, have a competent mechanic inspect the com-...
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 Floor Mat Safety Information WARNING! (Continued) Always use floor mats designed to fit the footwell of your • Never place or install floor mats or other floor vehicle. Use only floor mats that leave the pedal area coverings in the vehicle that cannot be properly unobstructed and that are firmly secured so that they secured to prevent them from moving and inter-...
Page 84: Periodic Safety Checks You Should Make Outside The Vehicle
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE lodged in the tread or sidewall. Inspect the tread for cuts WARNING! (Continued) and cracks. Inspect sidewalls for cuts, cracks and bulges. • Always make sure that objects cannot fall into the Check the wheel nuts for tightness.
Page 85: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......87 “Slide-On-Rod” Features Of Sun Visor — If Equipped .
Page 86 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information ....124 Head Restraints ..... 139 Voice Command —...
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 Headlights On With Wipers (Available With Intermittent Wiper System ....155 Automatic Headlights Only) ... . 149 Windshield Washers .
Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overhead Console — If Equipped ..163 Door Storage ..... . . 175 Courtesy/Reading Lights .
Page 89: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. The mirror should be adjusted while set in the day position (toward the windshield).
Page 90: Outside Mirrors
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE to the left of the button will illuminate to indicate when CAUTION! the dimming feature is activated. The sensor to the right of the button does not illuminate. To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror.
Page 91: Outside Mirrors Folding Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 WARNING! Vehicles and other objects seen in a passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object.
Page 92: Power Mirrors - If Equipped
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors — If Equipped The controls for the power mirrors are located on the driver’s door trim panel. Power Mirror Controls 1 — Mirror Select Buttons 2 — Mirror Control Power Mirror Controls To adjust a mirror, press the mirror select button for the The power mirror controls consist of mirror select but- mirror that you want to adjust.
Page 93: Heated Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 Illuminated Vanity Mirror — If Equipped Illuminated vanity mirrors are located on each sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights will turn on auto- matically.
Page 94: Slide-On-Rod" Features Of Sun Visor - If Equipped
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE “Slide-On-Rod” Features Of Sun Visor — If Equipped The sun visor “Slide-On-Rod” feature allows for addi- tional flexibility in positioning the visor to block out the sun. To use the “Slide-On-Rod” feature, rotate the sun visor downward and unclip it.
Page 95: Uconnect™ Phone - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 Trailer Towing Position Blindspot Mirror NOTE: Fold the trailer towing mirrors rearward prior to Uconnect™ Phone — IF EQUIPPED entering an automated car wash. Uconnect™ Phone is a voice-activated, hands-free, in- vehicle communications system. Uconnect™ Phone al- A small blindspot mirror is located next to main mirror lows you to dial a phone number with your mobile and can be adjusted separately.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE mobile phone’s audio is transmitted through your vehi- Uconnect™ Phone allows you to transfer calls between cle’s audio system; the system will automatically mute the system and your mobile phone as you enter or exit your radio when using the Uconnect™...
Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Voice Command Button WARNING! Actual button location may vary with the ra- dio. The individual buttons are described in the Any voice commanded system should be used only “Operation” section. in safe driving conditions following local laws and phone use.
Page 98: Operation
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Operation example, you can use the compound form voice Voice commands can be used to operate the Uconnect™ command “Phonebook New Entry”, or you can break Phone and to navigate through the Uconnect™ Phone the compound form command into two voice com- menu structure.
Page 99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 • When prompted, after the beep, say “Pair a Device” Cancel Command At any prompt, after the beep, you can say “Cancel” and and follow the audible prompts. you will be returned to the main menu. However, in a •...
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone will confirm the phone number phone to use if multiple mobile phones are in the vehicle at the same time. For example, if priority three and then dial. The number will appear in the display and priority five phones are present in the vehicle, the of certain radios.
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 • The Uconnect™ system will confirm the name and • When prompted, enter the number designation (e.g., then dial the corresponding phone number, which “Home”, “Work”, “Mobile”, or “Other”). This will may appear in the display of certain radios. allow you to store multiple numbers for each phone- book entry, if desired.
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Depending on the maximum number of entries down- Phonebook Download – Automatic Phonebook Transfer From Mobile Phone loaded, there may be a short delay before the latest If equipped and specifically supported by your phone, downloaded names can be used.
Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 Edit Uconnect™ Phonebook Entries After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in NOTE: the phonebook, call the number you just edited, or return •...
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After you enter the Phonebook Delete menu, you will Delete/Erase “All” Uconnect™ Phonebook Entries then be asked for the name of the entry that you wish • Press the button to begin. to delete.
Page 105: Phone Call Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 List All Names In The Uconnect™ Phonebook Phone Call Features The following features can be accessed through the • Press the button to begin. Uconnect™ Phone if the feature(s) are available on your •...
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer Or Reject An Incoming Call — Call in progress. To go back to the first call, refer to “Toggling Currently In Progress Between Calls” in this section. To combine two calls, refer If a call is currently in progress and you have another to “Conference Call”...
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Conference Call Call Termination When two calls are in progress (one active and one on To end a call in progress, momentarily press the hold), press and hold the button until you hear a button.
Page 108: Uconnect™ Phone Features
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Continuation Uconnect™ Phone Features Call continuation is the progression of a phone call on the Language Selection Uconnect™ Phone after the vehicle ignition key has been To change the language that the Uconnect™ Phone is switched to OFF.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Emergency Assistance Canada and 060 for Mexico). The number dialed may If you are in an emergency and the mobile phone is not be applicable with the available mobile service and reachable: area. •...
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Towing Assistance Paging If you need towing assistance: To learn how to page, refer to “Working with Automated Systems”. Paging works properly except for pagers of • Press the button to begin. certain companies, which time out a little too soon to •...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 When calling a number with your Uconnect™ Phone that The Uconnect™ Phone will then send the corresponding normally requires you to enter in a touch-tone sequence phone number associated with the phonebook entry, as on your mobile phone keypad, you can press the tones over the phone.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts ON/OFF Dialing Using The Mobile Phone Keypad Turning confirmation prompts off will stop the system You can dial a phone number with your mobile phone from confirming your choices (e.g., the Uconnect™ keypad and still use the Uconnect™...
Page 113: Advanced Phone Connectivity
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Mute/Un-Mute (Mute OFF) from your Uconnect™ Phone paired mobile phone to the When you mute the Uconnect™ Phone, you will still be Uconnect™ Phone or vice versa, press the button able to hear the conversation coming from the other and say “Transfer Call”.
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, say “List Phones”. • The selected phone will be used for the next phone call. If the selected phone is not available, the • The Uconnect™ Phone will play the phone names of Uconnect™...
Page 115: Things You Should Know About Your Uconnect™ Phone
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Things You Should Know About Your Uconnect™ You can either press the Uconnect™ Phone button to Phone restore the factory setting or repeat the words and phrases when prompted by the Uconnect™ Phone. For Uconnect™...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • fully closed windows, Voice Command • For best performance, adjust the rearview mirror to • dry weather condition. provide at least ⁄ in (1 cm) gap between the overhead • Even though the system is designed for users speaking console (if equipped) and the mirror.
Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 • Numbers must be spoken in single digits. “800” must • fully closed windows, be spoken “eight-zero-zero” not “eight hundred”. • dry weather conditions, and • You can say “O” (letter “O”) for “0” (zero). •...
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Send Messages: Uconnect™ Phone can read or send new messages on You can send messages using Uconnect™ Phone. To send your phone. a new message: • Press the Read Messages: button. If you receive a new text message while your phone is •...
Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 List of Preset Messages: 11. See You in 15 minutes 1. Yes 12. I am on my way 2. No 13. I’ll be late 3. Where are you? 14. Are you there yet? 4.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn SMS Incoming Announcement ON/OFF Bluetooth Communication Link Turning the SMS Incoming Announcement OFF will stop Mobile phones have been found to lose connection to the the system from announcing the new incoming mes- Uconnect™...
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119...
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121...
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...
Page 126: Understanding The Features Of Your Vehicle General Information
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...
Page 127: Commands
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 If you ever wish to interrupt the system while it lists The system will best recognize your speech if the win- options, press the Voice Command button, listen dows are closed, and the heater/air conditioning fan is set to low.
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Say a command (e.g., “Help”). Radio AM To switch to the AM band, say “AM” or “Radio AM”. In 3. Use the ON/OFF VOLUME rotary knob to adjust the this mode, you may say the following commands: volume to a comfortable level while the Voice Command •...
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 • “Menu Radio” (to switch to the radio menu) Disc To switch to the disc mode, say “Disc”. In this mode, you • “Main Menu” (to switch to the main menu) may say the following commands: Satellite Radio •...
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Switch to system setup” − “Continue” (to continue recording) • “Change to setup” − “Delete” (to delete the recording) • “Play Memos” (to play previously recorded memos) • “Main menu setup” or —...
Page 131: Voice Training
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 Voice Training SEATS For users experiencing difficulty with the system recog- Seats are a part of the Occupant Restraint System of the nizing their voice commands or numbers the Uconnect™ vehicle. Voice “Voice Training” feature may be used. WARNING! 1.
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE There are two power seat switches that are used to Adjusting The Seat Forward Or Rearward control the movement of the seat cushion and the seat- The seat can be adjusted both forward and rearward. back.
Page 133: Passenger's Power Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Reclining The Seatback WARNING! (Continued) The angle of the seatback can be adjusted forward or • Do not ride with the seatback reclined so that the rearward. Push the seatback switch forward or rearward, shoulder belt is no longer resting against your the seat will move in the direction of the switch.
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjusting The Seat Forward Or Rearward WARNING! The seat can be adjusted both forward and rearward. • Adjusting a seat while driving may be dangerous. Push the seat switch forward or rearward, the seat will move in the direction of the switch.
Page 135: Power Lumbar - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 CAUTION! Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE controls for each seat are located near the bottom center WARNING! of the instrument panel (below the climate controls). • Persons who are unable to feel pain to the skin You can choose from HIGH, LOW or OFF heat settings. because of advanced age, chronic illness, diabetes, Amber indicator lights in each switch indicate the level of spinal cord injury, medication, alcohol use, ex-...
Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 The heated seats switch from HIGH to LOW and from Rear Heated Seats LOW to OFF automatically, based on time and tempera- On some models, the two outboard seats are equipped ture of the seat. The heated seats can operate on HIGH with heated seats.
Page 138: Ventilated Seats - If Equipped
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: small fans that draw the air from the passenger compart- • Once a heat setting is selected, heat will be felt within ment and blow air through fine perforations in the seat two to five minutes.
Page 139: Manual Seat Adjuster - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Vehicles Equipped With Remote Start On models equipped with remote start, the drivers ventilated seat can be programmed to come on during a remote start. Refer to “Remote Starting System — If Equipped” in “Things to Know Before Starting Your Vehicle”...
Page 140: Manual Reclining Seats - If Equipped
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust any seat only while the vehicle is parked.
Page 141: Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 WARNING! WARNING! (Continued) • You can be seriously, even fatally, injured riding in • Actuating the recliner handle will allow the seat- a seat with the seatback reclined. Do not ride with back to swing (dump) forward on manual recliner the seatback reclined so that the shoulder belt is seats.
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! The head restraints for all occupants must be prop- erly adjusted prior to operating the vehicle or occu- pying a seat. Head restraints should never be ad- justed while the vehicle is in motion. Driving a vehicle with the head restraints improperly adjusted or removed could cause serious injury or death in the event of a collision.
Page 143: 40-20-40 Front Bench Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 The back of the center portion (20%) easily folds down to provide an armrest/center storage compartment (if equipped). DRIVER MEMORY SEAT — IF EQUIPPED The memory seat buttons are located on the outboard side of the drivers seat cushion.
Page 144: Setting Memory Positions And Linking Rke Transmitter To Memory
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The memory buttons 1 and 2 can be programmed to Setting Memory Positions And Linking RKE recall the driver’s seat position, driver’s outside mirror Transmitter To Memory position, adjustable brake, accelerator pedals position NOTE: Each time the S (SET) button and a numbered and radio station preset settings.
Page 145: Memory Position Recall
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 5. Turn on the radio and set the radio station presets (up 11. Select “Remote Linked to Memory” in the Electronic to 12 AM and 12 FM stations can be set). Vehicle Information Center (EVIC) and enter “Yes”. Refer to “Electronic Vehicle Information Center (EVIC)/ 6.
Page 146: To Disable A Rke Transmitter Linked To Memory
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To recall the memory setting for driver two, press 3. Press and release the memory S (SET) button located MEMORY button number 2 on the driver’s door, or the on the driver’s door. UNLOCK button on the RKE transmitter linked to 4.
Page 147: To Open And Close The Hood
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 There are two possible Easy Entry/Exit adjustments The Easy Entry/Exit feature will be automatically dis- available: abled if the seat is already positioned closer than 0.9 in (23 mm) forward of the rear stop. At this position, there •...
Page 148 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. Pull the hood release lever located below the steering wheel at the base of the instrument panel. Safety Latch (1500 Series Shown) CAUTION! Hood Release To prevent possible damage, do not slam the hood to 2.
Page 149: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 WARNING! Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.
Page 150: Headlights
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To minimize the possibility of scratching the lenses and Automatic Headlights — If Equipped reducing light output, avoid wiping with a dry cloth. To This system automatically turns the headlights on or off remove road dirt, wash with a mild soap solution fol- according to ambient light levels.
Page 151: Headlights On With Wipers (Available With Automatic Headlights Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 When the system is on, the Headlight Delay feature is Headlight Delay also on. This means the headlights will stay on for up to To aid in your exit, your vehicle is equipped with a 90 seconds after you turn the ignition switch to the OFF headlight delay that will leave the headlights on for position.
Page 152: Parking Lights And Panel Lights
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Parking Lights And Panel Lights To turn on the parking lights and instrument panel lights, rotate the headlight switch clockwise. To turn off the parking lights, rotate the headlight switch back to the O (Off) position. Fog Lights —...
Page 153: Interior Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Interior Lights to the right until you hear a click. This feature is termed Courtesy and dome lights are turned on when the front the “Parade” mode and is useful when headlights are doors are opened, when the dimmer control (rotating required during the day.
Page 154: Cargo Light
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Light Lights-On Reminder The cargo lights are turned on by pressing on the cargo If the headlights, parking lights, or cargo lights are left on button. after the ignition is turned OFF, a chime will sound when the driver’s door is opened.
Page 155: Daytime Running Lights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Daytime Running Lights — If Equipped The headlights on your vehicle will illuminate when the engine is started and the transmission is in any gear except PARK. This provides a constant Lights ON condition until the ignition is turned OFF.
Page 156: Windshield Wipers And Washers
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lane Change Assist Tap the lever up or down once, without moving beyond the detent, and the turn signal (right or left) will flash three times then automatically turn off. Flash-To-Pass You can signal another vehicle with your headlights by partially pulling the multifunction lever toward the steer- ing wheel.
Page 157: Windshield Wiper Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 Intermittent Wiper System The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle, with a variable pause between cycles, desirable. For maximum delay between cycles, rotate the control knob into the upper end of the delay range.
Page 158: Windshield Washers
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers WARNING! To use the windshield washer, push the washer knob, located on the end of the multifunction lever, inward to Sudden loss of visibility through the windshield the second detent. Washer fluid will be sprayed and the could lead to a collision.
Page 159: Tilt Steering Column
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 TILT STEERING COLUMN This feature allows you to tilt the steering column upward or downward. The tilt lever is located on the steering column, below the multifunction lever. Pull the lever toward the steering wheel to unlock the steering column.
Page 160: Driver Adjustable Pedals - If Equipped
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Be sure the steering column is locked before driving your ve- hicle.
Page 161: Heated Steering Wheel - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 be adjusted when the system is locked out (“Adjust- HEATED STEERING WHEEL — IF EQUIPPED able Pedal Disabled — Cruise Control Engaged” or The steering wheel contains a heating element that helps “Adjustable Pedal Disabled — Vehicle In Reverse”. warm your hands in cold weather.
Page 162: Electronic Speed Control
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The engine must be running for the heated WARNING! (Continued) steering wheel to operate. • Do not place anything on the steering wheel that Vehicles Equipped With Remote Start insulates against heat, such as a blanket or cush- On models that are equipped with remote start, the ion.
Page 163: To Activate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 System can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed. To Activate Push the ON/OFF button. The Cruise Indicator Light in the instrument cluster will illuminate. To turn the system off, push the ON/OFF button a second time.
Page 164: To Set A Desired Speed
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Set A Desired Speed To Resume Speed Turn the Electronic Speed Control ON. When the vehicle To resume a previously set speed, push the RES (+) has reached the desired speed, press the SET (-) button button and release.
Page 165: To Accelerate For Passing
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 decrease until the button is released. Release the button On steep hills, a greater speed loss or gain may occur so when the desired speed is reached, and the new set speed it may be preferable to drive without Electronic Speed will be established.
Page 166: Courtesy/Reading Lights
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Power Sliding Rear Window Switch — If Equipped UNLOCK button is pressed on the Remote Keyless Entry (RKE) transmitter, if equipped. These lights are also operated individually as reading lights by pressing on the corresponding lens.
Page 167: Electrical Power Outlets
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 ELECTRICAL POWER OUTLETS The auxiliary 12 Volt (13 Amp) power outlets can provide power for in-cab accessories designed for use with the standard “cigar lighter” plug. The 12 Volt power outlets have a cap attached to the outlet indicating “12V DC”, together with either a key symbol or a battery symbol.
Page 168 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced. •...
Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Power Outlet — Upper Lid Power Outlet — Rear Center Console • Rear of the center console storage compartment — Crew Cab.
Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The key symbol indicates that this outlet can supply power when the key is in the ON or ACC positions. All accessories connected to the outlet(s) should be removed or turned off when the vehicle is not in use to protect the battery against discharge.
Page 171: Cigar Lighter And Ash Receiver - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 CIGAR LIGHTER AND ASH RECEIVER — IF CAUTION! EQUIPPED • Many accessories that can be plugged in draw A removable ash receiver and cigar lighter are available. For vehicles with a bench seat the cupholder tray can be power from the vehicle’s battery, even when not in used to hold the ash receiver.
Page 172: Power Inverter - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For vehicles equipped with a floor console the cuphold- To avoid overloading the circuit, check the power ratings ers may be used. on electrical devices prior to using the inverter. POWER INVERTER — IF EQUIPPED A 115 Volt (150 Watts Maximum) outlet is located on the center stack of the instrument panel, to the right of the radio.
Page 173 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 • Due to built-in overload protection, the power inverter The power inverter switch is located on the switch bank below the Climate will shut down if the power rating is exceeded. Controls. To turn on the power outlet, WARNING! press the switch once.
Page 174: Cupholders
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Front Instrument Panel Cupholders — Floor Storage Bin Front Instrument Panel Cupholders — For vehicles equipped with bucket seats two cupholders (40–20–40 Seats) are located in the floor storage bin. The cupholders are located in the pull-out tray on the center stack of the instrument panel.
Page 175: Rear Cupholder - Crew Cab
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 Rear Cupholder — Crew Cab STORAGE Crew Cab vehicles are equipped with rear cupholders Glove Box Storage located in the center armrest. The glove box is located on the passenger side of the instrument panel and features both an upper (if equipped) and lower storage area.
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To open the upper glove box push upward on the handle To open the lower glove box, pull on the handle to release release. The glove box door will automatically open. the latch and lower the door. Upper Glove Box Lower Glove Box...
Page 177: Door Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Door Storage Rear Door Storage — Crew Cab Storage compartments are located in both the driver and Front Door Storage — If Equipped passenger door trim panels. Storage areas and bottle holders (drivers side only) are located in the door trim panels.
Page 178: Center Storage Compartment - If Equipped
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Center Storage Compartment — If Equipped WARNING! The center storage compartment is located between the • This armrest is not a seat. Anyone seated on the driver and passenger seats. The storage compartment provides an armrest and contains both and upper and armrest could be seriously injured during vehicle lower storage area.
Page 179 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Upper Storage Compartment Lower Storage Bin With the upper lid closed, pull on the lower handle to open the lower storage bin.
Page 180: Seatback Storage
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not operate this vehicle with a console compart- ment lid in the open position. Cellular phones, music players, and other handheld electronic devices should be stowed while driving. Use of these devices while driving can cause an accident due to distrac- tion, resulting in death or injury.
Page 181: Storage And Seats (Crew Cab)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 Storage Bin Crew Cab Storage Storage and Seats (Crew Cab) CAUTION! The Crew Cab models provide additional storage under the rear seats. Lift the seats to access the storage com- Always lift the storage compartment lids by using partment.
Page 182: Plastic Grocery Bag Retainers (Regular Cab Models)
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Plastic Grocery Bag Retainers REAR WINDOW FEATURES (Regular Cab Models) Rear Window Defroster Retainer hooks which will hold plastic grocery bag The rear window defroster button is located on the handles are built into the back panel of the cab, behind climate control panel.
Page 183: Power Sliding Rear Window - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 CAUTION! Failure to follow these cautions can cause damage to the heating elements: • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
Page 185 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....187 EVIC Average Fuel Economy ... . 213 Instrument Cluster —...
Page 186 184 UNDERSTANDING YOUR INSTRUMENT PANEL Media Center 730N/430/430N (RHR/RER/ Media Center 130 With Satellite Radio RBZ/RHB) CD/DVD/HDD/NAV — (Sales Code RES+RSC)....232 If Equipped .
Page 187 UNDERSTANDING YOUR INSTRUMENT PANEL 185 Controlling The iPod Or External USB Operating Instructions - Uconnect™ Device Using Radio Buttons ... . . 251 Multimedia (Satellite) Mode ... . . 258 Play Mode .
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL Summer Operation ....272 Window Fogging And Frosting ..273 Winter Operation .
Page 189: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 187 INSTRUMENT PANEL FEATURES 1 — Headlight Switch 7 — 115v Power Inverter Outlet 13 — Transfer Case Position Switch 2 — Instrument Cluster 8 — Power Outlet 14 — Ignition Switch 3 — Radio 9 — Lower Switch Bank 15 —...
Page 190: Instrument Cluster - Base
188 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — BASE...
Page 191: Instrument Cluster - Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 189 INSTRUMENT CLUSTER — PREMIUM...
Page 192: Instrument Cluster Descriptions
190 UNDERSTANDING YOUR INSTRUMENT PANEL • Check for an inoperative outside light bulb if either INSTRUMENT CLUSTER DESCRIPTIONS indicator flashes at a rapid rate. 1. Tachometer The Tachometer indicates engine speed in revolutions per 3. Fuel Gauge minute (RPM x 1000). Shows level of fuel in tank when ignition switch is in the ON/RUN position.
Page 193 UNDERSTANDING YOUR INSTRUMENT PANEL 191 CAUTION! WARNING! Driving with a hot engine cooling system could A hot engine cooling system is dangerous. You or damage your vehicle. If the temperature gauge reads others could be badly burned by steam or boiling “H”...
Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL 6. 4 LOW vehicle has completely stopped and the shift lever is This light alerts the driver that the vehicle is in placed in the PARK position, the light should turn off. the four-wheel drive LOW mode. The front and If the light remains lit with the engine running, your rear driveshafts are mechanically locked to- vehicle will usually be drivable;...
Page 195 UNDERSTANDING YOUR INSTRUMENT PANEL 193 9. SVC (Service) 4WD 11. Vehicle Security Light — If Equipped The SVC 4WD light monitors the electric shift This light will flash at a fast rate for approxi- four-wheel drive system. If the SVC 4WD light mately 15 seconds, when the vehicle security stays on or comes on during driving, it means alarm is arming, and then will flash slowly...
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL 14. Odometer Display / Electronic Vehicle Information The two trip odometers show individual trip mileage. To Center (EVIC) Display Area switch from odometer to trip odometers, press and release the TRIP ODOMETER button. Odometer Display The odometer display shows the total distance the ve- To reset a trip odometer, display the desired trip odom- hicle has been driven.
Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 NOTE: There is also an engine hour function. This loose gascap indicator or the message “gASCAP” will indicates the total number of hours the engine has been display in the odometer display area. Tighten the fuel running.
Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL CHANgE OIL 2. Fully depress the accelerator pedal slowly three Your vehicle is equipped with an engine oil change times within 10 seconds. indicator system. The CHANgE OIL message will flash 3. Turn the ignition switch to the OFF/LOCK position. in the instrument cluster odometer for approximately 12 seconds after a single chime has sounded to indicate NOTE: If the indicator message illuminates when you...
Page 199 UNDERSTANDING YOUR INSTRUMENT PANEL 197 shift the transmission into NEUTRAL and idle the ve- lever to activate ERS. Refer to “Automatic Transmission” hicle. If the temperature reading does not return to in “Starting And Operating” for further information. normal, turn the engine off immediately and call for 17.
Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL 19. Voltmeter — If Equipped 20. Cargo Light When the engine is running, the gauge indicates the The cargo light will illuminate when the cargo electrical system voltage. The pointer should stay within light is activated by pressing the cargo light the normal range if the battery is charged.
Page 201 UNDERSTANDING YOUR INSTRUMENT PANEL 199 to the brake booster, the ABS pump will run when WARNING! applying the brake and a brake pedal pulsation may be felt during each stop. Driving a vehicle with the red brake light on is dangerous.
Page 202 200 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is Center (EVIC). Refer to ”Electronic Vehicle Information applied with the ignition switch in the ON/RUN posi- Center (EVIC) — If Equipped” for further information. tion.
Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 Although your vehicle will usually be drivable and not WARNING! need towing, see your authorized dealer for service as soon as possible. A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal CAUTION! operating conditions.
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Front Fog Light Indicator — If Equipped 27. Transmission Temperature Warning Light This indicator will illuminate when the front fog This light indicates that there is excessive trans- lights are on. mission fluid temperature that might occur with severe usage such as trailer towing.
Page 205 UNDERSTANDING YOUR INSTRUMENT PANEL 203 belt remains unbuckled, the seat belt reminder light will WARNING! flash or remain on continuously. Refer to “Occupant Restraints” in “Things To Know Before Starting Your If the Transmission Temperature Warning Light is Vehicle” for further information. illuminated and you continue operating the vehicle, in some circumstances you could cause the fluid to 29.
Page 206: Electronic Vehicle Information Center (Evic) - If Equipped
204 UNDERSTANDING YOUR INSTRUMENT PANEL For vehicles equipped with a premium cluster this indi- cator will display in the Electronic Vehicle Information Center (EVIC). Refer to ”Electronic Vehicle Information Center (EVIC) — If Equipped” for further information. ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) —...
Page 207 UNDERSTANDING YOUR INSTRUMENT PANEL 205 This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel. The EVIC consists of the following: • Compass and Outside Temperature • Audio Information •...
Page 208: Electronic Vehicle Information Center (Evic) Displays
206 UNDERSTANDING YOUR INSTRUMENT PANEL Press and release the DOWN button to scroll Electronic Vehicle Information Center (EVIC) downward through the main menus and sub- Displays menus. When the appropriate conditions exist, the EVIC displays the following messages: SELECT Button •...
Page 209 UNDERSTANDING YOUR INSTRUMENT PANEL 207 • Trailer Brake Connected • System Setup Unavailable - Vehicle in Motion • Trailer Brake Disconnected • Service Four Wheel Drive System • Lights On • Adjustable pedals unavail. • Keyfob Battery Low • Cruise engaged •...
Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL • Exhaust filter full – Power reduced See Dealer - • Did not train Exhaust Filter 99% Full - - - • Oil temp high Speed may be limited • Blind spot system off • Remote start aborted — Door ajar •...
Page 211 UNDERSTANDING YOUR INSTRUMENT PANEL 209 • Adjustable Pedals Unavail — Cruise Engaged • Charging System Light This light shows the status of the electrical charg- EVIC Warning Lights ing system. The light should come on when the • Door Ajar ignition switch is first turned ON and remain on briefly This light will turn on to indicate that one or as a bulb check.
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Throttle Control (ETC) Light • Engine Temperature Warning Light This light informs you of a problem with the This light warns of an overheated engine condi- Electronic Throttle Control (ETC) system. The tion. As temperatures rise and the gauge ap- light will come on when the ignition is first proaches H, this indicator will illuminate and a turned ON and remain on briefly as a bulb...
Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 • SERV 4WD light comes on, stop the vehicle and run the engine at idle The SERV 4WD light monitors the electric shift or faster, with the transmission in NEUTRAL until the 4WD system. If the SERV 4WD light stays on or light goes off.
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL • Loose Gascap Message indicator system is duty-cycle based, which means the If the vehicle diagnostic system determines engine oil change interval may fluctuate dependent upon that the fuel filler cap is loose, improperly your personal driving style. installed, or damaged, a loose gascap icon will Unless reset, this message will continue to display each display in the telltale display area.
Page 215: Distance To Empty (Dte)
UNDERSTANDING YOUR INSTRUMENT PANEL 213 Distance To Empty (DTE) EVIC Average Fuel Economy Shows the estimated distance that can be traveled with Shows the average fuel economy since the last reset. the fuel remaining in the tank. This estimated distance is When the fuel economy is reset, the display will read determined by a weighted average of the instantaneous “RESET”...
Page 216: Vehicle Info
214 UNDERSTANDING YOUR INSTRUMENT PANEL The Trip Functions mode displays the following informa- To Reset The Display tion: Reset will only occur while a resettable function is being displayed. Press and release the ODOMETER/TRIP • Trip A ODOMETER button once to clear the resettable function Shows the total distance traveled for Trip A since the last being displayed.
Page 217: Units
UNDERSTANDING YOUR INSTRUMENT PANEL 215 • Trailer Brake — If Equipped Compass / Temperature Display Displays trailer brake output power and trailer brake The compass readings indicate the direction the vehicle is status indicator. facing. The EVIC will display one of eight compass •...
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL temperature sensor caused by the snowplow. In addi- NOTE: A good calibration requires a level surface and tion, on vehicles equipped with Automatic Tempera- an environment free from large metallic objects such as ture Control (ATC), it is suggested that the interior buildings, bridges, underground cables, railroad tracks, cabin temperature be manually controlled should the etc.
Page 219 UNDERSTANDING YOUR INSTRUMENT PANEL 217 4. Press and release the SELECT button to start the NOTE: Keep magnetic materials away from the top of calibration. The “CAL” indicator will be displayed in the the instrument panel, such as iPod’s, Mobile Phones, EVIC.
Page 220: Customer-Programmable Features (System Setup)
218 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Press the UP or DOWN button until the System Setup Press and release the UP or DOWN button until System (Customer-Programmable Features) menu is reached, Setup displays in the EVIC. then press the SELECT button. Use the UP or DOWN button to display one of the 3.
Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 route, mile by mile, turn-by-turn until the final destina- opened. To make your selection, press and release the tion is reached. To make your selection, press and release SELECT button until a check-mark appears next to the the SELECT button until a check-mark appears next to feature showing the system has been activated, or the the feature showing the system has been activated or the...
Page 222: Understanding Your Instrument Panel
220 UNDERSTANDING YOUR INSTRUMENT PANEL RKE Linked To Memory through the duration of remote start or until the key is When this feature is selected the memory seat, mirror, turned to RUN. To make your selection, press and release pedals, and radio settings will return to the memory set the SELECT button until a check-mark appears next to position when the Remote Keyless Entry (RKE) transmit- the feature showing the system has been activated or the...
Page 223 UNDERSTANDING YOUR INSTRUMENT PANEL 221 Lamps with Lock feature. To make your selection, press up or down until the preferred setting is highlighted, and release the SELECT button until a check-mark ap- then press and release the SELECT button until a check- pears next to the feature showing the system has been mark appears next to the setting, showing that the setting activated or the check-mark is removed showing the...
Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL SELECT button until a check-mark appears next to the Key-Off Power Delay feature showing the system has been activated or the When this feature is selected, the power window check-mark is removed showing the system has been switches, radio, hands-free system (if equipped), DVD deactivated.
Page 225: Media Center 730N/430/430N
UNDERSTANDING YOUR INSTRUMENT PANEL 223 Compass Variance Operating Instructions Refer to “Compass Display” for more information. (Voice Command System) — If Equipped Refer to “Voice Command” in the Uconnect™ User Calibrate Compass Manual located on the DVD for further details. Refer to “Compass Display”...
Page 226: Media Center 130 (Sales Code Res)
224 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 (SALES CODE RES) Operating Instructions — Radio Mode NOTE: The radio sales code is located on the lower right NOTE: The ignition switch must be in the ON or ACC side of the radio faceplate. position to operate the radio.
Page 227 UNDERSTANDING YOUR INSTRUMENT PANEL 225 SEEK Buttons 4. Adjust the minutes using the right side TUNE/ Press and release the SEEK buttons to search for the next SCROLL control knob. Press the TUNE/SCROLL control listenable station in AM/FM mode. Press the right switch knob to save time change.
Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the AM/FM Button mid-range tones.
Page 229: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 227 SET 2 in both AM and FM. This allows a total of 12 AM Operation Instructions — CD MODE For CD And and 12 FM stations to be stored into pushbutton memory. MP3 Audio Play The stations stored in SET 2 memory can be selected by NOTE: pressing the pushbutton twice.
Page 230 228 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio EJECT Button - Ejecting a CD ON, the unit will switch from radio to CD mode and Press the EJECT button to eject the CD. begin to play when you insert the disc.
Page 231: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 229 the current selection. Pressing and holding the SEEK SET/RND Button (Random Play Button) button will allow faster scrolling through the tracks in Press this button while the CD is playing to activate CD and MP3 modes. Random Play.
Page 232 230 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of characters in file/folder names: Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 • Level 1: 12 (including a separator . and a three- Level 1 and Level 2 and includes the Joliet extension. character extension) When reading discs recorded using formats other than •...
Page 233 UNDERSTANDING YOUR INSTRUMENT PANEL 231 When using the MP3 encoder to compress audio data to Playlist files are not supported. MP3 Pro files are not an MP3 file, the bit rate and sampling frequencies in the supported. following table are supported. In addition, variable bit Playback of MP3 Files rates (VBR) are also supported.
Page 234: Operation Instructions - Auxiliary Mode
232 UNDERSTANDING YOUR INSTRUMENT PANEL To increase the speed of disc loading, it is recommended NOTE: The AUX device must be turned on and the to use CD-R media and single-session discs. To create a device’s volume set to proper level. If the AUX audio is single-session disc, enable the “Disc at Once”...
Page 235: Operating Instructions - Radio Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 233 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping.
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL Voice Command System (Radio) — If Equipped If your vehicle is not equipped with or this feature is not Refer to “Voice Command” in “Understanding The Fea- available on your vehicle, a “Not Equipped With tures If Your Vehicle”.
Page 237 UNDERSTANDING YOUR INSTRUMENT PANEL 235 4. Adjust the minutes using the right side TUNE/ RW/FF SCROLL control knob. Press the TUNE/SCROLL control Pressing the RW (Rewind) or FF (Fast Forward) buttons knob to save time change. causes the tuner to search for the next frequency in the direction of the arrows.
Page 238 236 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a third or turning the TUNE/SCROLL control knob within five time and TREBLE will display. Turn the TUNE/SCROLL seconds will allow the program format type to be se- control knob to the right or left to increase or decrease the lected.
Page 239 UNDERSTANDING YOUR INSTRUMENT PANEL 237 By pressing the SEEK button when the Music Type icon Program Type 16-Digit Character Display is displayed, the radio will be tuned to the next frequency News News station with the same selected Music Type name. The Nostalgia Nostalga Music Type function only operates when in the FM...
Page 240 238 UNDERSTANDING YOUR INSTRUMENT PANEL the minutes using the right side TUNE/SCROLL display window. Each button can be set for SET 1 and control knob. Press the TUNE/SCROLL control knob SET 2 in both AM and FM. This allows a total of 12 AM to save time change.
Page 241: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 239 Operation Instructions — CD MODE for CD and If you insert a disc with the ignition ON and the radio MP3 Audio Play ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will NOTE: show the track number, and index time in minutes and •...
Page 242 240 UNDERSTANDING YOUR INSTRUMENT PANEL EJECT Button - Ejecting a CD the current selection. Pressing and holding the SEEK Press the EJECT button to eject the CD. button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD If you have ejected a disc and have not removed it within...
Page 243: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 241 SET/RND Button (Random Play Button) Supported Medium Formats (File Systems) Press this button while the CD is playing to activate The medium formats supported by the radio are ISO 9660 Random Play. This feature plays the selections on the Level 1 and Level 2 and includes the Joliet extension.
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of characters in file/folder names: When using the MP3 encoder to compress audio data to an MP3 file, the bit rate and sampling frequencies in the • Level 1: 12 (including a separator . and a three- following table are supported.
Page 245: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 243 Playlist files are not supported. MP3 Pro files are not To increase the speed of disc loading, it is recommended supported. to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option Playback of MP3 Files before writing to the disc.
Page 246: Uconnect™ Multimedia (Satellite Radio) - If Equipped
244 UNDERSTANDING YOUR INSTRUMENT PANEL Press the INFO button once more to return to elapsed is not loud enough, turn the device’s volume up. If the time priority mode. AUX audio sounds distorted, turn the device’s volume down. Press and hold the INFO button for three seconds or more and the radio will display song titles for each file.
Page 247 UNDERSTANDING YOUR INSTRUMENT PANEL 245 System Activation To access the ESN/SID, refer to the following steps: Sirius Satellite Radio service is pre-activated, and you ESN/SID Access may begin listening immediately to the one year of audio With the ignition switch in the ON/RUN or ACC posi- service that is included with the factory-installed satellite tion and the radio on, press the SETUP button and scroll radio system in your vehicle.
Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL bikes should be placed as far rearward as possible, within Operating Instructions - Uconnect™ Multimedia the loading design of the rack. Do not place items directly (Satellite) Mode on or above the antenna. NOTE: The ignition switch must be in the ON/RUN or Reception Quality ACC position to operate the radio.
Page 249 UNDERSTANDING YOUR INSTRUMENT PANEL 247 INFO Button MUSIC TYPE Button Pressing the INFO button will cycle the display informa- Pressing this button once will turn on the Music Type tion between Artist, Song Title, and Composer (if avail- mode for five seconds. Pressing the MUSIC TYPE button able).
Page 250 248 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button You may add a second channel to each pushbutton by Pressing the SETUP button allows you to select the repeating the above procedure with this exception: Press following items: the SET button twice and SET 2 will show in the display window.
Page 251: Ipod /Usb/Mp3 Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 249 iPod /USB/MP3 CONTROL — IF EQUIPPED NOTE: • If the radio has a USB port, refer to the appropriate NOTE: This section is for sales code RES and REQ/ Uconnect™ Multimedia radio User’s Manual for REL/RET radios only with Uconnect™.
Page 252: Connecting The Ipod Or External Usb Device
250 UNDERSTANDING YOUR INSTRUMENT PANEL Connecting The iPod Or External USB Device Once the audio device is connected and synchronized to Use the connection cable to connect an iPod or external the vehicle’s iPod /USB/MP3 control system (iPod or USB device to the vehicle’s USB connector port which is external USB device may take a few minutes to connect), located in the glove compartment.
Page 253: Controlling The Ipod Or External Usb Device Using Radio Buttons
UNDERSTANDING YOUR INSTRUMENT PANEL 251 • The audio device can be controlled using the radio mode. In Play mode, the following buttons on the radio buttons to Play, Browse, and List the iPod contents. faceplate may be used to control the iPod or external USB device and display data: •...
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL • A single press backward << RW or forward FF >> will • Press the SCAN button to use iPod /USB/MP3 de- jump backward or forward respectively, for five vice scan mode, which will play the first 10 seconds of seconds.
Page 255: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 253 • During all List modes, the iPod displays all lists in List Or Browse Mode During Play mode, pressing any of the buttons described “wrap-around” mode. So if the track is at the below, will bring up List mode. List mode enables bottom of the list, just turn the wheel backward scrolling through the list of menus and tracks on the (counterclockwise) to get to the track faster.
Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL • Pressing a PRESET button will display the current CAUTION! list on the top line and the first item in that list on • Leaving the iPod or external USB device (or any the second line. supported device) anywhere in the vehicle in •...
Page 257: Bluetooth Streaming Audio (Btsa)
UNDERSTANDING YOUR INSTRUMENT PANEL 255 Bluetooth Streaming Audio (BTSA) 2. After the Ready prompt and the following beep, say Music can be streamed from your cellular phone to the Setup , then Select Audio Devices . Uconnect™ phone system. 3. Say the name of the audio device or ask the Controlling BTSA Using Radio Buttons Uconnect™...
Page 258: Uconnect™ Multimedia (Satellite Radio) - If Equipped (Ren/Rer/Res Radios Only)
256 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect™ Multimedia (SATELLITE RADIO) — IF information, call the toll-free number 888-539-7474, or EQUIPPED (REN/RER/RES RADIOS ONLY) visit the Sirius web site at www.sirius.com, or at www- Satellite radio uses direct satellite-to-receiver broadcast- .siriuscanada.ca for Canadian residents. ing technology to provide clear digital sound, coast to Electronic Serial Number/Sirius Identification coast.
Page 259: Selecting Uconnect™ Multimedia (Satellite) Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 257 Sirius ID number will display. The Sirius ID number bikes should be placed as far rearward as possible, within display will time out in two minutes. Press any button on the loading design of the rack. Do not place items directly the radio to exit this screen.
Page 260: Operating Instructions - Uconnect
258 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Uconnect™ Multimedia INFO Button (Satellite) Mode Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- NOTE: The ignition switch must be in the ON or ACC able).
Page 261 UNDERSTANDING YOUR INSTRUMENT PANEL 259 MUSIC TYPE Button SETUP Button Pressing this button once will turn on the Music Type Pressing the SETUP button allows you to select the mode for five seconds. Pressing the MUSIC TYPE button following items: or turning the TUNE/SCROLL control knob within five •...
Page 262: Operating Instructions - Uconnect™ Phone (If Equipped)
260 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second channel to each pushbutton by STEERING WHEEL AUDIO CONTROLS — repeating the above procedure with this exception: Press IF EQUIPPED the SET button twice and SET 2 will show in the display The remote sound system controls are located on the rear window.
Page 263: Radio Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 261 The right hand control is a rocker type switch with a The button located in the center of the left hand control pushbutton in the center. Pressing the top of the switch will tune to the next pre-set station that you have will increase the volume, and pressing the bottom of the programmed in the radio pre-set pushbuttons.
Page 264: Cd/Dvd Disc Maintenance
262 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD DISC MAINTENANCE NOTE: If you experience difficulty in playing a particu- To keep a CD/DVD in good condition, take the following lar disc, it may be damaged (i.e., scratched, reflective precautions: coating removed, a hair, moisture or dew on the disc) oversized, or have protection encoding.
Page 265: Manual Heating And Air Conditioning System
UNDERSTANDING YOUR INSTRUMENT PANEL 263 throughout the vehicle. The controls are located on the dials and inner push knobs. These comfort controls can instrument panel below the radio. be set to obtain desired interior conditions. NOTE: During snowplow usage on vehicles equipped with outside temperature display, the display may show higher temperatures than the outside ambient tempera- ture.
Page 266 264 UNDERSTANDING YOUR INSTRUMENT PANEL Front Blower Control temperatures. Rotating the knob clockwise, into the red There are four blower speeds. Use this area, indicates warmer temperatures. control to regulate the amount of air NOTE: If your air conditioning performance seems forced through the system in any lower than expected, check the front of the A/C con- mode you select.
Page 267 UNDERSTANDING YOUR INSTRUMENT PANEL 265 Panel Mode Mix Mode Air is directed through the outlets in the instrument Air is directed through the floor, defrost and side panel. These outlets can be adjusted to direct airflow. window demist outlets. This setting works best in cold or snowy conditions that require extra heat at Bi-Level Mode the windshield.
Page 268 266 UNDERSTANDING YOUR INSTRUMENT PANEL • In cold or damp weather, the use of the Recirculation Recirculation Control Press this button to choose between mode will cause windows to fog on the inside because outside air intake or recirculation of of moisture buildup inside the vehicle.
Page 269: Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 267 Economy Mode MAX A/C If ECONOMY mode is desired, press the A/C button to For maximum cooling, when MAX turn off the LED indicator and the A/C compressor. A/C is selected the A/C is turned on Rotate the temperature control knob to the desired automatically and the air is recircu- temperature.
Page 270 268 UNDERSTANDING YOUR INSTRUMENT PANEL • When occupants in the vehicle select an Auto mode operation, Auto blower operation is set by using rotary knobs on the control unit and a comfort temperature setting by using the temperature up and down but- tons.
Page 271 UNDERSTANDING YOUR INSTRUMENT PANEL 269 Automatic Operation NOTE: • It is not necessary to move the temperature settings for 1. Position the MODE control knob to the Auto position cold or hot vehicles. The system automatically adjusts on the Automatic Temperature Control (ATC) Panel. the temperature, mode and fan speed to provide 2.
Page 272 270 UNDERSTANDING YOUR INSTRUMENT PANEL blower will engage immediately if the Defrost mode is The blower fan speed can be set to any fixed speed by selected, or by adjusting the blower control knob and adjusting the blower control knob. The fan will now setting the fan to any fixed speed.
Page 273 UNDERSTANDING YOUR INSTRUMENT PANEL 271 NOTE: In many temperature positions, the BI-LEVEL NOTE: While operating in the other modes, the system mode is designed to provide cooler air out of the panel will not automatically sense the presence of fog, mist or outlets and warmer air from the floor outlets.
Page 274: Summer Operation
272 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation Control Summer Operation When outside air contains smoke, odors, or The engine cooling system in air conditioned vehicles high humidity, or if rapid cooling is desired, must be protected with a high-quality antifreeze coolant you may wish to recirculate interior air by to provide proper corrosion protection and to protect pressing the RECIRCULATION control button.
Page 275: Window Fogging And Frosting
UNDERSTANDING YOUR INSTRUMENT PANEL 273 Vacation/Storage Outside Air Intake Any time you store your vehicle or keep it out of service Make sure the air intake, located directly in front of the (i.e., vacation) for two weeks or more, run the air windshield, is free of obstructions such as leaves.
Page 276: Operating Tips
274 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips...
Page 277: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....279 Automatic Transmission ....282 Normal Starting .
Page 278 276 STARTING AND OPERATING Transfer Case Position Indicator Light ..297 Parking Brake ......310 Electronically Shifted Transfer Case Brake System .
Page 279 STARTING AND OPERATING 277 Spare Tire Matching Original Equipped Tire Tire Rotation Recommendations ... 339 And Wheel – If Equipped ....330 Dual Rear Wheels .
Page 280 278 STARTING AND OPERATING Vehicle Loading ..... . 347 Over The Road Operation With Snowplow Attached ......366 Certification Label .
Page 281: Starting Procedures
STARTING AND OPERATING 279 STARTING PROCEDURES Normal Starting Before starting your vehicle, adjust your seat, adjust both Normal starting of either a warm or cold engine is inside and outside mirrors, and fasten your seat belt. obtained without pumping or pressing the accelerator pedal.
Page 282: Extreme Cold Weather (Below -20°F Or 29°C)
280 STARTING AND OPERATING Tip Start Feature CAUTION! Do not press the accelerator. Turn the ignition switch briefly to the START position and release it. The starter To prevent damage to the starter, do not crank the motor will continue to run but will automatically disen- engine for more than 15 seconds at a time.
Page 283: After Starting
STARTING AND OPERATING 281 After Starting WARNING! (Continued) The idle speed is automatically controlled and will de- • If the vehicle has a discharged battery, booster crease as the engine warms up. cables may be used to obtain a start from a booster battery or the battery in another vehicle.
Page 284: Automatic Transmission
282 STARTING AND OPERATING The engine block heater must be plugged in at least one CAUTION! (Continued) hour to have an adequate warming effect on the engine. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine WARNING! is at idle speed.
Page 285 STARTING AND OPERATING 283 WARNING! WARNING! (Continued) • Leaving children in a vehicle unattended is dan- • Unintended movement of a vehicle could injure gerous for a number of reasons. A child or others those in or near the vehicle. As with all vehicles, could be seriously or fatally injured.
Page 286: Key Ignition Park Interlock
284 STARTING AND OPERATING Key Ignition Park Interlock shift lever is mounted on the right side of the steering This vehicle is equipped with a Key Ignition Park Inter- column. You must press the brake pedal to move the shift lock which requires the shift lever to be placed in PARK lever out of the PARK position (refer to “Brake/ before the ignition switch can be turned to the LOCK/...
Page 287 STARTING AND OPERATING 285 The transmission shift lever has only PARK, REVERSE, When parking on a level surface, you may place the shift NEUTRAL, and DRIVE shift positions. Manual down- lever in the PARK position first, and then apply the shifts can be made using the Electronic Range Select parking brake.
Page 288 286 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Your vehicle could move and injure you and others • Unintended movement of a vehicle could injure if it is not completely in PARK. Check by trying to those in and near the vehicle. As with all vehicles, move the shift lever clockwise without first pull- you should never exit a vehicle while the engine is ing it toward you after you have placed it in PARK.
Page 289 STARTING AND OPERATING 287 • Look at the shift lever position display and verify that CAUTION! it indicates the PARK position. • Before moving the shift lever out of PARK, you • With brake pedal released, verify that the shift lever must turn the ignition switch from the LOCK/OFF will not move out of PARK.
Page 290 288 STARTING AND OPERATING DRIVE WARNING! This range should be used for most city and highway driving. It provides the smoothest upshifts and down- Do not coast in NEUTRAL and never turn off the shifts, and the best fuel economy. The transmission ignition to coast down a hill.
Page 291 STARTING AND OPERATING 289 If the transmission operating temperature exceeds nor- During cold temperatures, transmission operation may mal operating limits, the powertrain controller will be modified depending on engine and transmission modify the transmission shift schedule and expand the temperature as well as vehicle speed. This feature im- range of torque converter clutch engagement.
Page 292 290 STARTING AND OPERATING to operate. Limp Home Mode allows the vehicle to be NOTE: Even if the transmission can be reset, we recom- driven to an authorized dealer for service without dam- mend that you visit your authorized dealer at your aging the transmission.
Page 293 STARTING AND OPERATING 291 switch will activate ERS mode, display the current gear in To exit ERS mode, simply press and hold the ERS (+) the instrument cluster, and maintain that gear as the top switch until “D” is once again displayed in the shift lever available gear.
Page 294 292 STARTING AND OPERATING Overdrive Operation HAUL mode. This will improve performance and reduce The automatic transmission includes an electronically the potential for transmission overheating or failure due controlled Overdrive (fifth and sixth gears). The trans- to excessive shifting. When operating in TOW/HAUL mission will automatically shift into the Overdrive gear if mode, transmission upshifts are delayed, and the trans- the following conditions are present:...
Page 295 STARTING AND OPERATING 293 The “TOW/HAUL Indicator Light” will illuminate in the transmission fluid and engine coolant are warm [usu- instrument cluster to indicate that TOW/HAUL mode ally after 1 to 3 miles (1.6 to 4.8 km) of driving]. has been activated. Pressing the switch a second time Because sixth gear is disabled, and engine speed is restores normal operation.
Page 296: Four-Wheel Drive Operation - If Equipped
294 STARTING AND OPERATING FOUR-WHEEL DRIVE OPERATION — When additional traction is required, the 4H and 4L IF EQUIPPED positions can be used to lock the front and rear drive- Four-wheel drive trucks are equipped with either a shafts together and force the front and rear wheels to manually shifted transfer case or an electronically shifted rotate at the same speed.
Page 297 STARTING AND OPERATING 295 at a given road speed. Take care not to overspeed the WARNING! engine and do not exceed 25 mph (40 km/h). You or others could be injured if you leave the Proper operation of four-wheel drive vehicles depends vehicle unattended with the transfer case in the on tires of equal size, type and circumference on each NEUTRAL position without first fully engaging the...
Page 298: Shifting Procedure - Manually Shifted Transfer Case
296 STARTING AND OPERATING Shifting Procedure – Manually Shifted Transfer Four-Wheel Drive High Range - This range locks the Case front and rear driveshafts together forcing the front and 2H ⇔ 4H rear wheels to rotate at the same speed. Additional Shifting between 2H and 4H can be made with the traction for loose, slippery road surfaces only.
Page 299: Transfer Case Position Indicator Light
STARTING AND OPERATING 297 NOTE: method is with the vehicle rolling 2 to 3 mph (3 to • Pausing in transfer case NEUTRAL in vehicles 5 km/h). Avoid attempting to engage or disengage 4L equipped with an automatic transmission may require with the vehicle moving faster than 2 to 3 mph (3 to shutting the engine OFF to avoid gear clash while 5 km/h).
Page 300: Electronically Shifted Transfer Case (Four-Position Switch) - If Equipped
298 STARTING AND OPERATING Electronically Shifted Transfer Case This electronically shifted transfer case provides four (Four-Position Switch) – If Equipped mode positions: This is an electronic shift transfer case and is operated by • Two-wheel drive high range (2WD) the 4WD Control Switch (Transfer Case Switch), which is •...
Page 301 STARTING AND OPERATING 299 desired position. Refer to “Shifting Procedure” for spe- the current and desired transfer case selection. When you cific shifting instructions. The 4WD LOCK and 4WD select a different transfer case position, the indicator LOW positions are designed for loose, slippery road lights will do the following: surfaces only.
Page 302 300 STARTING AND OPERATING NOTE: Before retrying a selection, make certain that all WARNING! the necessary requirements for selecting a new transfer case position have been met. To retry the selection, turn Always engage the parking brake when powering the control knob back to the current position, wait five down the vehicle if the “SVC 4WD Warning Light”...
Page 303 STARTING AND OPERATING 301 Proper operation of four-wheel drive vehicles depends For additional information on the appropriate use of each on tires of equal size, type and circumference on each transfer case mode position, see the information below: wheel. Any difference in tire size can cause damage to the drivetrain.
Page 304: Shifting Procedure
302 STARTING AND OPERATING • If all the requirements to select a new transfer case Neutral - This range disengages both the front and rear position have been met, the current position indicator driveshafts from the powertrain. To be used for flat light will turn OFF, the selected position indicator light towing behind another vehicle.
Page 305 STARTING AND OPERATING 303 NOTE: The four-wheel drive system will not allow 2. Shift the transmission into NEUTRAL. shifts between 2WD/4WD LOCK if the front and/or rear 3. While still rolling, rotate the transfer case control wheels are spinning (no traction). In this situation, the switch to the desired position.
Page 306: Limited-Slip Differential
304 STARTING AND OPERATING NOTE: surfaces, however, the differential delivers more of the • If Steps 1 or 2 of either the Preferred or Alternate driving effort to the rear wheel having the better traction. Procedure are not satisfied prior to attempting the The limited-slip differential is especially helpful during shift, then the desired position indicator light will flash slippery driving conditions.
Page 307: Driving On Slippery Surfaces
STARTING AND OPERATING 305 Care should be taken to avoid sudden accelerations when WARNING! both rear wheels are on a slippery surface. This could cause both rear wheels to spin, and allow the vehicle to Rapid acceleration on slippery surfaces is dangerous. slide sideways on the crowned surface of a road or in a Unequal traction can cause sudden pulling of the rear turn.
Page 308: Driving Through Water
306 STARTING AND OPERATING 2. Slow down if the road has standing water or puddles. Flowing/Rising Water 3. Replace tires when tread wear indicators first become WARNING! visible. Do not drive on or across a road or path where water 4.
Page 309 STARTING AND OPERATING 307 CAUTION! CAUTION! (Continued) • Driving through standing water may cause dam- • Always check the depth of the standing water age to your vehicle’s drivetrain components. Al- before driving through it. Never drive through ways inspect your vehicle’s fluids (i.e., engine oil, standing water that is deeper than the bottom of transmission, axle, etc.) for signs of contamination the tire rims mounted on the vehicle.
Page 310: Power Steering
308 STARTING AND OPERATING POWER STEERING WARNING! The standard power steering system will give you good • Driving through standing water limits your vehi- vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical cle’s traction capabilities. Do not exceed 5 mph steering capability if power assist is lost.
Page 311: Power Steering Fluid Check
STARTING AND OPERATING 309 • Upon initial start-up in cold weather, the power steer- Power Steering Fluid Check ing pump may make noise for a short amount of time. Checking the power steering fluid level at a defined This is due to the cold, thick fluid in the steering service interval is not required.
Page 312: Parking Brake
310 STARTING AND OPERATING The foot operated parking brake is located below the WARNING! lower left corner of the instrument panel. To apply the park brake, firmly push the park brake pedal fully. To Fluid level should be checked on a level surface and release the parking brake, pull the parking brake release with the engine off to prevent injury from moving handle.
Page 313 STARTING AND OPERATING 311 When the parking brake is applied with the ignition The parking brake should always be applied whenever switch ON, the “Brake Warning Light” in the instrument the driver is not in the vehicle. cluster will illuminate. WARNING! NOTE: •...
Page 314: Brake System
312 STARTING AND OPERATING brakes will still function. However, you will experience a WARNING! (Continued) substantial increase in braking effort to stop the vehicle. • Always fully apply the parking brake when leav- If either the front or rear hydraulic system loses normal ing your vehicle or it may roll and cause damage or braking capability, the remaining system will still func- injury.
Page 315: Four-Wheel Anti-Lock Brake System
STARTING AND OPERATING 313 Four-Wheel Anti-Lock Brake System The system’s pump motor runs during an ABS stop to provide regulated hydraulic pressure. The pump motor WARNING! makes a low humming noise during operation. This is normal. The Four-Wheel Anti-Lock Brake System contains The ABS conducts a low-speed selftest at about 10 mph sophisticated electronic equipment.
Page 316 314 STARTING AND OPERATING ABS Warning Light WARNING! (Continued) The ABS includes an amber warning light. When the light • The ABS cannot prevent collisions, including is illuminated, the ABS is not functioning. The system those resulting from excessive speed in turns, reverts to standard, non-anti-lock brakes.
Page 317: Tire Safety Information
The letter P is absent from this tire size designation. Example: 215/65R15 96H. • LT (Light Truck) - Metric tire sizing is based on U.S. design standards. The size designation for LT-Metric tires is the same as for P-Metric tires except for the letters “LT”...
Page 318 P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in)
Page 319 STARTING AND OPERATING 317 EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 320: Tire Identification Number (Tin)
318 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 321: Tire Terminology And Definitions
STARTING AND OPERATING 319 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 322: Tire Loading And Tire Pressure
320 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
Page 323 STARTING AND OPERATING 321 axles must not be exceeded. For further information on This placard tells you important information about GAWRs, vehicle loading, and trailer towing, refer to the: “Vehicle Loading” in this section. 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of...
Page 324 322 STARTING AND OPERATING 3. Subtract the combined weight of the driver and pas- NOTE: • The following table shows examples on how to calcu- sengers from XXX lbs or XXX kg. late total load, cargo/luggage, and towing capacities 4. The resulting figure equals the available amount of of your vehicle with varying seating configurations cargo and luggage load capacity.
Page 325 STARTING AND OPERATING 323...
Page 326: Tires - General Information
324 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 327: Tire Inflation Pressures
STARTING AND OPERATING 325 Ride Comfort And Vehicle Stability WARNING! (Continued) Proper tire inflation contributes to a comfortable ride. • Unequal tire pressures from one side of the ve- Over-inflation produces a jarring and uncomfortable hicle to the other can cause the vehicle to drift to ride.
Page 328 326 STARTING AND OPERATING The pressure should be checked and adjusted as well as Inflation pressures specified on the placard are always inspecting for signs of tire wear or visible damage at least “cold tire inflation pressure.” Cold tire inflation pressure once a month.
Page 329 This type of tire utilizes steel cords in the sidewall. As the winter. such, they cannot be treated like normal light truck tires. Adjusting tire pressure must be performed by personnel Example: If garage temperature = 68°F (20°C) and the trained, supervised and equipped accordingly.
Page 330 328 STARTING AND OPERATING 4500/5500 Tire Inflation...
Page 331 STARTING AND OPERATING 329 When adjusting inflation pressure to a tire and wheel Tire Pressures For High Speed Operation assembly mounted on a vehicle, use a Remote Mount The manufacturer advocates driving at safe speeds Automatic Inflation Kit or see your authorized dealer. within posted speed limits.
Page 332: Radial Ply Tires
330 STARTING AND OPERATING Radial Ply Tires Spare Tire Matching Original Equipped Tire And Wheel – If Equipped WARNING! Your vehicle may be equivalent with a spare tire and wheel in look and function as the original equipment tire Combining radial ply tires with other types of tires and wheel found on the front or rear axle of your vehicle.
Page 333: Compact Spare Tire - If Equipped
STARTING AND OPERATING 331 Since this tire has limited tread life the original equip- CAUTION! ment tire should be repaired (or replaced) and reinstalled on your vehicle at the first opportunity. Because of the reduced ground clearance, do not take your vehicle through an automatic car wash with a Do not install a wheel cover or attempt to mount a compact, full size or limited-use temporary spare...
Page 334: Full Size Spare - If Equipped
332 STARTING AND OPERATING Full Size Spare – If Equipped your original equipment tire, replace (or repair) the The full size spare is for temporary emergency use only. original equipment tire and reinstall on the vehicle at the This tire may look like the original equipped tire on the first opportunity.
Page 335: Tire Spinning
STARTING AND OPERATING 333 Tire Spinning Tread Wear Indicators When stuck in mud, sand, snow, or ice conditions, do not Tread wear indicators are in the original equipment tires spin your vehicle’s wheels faster than 30 mph (48 km/h) to help you in determining when your tires should be or for longer than 30 seconds continuously without replaced.
Page 336: Life Of Tire
334 STARTING AND OPERATING These indicators are molded into the bottom of the tread WARNING! grooves. They will appear as bands when the tread depth becomes 1/16 in (2 mm). When the tread is worn to the Tires and spare tire should be replaced after six years, tread wear indicators, the tire should be replaced.
Page 337 STARTING AND OPERATING 335 Information” placard for the size designation of your tire. WARNING! The Load Index and Speed Symbol for your tire will be • Do not use a tire, wheel size or rating other than found on the original equipment tire sidewall. See the Tire Sizing Chart example found in the Tire Safety that specified for your vehicle.
Page 338: Supplemental Tire Pressure Information - If Equipped
336 STARTING AND OPERATING SUPPLEMENTAL TIRE PRESSURE INFORMATION WARNING! (Continued) — IF EQUIPPED • Never use a tire with a smaller load index or A light load vehicle condition is defined as two passen- capacity, other than what was originally equipped gers [150 lbs (68 kg) each] plus 200 lbs (91 kg) of cargo.
Page 339 STARTING AND OPERATING 337 CAUTION! (Continued) CAUTION! (Continued) • Because of limited chain clearance between tires • Observe the tire chain manufacturer’s instructions and other suspension components, it is important on method of installation, operating speed, and that only chains in good condition are used. Bro- conditions for usage.
Page 340: Snow Tires
338 STARTING AND OPERATING • On 4X2 vehicles, class “U” snow chains are permitted SNOW TIRES on the rear wheels only of vehicles equipped with Some areas of the country require the use of snow tires LT245/70R17, LT265/70R17, and LT235/80R17 size during the winter.
Page 341: Tire Rotation Recommendations
STARTING AND OPERATING 339 While studded tires improve performance on ice, skid Refer to the “Maintenance Schedule” for the proper and traction capability on wet or dry surfaces may be maintenance intervals. More frequent rotation is permis- poorer than that of non-studded tires. Some states pro- sible if desired.
Page 342: Dual Rear Wheels
340 STARTING AND OPERATING NOTE: On Canadian vehicles only, if your vehicle is The tires used on dual wheel assemblies should be equipped with All-Season type tires on the front and matched for wear to prevent overloading one tire in a set. On/Off Road type tires mounted on the rear, do not use To check if tires are even, lay a straight edge across all a front to back rotation pattern.
Page 343: Fuel Requirements
STARTING AND OPERATING 341 for optimum performance. The use of premium gasoline CAUTION! (Continued) is not recommended, as it will not provide any benefit • When replacing a flat, the spare tire may have to over regular gasoline in these engines. be remounted on the rim or installed at a different Light spark knock at low engine speeds is not harmful to location to maintain the correct placement of the...
Page 344: Reformulated Gasoline
342 STARTING AND OPERATING Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner burning gasoline referred to as “Reformulated Gasoline” Do not use gasolines containing Methanol or E-85 Reformulated gasolines contain oxygenates, and are spe- Ethanol. Use of these blends may result in starting cifically blended to reduce vehicle emissions and im- and drivability problems and may damage critical prove air quality.
Page 345: Mmt In Gasoline
STARTING AND OPERATING 343 If a Non-FFV vehicle is inadvertently fueled with E-85 More extensive repairs will be required for prolonged fuel, the engine will have some or all of these symptoms: exposure to E-85 fuel. • operate in a lean mode MMT In Gasoline MMT is a manganese containing metallic additive that is •...
Page 346: Materials Added To Fuel
344 STARTING AND OPERATING Materials Added To Fuel CAUTION! (Continued) All gasolines sold in the United States are required to • An out-of-tune engine, or certain fuel or ignition contain effective detergent additives. Use of additional malfunctions, can cause the catalytic converter to detergents or other additives is not needed under normal overheat.
Page 347: Carbon Monoxide Warnings
STARTING AND OPERATING 345 Carbon Monoxide Warnings CAUTION! (Continued) • The use of fuel additives which are now being WARNING! sold as octane enhancers is not recommended. Carbon monoxide (CO) in exhaust gases is deadly. Many of these products contain high concentra- Follow the precautions below to prevent carbon tions of methanol.
Page 348: Adding Fuel
346 STARTING AND OPERATING WARNING! (Continued) CAUTION! (Continued) • Guard against carbon monoxide with proper • A poorly fitting gas cap may cause the MIL to turn maintenance. Have the exhaust system inspected • To avoid fuel spillage and overfilling, do not “top every time the vehicle is raised.
Page 349: Loose Fuel Filler Cap Message
STARTING AND OPERATING 347 NOTE: Tighten the gas cap 1/4 turn until you hear one Refer to “Electronic Vehicle Information Center (EVIC) in click. This is an indication that the cap is properly “Understanding Your Instrument Panel” for further in- tightened.
Page 350 The payload of a vehicle is defined as the allowable load Rim Size weight a truck can carry, including the weight of the This is the rim size that is appropriate for the tire size driver, all passengers, options and cargo.
Page 351 STARTING AND OPERATING 349 Curb Weight or rear axles has been exceeded but the total load is The curb weight of a vehicle is defined as the total weight within the specified GVWR. If so, weight must be shifted of the vehicle with all fluids, including vehicle fuel, at full from front to rear or rear to front as appropriate until the capacity conditions, and with no occupants or cargo specified weight limitations are met.
Page 352: Trailer Towing
350 STARTING AND OPERATING TRAILER TOWING exceed the GVWR. Refer to “Vehicle Loading/Vehicle In this section you will find safety tips and information Certification Label” in “Starting and Operating” for on limits to the type of towing you can reasonably do further information.
Page 353 These kind of hitches are the most popular on the market today and...
Page 354 Weights (TW) and may be required depending on vehicle coupling that mounts over the rear axle of the tow vehicle and trailer configuration/loading to comply with GAWR in the truck bed. It connects a vehicle and fifth-wheel requirements. trailer with a coupling king pin.
Page 355: Trailer Hitch Classification
Max. Trailer Hitch Industry which attaches to a ball mounted in the bed of a pickup Standards truck. The coupling arm connects to the hitch mounted Class I - Light Duty 2,000 lbs (907 kg) over the rear axle in the truck bed.
Page 356: Trailer Towing Weights (Maximum Trailer Weight Ratings)
354 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) Refer to the following website address for your specific vehicle’s “BASE WEIGHTS/GCW/PAYLOAD/TRAILER TOW” information and restrictions based on the type of trailer hitch: • http://www.dodge.com/bodybuilder Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.
Page 357: Towing Requirements
STARTING AND OPERATING 355 NOTE: Remember that everything put into or on the CAUTION! (Continued) trailer adds to the load on your vehicle. Also, additional • Then, during the first 500 miles (805 km) that a factory-installed options or dealer-installed options must trailer is towed, do not drive over 50 mph be considered as part of the total load on your vehicle.
Page 358 356 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Make certain that the load is secured in the trailer • Vehicles with trailers should not be parked on a and will not shift during travel. When trailering grade. When parking, apply the parking brake on cargo that is not fully secured, dynamic load shifts the tow vehicle.
Page 359 STARTING AND OPERATING 357 Towing Requirements – Tires replacement procedures. Replacing tires with a higher load carrying capacity will not increase the vehicle’s • Do not attempt to tow a trailer with less than the full GVWR and GAWR limits. size spare tire.
Page 360 358 STARTING AND OPERATING CAUTION! WARNING! (Continued) • Towing any trailer will increase your stopping If the trailer weighs more than 1,000 lbs (454 kg) distance. When towing you should allow for addi- loaded, it should have its own brakes and they tional space between your vehicle and the vehicle should be of adequate capacity.
Page 361 STARTING AND OPERATING 359 This display may also be used to display diagnostic information, if needed. • SC — Short Circuit to Ground • Sb — Short to Battery • CF — Controller Fault – If this message appears on the display, see your authorized dealer.
Page 362 360 STARTING AND OPERATING The trailer and the vehicle’s brake lamps will come on GAIN setting can be increased to a maximum of 10 or when either vehicle braking or manual trailer brakes are decreased to a minimum of 0 (no trailer braking). applied.
Page 363 STARTING AND OPERATING 361 3. When a trailer with electric brakes is plugged in, the EVIC Display Messages GAIN setting will illuminate. The trailer brake control interacts with the Electronic Vehicle Information Center (EVIC). Display messages, 4. Use the GAIN adjustment (+/-) buttons to increase or along with a single chime, will be displayed when a decrease the GAIN setting to the desired starting point.
Page 364: Towing Tips
362 STARTING AND OPERATING Towing Requirements – Trailer Lights And Wiring WARNING! Whenever you pull a trailer, regardless of the trailer size, stop lights and turn signals on the trailer are required for The ITBM module has been designed and verified motoring safety.
Page 365 STARTING AND OPERATING 363 Automatic Transmission Tow/Haul The “DRIVE” range can be selected when towing. How- To reduce potential for automatic transmission overheat- ever, if frequent shifting occurs while in this range, select ing, turn the “TOW/HAUL” feature ON when driving in “TOW/HAUL”...
Page 366: Snowplow
364 STARTING AND OPERATING Cooling System Dodge Body Builders Guide. See your authorized dealer, To reduce potential for engine and transmission over- installer or snowplow manufacturer for this information. heating, take the following actions: There are unique electrical systems that must be con- nected to properly assure operator safety and prevent −...
Page 367: Before Plowing
Vehicle front end wheel alignment was set to specifica- Builders Guide. tions at the factory without consideration for the weight 1. The maximum number of occupants in the truck of the plow. Front end toe-in should be checked and reset should not exceed two.
Page 368: Over The Road Operation With Snowplow Attached
366 STARTING AND OPERATING if necessary at the beginning and end of the snowplow Operating Tips season. This will help prevent uneven tire wear. Under ideal snow plowing conditions, 20 mph (32 km/h) should be maximum operating speed. The operator The blade should be lowered whenever the vehicle is should be familiar with the area and surface to be parked.
Page 369: General Maintenance
STARTING AND OPERATING 367 • Vehicles with automatic transmissions should use 4L General Maintenance Snowplows should be maintained in accordance with the range when plowing deep or heavy snow for extended plow manufacturer’s instructions. periods of time to avoid transmission overheating. •...
Page 370: Recreational Towing (Behind Motorhome, Etc.)
368 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF The Two-Wheel Four-Wheel Drive Models Ground Drive Models See Instructions • Automatic transmission in PARK • Manual transmission in gear Flat Tow NONE NOT ALLOWED (NOT in NEUTRAL)
Page 371: Recreational Towing - Two-Wheel Drive Models
STARTING AND OPERATING 369 Recreational Towing – Two-Wheel Drive Models 6. Install a suitable clamping device, designed for tow- DO NOT flat tow this vehicle. Damage to the drivetrain ing, to secure the front wheels in the straight position. will result. CAUTION! Recreational towing (for two-wheel drive models) is •...
Page 372 370 STARTING AND OPERATING must be placed in gear (NOT in NEUTRAL) for recre- CAUTION! (Continued) ational towing. Refer to the following for the proper • Before recreational towing, perform the procedure transfer case NEUTRAL (N) shifting procedure for your outlined under “Shifting Into NEUTRAL (N)”...
Page 373 STARTING AND OPERATING 371 Shifting Into NEUTRAL (N) – Manual Shift CAUTION! Transfer Case (If Equipped) Use the following procedure to prepare your vehicle for It is necessary to follow these steps to be certain that recreational towing. the transfer case is fully in NEUTRAL (N) before recreational towing to prevent damage to internal WARNING! parts.
Page 374 372 STARTING AND OPERATING 8. Release the brake pedal (and clutch pedal on manual 13. Remove the key fob from the ignition switch. transmissions) for five seconds and ensure that there is 14. Attach the vehicle to the tow vehicle using a suitable no vehicle movement.
Page 375 STARTING AND OPERATING 373 6. Shift the transfer case lever to the desired position. Shifting Into NEUTRAL – Electronic Shift Transfer Case (If Equipped) NOTE: When shifting out of transfer case NEUTRAL Use the following procedure to prepare your vehicle for (N), turning the engine OFF may be required to avoid recreational towing: gear clash.
Page 376 374 STARTING AND OPERATING light will blink while the shift is in progress. The light CAUTION! will stop blinking (stay on solid) when the shift to NEUTRAL is complete. It is necessary to follow these steps to be certain that the transfer case is fully in NEUTRAL before recre- 7.
Page 377 STARTING AND OPERATING 375 • Steps 1 through 5 are requirements that must be met 14. Shift the transmission into PARK or place manual transmission in gear (not in Neutral). prior to pressing the NEUTRAL button, and must continue to be met until the shift has been completed. CAUTION! If any of these requirements are not met prior to pressing the NEUTRAL button or are no longer met...
Page 378 376 STARTING AND OPERATING Shifting Out Of NEUTRAL – Electronic Shift 8. After the NEUTRAL button has been released, the Transfer Case (If Equipped) transfer case will shift to the position indicated by the Use the following procedure to prepare your vehicle for selector switch.
Page 379 STARTING AND OPERATING 377 • The ignition switch must be in the ON/RUN position 15. Shift the transmission into gear, release the brake pedal (and clutch pedal on manual transmissions), and for a transfer case shift to take place and for the check that the vehicle operates normally.
Page 381: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....380 Jump-Starting Procedure ....394 Jacking And Tire Changing .
Page 382: Hazard Warning Flashers
380 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS JACKING AND TIRE CHANGING The Hazard Warning flasher switch is located on the WARNING! upper switch bank just below the radio. • Do not attempt to change a tire on the side of the Press the switch to turn on the Hazard Warning flasher.
Page 383: 3500 Models - If Equipped
WHAT TO DO IN EMERGENCIES 381 WARNING! (Continued) • The jack is designed to use as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.
Page 384: Preparations For Jacking
382 WHAT TO DO IN EMERGENCIES Preparations For Jacking WARNING! 1. Park the vehicle on a firm, level surface. Avoid ice or After using the jack and tools, always reinstall them slippery areas. in the original carrier and location. While driving you may experience abrupt stopping, rapid accelera- WARNING! tion, or sharp turns.
Page 385: Jacking Instructions
WHAT TO DO IN EMERGENCIES 383 6. Block both the front and rear of the WARNING! (Continued) wheel diagonally opposite the jacking • Always park on a firm, level surface as far from position. For example, if the right front the edge of the roadway as possible before raising wheel is being changed, block the left the vehicle.
Page 386 384 WHAT TO DO IN EMERGENCIES WARNING! (Continued) CAUTION! • If working on or near a roadway, be extremely Do not attempt to raise the vehicle by jacking on careful of motor traffic. locations other than those indicated in the Jacking •...
Page 387 Before raising the wheel off the ground, make sure that tube to the jack and connect the drive tube to the the jack will not damage surrounding truck parts and extension tube. Securely place the jack under the sway adjust the jack position as required.
Page 388 386 WHAT TO DO IN EMERGENCIES 4. By rotating the wheel wrench clockwise, raise the 6. Using the wheel wrench, finish tightening the nuts vehicle until the wheel just clears the surface. using a crisscross pattern. The correct nut tightness is 135 ft lbs (183 N·m) torque for single rear wheel (SRW) WARNING! models and 145 ft lbs (197 N·m) for dual rear wheel...
Page 389 WHAT TO DO IN EMERGENCIES 387 8. Lower the jack to its fully closed position. If the jack CAUTION! will not lower by turning the dial (thumbwheel) by hand, it may be necessary to use the jack drive tube in order to Use extreme caution when removing the front and lower the jack.
Page 390 388 WHAT TO DO IN EMERGENCIES models use the blade on the end of the lug wrench to pry Replace the wheel skins first using a rubber mallet. When the caps off. The wheel skin can now be removed. replacing the hub caps, tilt the cap retainer over the lug nut bolt circle and strike the high side down with a CAUTION! rubber mallet.
Page 391 WHAT TO DO IN EMERGENCIES 389 Slots in the wheels will assist in properly orienting the inner and outer wheels. Align these slots when assem- bling the wheels for best access to the tire valve on the inner wheel. The tires of both dual wheels must be completely off the ground when tightening to insure wheel centering and maximum wheel clamping.
Page 392 390 WHAT TO DO IN EMERGENCIES These dual rear wheels should be tightened as follows: Tightening Pattern (10 Studs) Tightening Pattern (8 Studs)
Page 393 WHAT TO DO IN EMERGENCIES 391 1. Tighten the wheel nuts in the numbered sequence to a Wheel Nut Torque snug fit. All wheel nuts should be tightened occasionally to elimi- nate the possibility of wheel studs being sheared or the 2.
Page 394: Hoisting
12 Volts or damage to the battery, starter motor, alternator or electrical system may occur. Never use a floor jack directly under the differential housing of a loaded truck or damage to your vehicle may result. WARNING! Do not attempt jump-starting if the battery is frozen.
Page 395: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 393 Preparations For Jump-Start WARNING! The battery in your vehicle is located in the front of the • Take care to avoid the radiator cooling fan when- engine compartment, behind the left headlight assembly. ever the hood is raised. It can start anytime the NOTE: The positive battery post is covered with a ignition switch is on.
Page 396: Jump-Starting Procedure
394 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park CAUTION! the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. Failure to follow these procedures could result in damage to the charging system of the booster vehicle WARNING! or the discharged vehicle.
Page 397 WHAT TO DO IN EMERGENCIES 395 8. Disconnect the opposite end of the positive (+) jumper WARNING! cable from the positive (+) post of the booster battery. Do not connect the cable to the negative post (-) of the 9. Disconnect the positive (+) end of the jumper cable discharged battery.
Page 398: Freeing A Stuck Vehicle
396 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE CAUTION! (Continued) If the vehicle becomes stuck in snow, sand, or mud, it can • When “rocking” a stuck vehicle by moving be- often be moved by a rocking motion. Move the shift lever tween DRIVE/1st and REVERSE, do not spin the rhythmically between DRIVE/1st and REVERSE while wheels faster than 15 mph (24 km/h), or drivetrain...
Page 399: Emergency Tow Hooks - If Equipped
EMERGENCY TOW HOOKS — IF EQUIPPED vehicle stranded off-road. Do not use tow hooks for Your vehicle may be equipped with emergency tow tow truck hookup or highway towing. You could hooks. damage your vehicle. NOTE: For off-road recovery, it is recommended to use both of the front tow hooks to minimize the risk of damage to the vehicle.
Page 400: Shift Lever Override
398 WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: 1. Firmly set the parking brake. 2.
Page 401: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES 399 TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial wrecker service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described under “Recreational Towing”...
Page 402: Towing Without The Ignition Key Fob
Do not attempt to use sling type equipment when ment manufacturer’s instructions. Use of safety chains is towing. When securing the vehicle to a flat bed truck, mandatory. Attach a tow bar or other towing device to do not attach to front or rear suspension components.
Page 403: Two-Wheel Drive Models
WHAT TO DO IN EMERGENCIES 401 Two-Wheel Drive Models If the transmission is not operable, or the vehicle must be The manufacturer recommends towing your vehicle with towed faster than 30 mph (48 km/h) or farther than all four wheels OFF the ground using a flatbed. 15 miles (24 km), tow with the rear wheels OFF the ground.
Page 404: Four-Wheel Drive Vehicles
402 WHAT TO DO IN EMERGENCIES Four-Wheel Drive Vehicles CAUTION! The manufacturer recommends towing with all wheels • Front or rear wheel lifts should not be used. OFF the ground. Acceptable methods are to tow the vehicle on a flatbed or with one end of vehicle raised and Internal damage to the transmission or transfer the opposite end on a towing dolly.
Page 405: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 5.7L ... . . 405 Engine Oil Filter ..... 412 Onboard Diagnostic System (OBD II) .
Page 406 404 MAINTAINING YOUR VEHICLE Exhaust System ..... 419 Replacement Bulbs ....446 Cooling System .
Page 407: Engine Compartment - 5.7L
MAINTAINING YOUR VEHICLE 405 ENGINE COMPARTMENT — 5.7L 1 — Air Cleaner Filter 7 — Washer Fluid Reservoir 2 — Automatic Transmission Dipstick 8 — Integrated Power Module (Fuses) 3 — Engine Oil Fill 9 — Power Steering Fluid Reservoir 4 —...
Page 408: Onboard Diagnostic System (Obd Ii)
406 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM (OBD II) CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.
Page 409: Emissions Inspection And Maintenance Programs
MAINTAINING YOUR VEHICLE 407 the SELECT button to turn off the message. If the Normally, the OBD II system will be ready. The OBD II problem continues, the message will appear the next time system may not be ready if your vehicle was recently the vehicle is started.
Page 410: Replacement Parts
408 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will system to update. A recheck with the above test routine happen: may then indicate that the system is now ready. a. The MIL will flash for about 10 seconds and then Regardless of whether your vehicle’s OBD II system is return to being fully illuminated until you turn OFF ready or not, if the MIL is illuminated during normal...
Page 411: Dealer Service
MAINTAINING YOUR VEHICLE 409 DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
Page 412: Engine Oil
410 MAINTAINING YOUR VEHICLE The best time to check the engine oil level is about five CAUTION! (Continued) minutes after a fully warmed up engine is shut off. • Your vehicle has been built with improved fluids Checking the oil while the vehicle is on level ground will that protect the performance and durability of improve the accuracy of the oil level readings.
Page 413 MAINTAINING YOUR VEHICLE 411 Change Engine Oil American Petroleum Institute (API) Engine Oil The oil change indicator system will remind you that it is Identification Symbol time to take your vehicle in for scheduled maintenance. This symbol means that the oil has Refer to the “Maintenance Schedule”...
Page 414: Engine Oil Filter
412 MAINTAINING YOUR VEHICLE Engine Oil Viscosity (SAE Grade) Materials Added To Engine Oil SAE 5W-20 engine oil is recommended for all operating The manufacturer strongly recommends against the ad- temperatures. This engine oil improves low temperature dition of any additives (other than leak detection dyes) to starting and vehicle fuel economy.
Page 415: Engine Air Cleaner Filter
MAINTAINING YOUR VEHICLE 413 Engine Oil Filter Selection WARNING! The manufacturer’s engines have a full-flow type oil filter. Use a filter of this type for replacement. The quality The air induction system (air cleaner, hoses, etc.) can of replacement filters varies considerably. Only high- provide a measure of protection in the case of engine quality filters should be used to assure most efficient backfire.
Page 416: Maintenance-Free Battery
414 MAINTAINING YOUR VEHICLE Maintenance-Free Battery WARNING! (Continued) Your vehicle is equipped with a maintenance-free battery. • Battery gas is flammable and explosive. Keep You will never have to add water, nor is periodic main- flame or sparks away from the battery. Do not use tenance required.
Page 417: Air Conditioner Maintenance
MAINTAINING YOUR VEHICLE 415 Air Conditioner Maintenance CAUTION! For best possible performance, your air conditioner • It is essential when replacing the cables on the should be checked and serviced by an authorized dealer at the start of each warm season. This service should battery that the positive cable is attached to the include cleaning of the condenser fins and a performance positive post and the negative cable is attached to...
Page 418: Front Prop Shaft Lubrication - Four-Wheel Drive Models
416 MAINTAINING YOUR VEHICLE NOTE: Use only manufacturer approved A/C System WARNING! Sealers, Stop Leak Products, Seal Conditioners, Compres- • Use only refrigerants and compressor lubricants sor Oil, or Refrigerants. approved by the manufacturer for your air condi- Refrigerant Recovery And Recycling tioning system.
Page 419: Body Lubrication
MAINTAINING YOUR VEHICLE 417 Body Lubrication amount of a high quality lubricant such as MOPAR Locks and all body pivot points, including such items as Lock Cylinder Lubricant or equivalent directly into the seat tracks, door hinge pivot points and rollers, liftgate, lock cylinder.
Page 420: Adding Washer Fluid
418 MAINTAINING YOUR VEHICLE performance of blades may be present with chattering, The washer fluid reservoir will hold a full gallon of fluid marks, water lines or wet spots. If any condition is when the Low Washer Fluid Light illuminates. present please proceed to clean wiper blades with humid WARNING! cloth removing any debris that may be affecting its...
Page 421: Exhaust System
MAINTAINING YOUR VEHICLE 419 Exhaust System WARNING! The best protection against carbon monoxide entry into • Exhaust gases can injure or kill. They contain the vehicle body is a properly maintained engine exhaust system. carbon monoxide (CO), which is colorless and odorless.
Page 422 420 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- • The catalytic converter requires the use of un- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst leaded fuel only.
Page 423: Cooling System
MAINTAINING YOUR VEHICLE 421 To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in You or others can be badly burned by hot coolant or motion.
Page 424 422 MAINTAINING YOUR VEHICLE Check the coolant recovery bottle tubing for brittle rub- Refer to the “Maintenance Schedule” for the proper ber, cracking, tears, cuts and tightness of the connection maintenance intervals. at the bottle and radiator. Inspect the entire system for Selection Of Coolant leaks.
Page 425 MAINTAINING YOUR VEHICLE 423 Please review these recommendations for using Hybrid CAUTION! (Continued) Organic Additive Technology (HOAT) engine coolant • Do not use water alone or alcohol-based engine (antifreeze). When adding engine coolant (antifreeze): coolant (antifreeze) products. Do not use addi- •...
Page 426 424 MAINTAINING YOUR VEHICLE Please note that it is the owner’s responsibility to main- WARNING! tain the proper level of protection against freezing ac- • The warning words “DO NOT OPEN HOT” on cording to the temperatures occurring in the area where the vehicle is operated.
Page 427 MAINTAINING YOUR VEHICLE 425 Disposal Of Used Coolant To check the coolant level: Used ethylene glycol-based engine coolant (antifreeze) is 1. Open the coolant reservoir. a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community.
Page 428 426 MAINTAINING YOUR VEHICLE 2. Lift and remove the plastic dipstick from the reservoir of this. As long as the engine operating temperature is neck. satisfactory, the coolant bottle need only be checked once a month. When additional engine coolant (antifreeze) is needed to maintain the proper level, it should be added to the coolant bottle.
Page 429: Brake System
MAINTAINING YOUR VEHICLE 427 • Do not overfill the coolant recovery bottle. • Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the • Check engine coolant (antifreeze) freeze point in the condenser clean, also.
Page 430 428 MAINTAINING YOUR VEHICLE The brake master cylinder has a translucent plastic WARNING! reservoir. On the outboard side of the reservoir, there is a “MAX” dot and an “MIN” dot. The fluid level must be Riding the brakes can lead to brake failure and kept within these two dots.
Page 431 MAINTAINING YOUR VEHICLE 429 WARNING! WARNING! (Continued) • To avoid contamination from foreign matter or • Use only manufacturer’s recommended brake moisture, use only new brake fluid or fluid that fluid. Refer to “Fluids, Lubricants, and Genuine has been in a tightly closed container. Keep the Parts”...
Page 432: Rear Axle And 4X4 Front Driving Axle Fluid Level
430 MAINTAINING YOUR VEHICLE Drain And Refill WARNING! (Continued) On 4500/5500 vehicles, remove the lower bolt to drain • Do not allow petroleum based fluid to contami- the axle fluid. nate the brake fluid. Brake seal components could be damaged, causing partial or complete brake failure.
Page 433: Transfer Case
MAINTAINING YOUR VEHICLE 431 Lubricant Selection Transfer Case Refer to “Fluids, Lubricants, and Genuine Parts” in Drain And Refill “Maintaining Your Vehicle” for further information. Refer to the “Maintenance Schedule” for the proper NOTE: The presence of water in the gear lubricant will maintenance intervals.
Page 434: Automatic Transmission
432 MAINTAINING YOUR VEHICLE Automatic Transmission CAUTION! (Continued) Selection Of Lubricant • Using a transmission fluid other than the manu- It is important that the proper lubricant is used in the facturer’s recommended fluid may cause deterio- transmission to assure optimum transmission perfor- ration in transmission shift quality and/or torque mance.
Page 435 MAINTAINING YOUR VEHICLE 433 Fluid Level Check 2. The vehicle must be on level ground. The fluid level should be checked when the engine is 3. Fully apply the parking brake and press the brake fully warmed up and the fluid in the transmission is at pedal.
Page 436 434 MAINTAINING YOUR VEHICLE NOTE: If it is necessary to check the transmission below To prevent dirt and water from entering the transmission the operating temperature, the fluid level should be after checking or replenishing fluid, make certain that the between the two “COLD”...
Page 437: Appearance Care And Protection From Corrosion
MAINTAINING YOUR VEHICLE 435 Appearance Care And Protection From Corrosion The most common causes are: • Road salt, dirt and moisture accumulation. Protection Of Body And Paint From Corrosion Vehicle body care requirements vary according to geo- • Stone and gravel impact. graphic locations and usage.
Page 438 436 MAINTAINING YOUR VEHICLE • Use a high quality cleaner wax, such as MOPAR Special Care Cleaner Wax or equivalent to remove road film, stains • If you drive on salted or dusty roads or if you drive and to protect your paint finish. Take care never to near the ocean, hose off the undercarriage at least once scratch the paint.
Page 439 MAINTAINING YOUR VEHICLE 437 • If you carry special cargo such as chemicals, fertilizers, CAUTION! de-icer salt, etc., be sure that such materials are well packaged and sealed. Do not use scouring pads, steel wool, a bristle brush, or metal polishes. Do not use oven cleaner. These •...
Page 440 438 MAINTAINING YOUR VEHICLE • For tough stains, apply MOPAR Total Clean or Your leather upholstery can be best preserved by regular equivalent, or a mild soap solution to a clean, damp cleaning with a damp soft cloth. Small particles of dirt cloth and remove stain.
Page 441 MAINTAINING YOUR VEHICLE 439 Cleaning Headlights cleaner. Use caution when cleaning the inside rear win- Your vehicle is equipped with plastic headlights and fog dow equipped with electric defrosters or the right rear lights (if equipped) that are lighter and less susceptible to quarter window equipped with the radio antenna.
Page 442: Fuses
440 MAINTAINING YOUR VEHICLE Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. If the belts need cleaning, use a mild soap solution or lukewarm water.
Page 443 MAINTAINING YOUR VEHICLE 441 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 30 Amp Diesel Powertrain 30 Amp Transfer Case Module Pink Control Module – If Pink Equipped 30 Amp Rear Defroster 25 Amp Driver Door Node Pink Natural 60 Amp...
Page 444 442 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 30 Amp Front Wiper Ground/ 20 Amp Front Heated Seat & Pink Low/High Yellow Steering Wheel 20 Amp Washer Control 20 Amp Rear Heated Seats Blue Yellow 25 Amp...
Page 445 MAINTAINING YOUR VEHICLE 443 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 20 Amp Main #2 Instrument 15 Amp Center Stop Lamp Yellow Cluster/Wireless Con- Blue trol Module/ITM/ 25 Amp Automatic Shutdown Siren/Multifunction Natural 1 and 2 Switch (Steering Col- 15 Amp Instrument Cluster...
Page 446 444 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 10 Amp Driver’s Door Switch 10 Amp Park Assist Module/ Climate Control Sys- tem Module/IR 10 Amp Ignition Switch Sensor/Compass Module 15 Amp Powertrain Control 15 Amp Left Front &...
Page 447: Vehicle Storage
MAINTAINING YOUR VEHICLE 445 VEHICLE STORAGE CAUTION! If you are storing your vehicle for more than 21 days, we • When installing the totally integrated power mod- recommend that you take the following steps to mini- mize the drain on your vehicle’s battery: ule cover, it is important to ensure the cover is properly positioned and fully latched.
Page 448: Replacement Bulbs
446 MAINTAINING YOUR VEHICLE NOTE: NOTE: For lighted switches, see your authorized dealer • When reinstalling the IOD fuse push firmly until fully for replacement instructions. seated; the gauges in the instrument cluster will do a All of the inside bulbs are brass or glass-wedge base. full sweep when the ignition switch is turned to the Aluminum base bulbs are not approved.
Page 449: Bulb Replacement
MAINTAINING YOUR VEHICLE 447 BULB REPLACEMENT Dual Or Quad Headlamp/Front Park And Turn Signal – If Equipped 1. Open the hood. 2. Disconnect and isolate the negative battery cable. 3. Remove the four plastic push-in fasteners that secure the upper radiator seal to the grille support and both fender ledges.
Page 450 448 MAINTAINING YOUR VEHICLE 8. Reach through the access hole of the wheel house 10. Disconnect electrical connectors. splash shield and lift the slide lock upward far enough to 11. Replace bulb(s) as necessary. disengage it from the lock post on the back of the front lamp unit housing.
Page 451: Fog Lamps - If Equipped
MAINTAINING YOUR VEHICLE 449 Fog Lamps – If Equipped Center High-Mounted Stoplamp (CHMSL) With Cargo Lamp 1. Reach under and behind the front bumper to access the back of the front fog lamp housing. 1. Remove the two screws holding the housing/lens to the body as shown.
Page 452 450 MAINTAINING YOUR VEHICLE 2. Separate the connector holding the housing and wir- 3. Turn the desired bulb socket ⁄ turn and remove the ing harness to the body. socket and bulb from housing. 4. Pull the desired bulb straight from the socket.
Page 453: Cab Top Clearance Lamps - If Equipped
MAINTAINING YOUR VEHICLE 451 Cab Top Clearance Lamps – If Equipped CAUTION! 1. Remove the two screws from the top of the lamp. Do not contaminate the bulb glass by touching it with your fingers or by allowing it to contact other oily surfaces.
Page 454 452 MAINTAINING YOUR VEHICLE 2. Rotate the socket ⁄ turn and pull it from the lamp 3. Pull the bulb straight from it’s socket and replace. assembly.
Page 455: Fluid Capacities
MAINTAINING YOUR VEHICLE 453 FLUID CAPACITIES U.S. Metric Fuel (Approximate) Standard Rear Tank 52 Gallons 197 Liters Optional Midship Tank 22 Gallons 83 Liters Engine Oil with Filter 5.7L Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters Cooling System 5.7L Engine (MOPAR Antifreeze/Coolant 5 18.7 Quarts 17.7 Liters...
Page 456: Fluids, Lubricants And Genuine Parts
454 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 5–Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. Engine Oil – 5.7L Engine Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 457: Chassis
MAINTAINING YOUR VEHICLE 455 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission (5.7L En- MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed gine Only) ATF+4 product. Transfer Case MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Front and Rear Axle Fluid (4500/ GL-5 SAE 75W-90 Synthetic (MS-9763) or equivalent.
Page 459 MAINTENANCE SCHEDULES CONTENTS Maintenance Schedule ....458 5.7L Gas Engine ..... 458 Required Maintenance Intervals .
Page 460 458 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE On Electronic Vehicle Information Center (EVIC) equipped vehicles, “Oil Change Due” will be displayed 5.7L Gas Engine in the EVIC and a single chime will sound, indicating that The Scheduled Maintenance services listed in this an oil change is necessary.
Page 461 MAINTENANCE SCHEDULES 459 NOTE: referring to the steps described under “Electronic Vehicle • The oil change indicator message will not monitor the Information Center (EVIC)/Oil Change Due” in “Under- time since the last oil change. Change your vehicles oil standing Your Instrument Panel” or under “Instrument if it has been 6 months since your last oil change even Cluster Description/Odometer/Trip Odometer”...
Page 462 460 MAINTENANCE SCHEDULES Once A Month At Each Oil Change • Check tire pressure and look for unusual wear or • Change the engine oil filter. damage. • Inspect the brake hoses and lines. • Inspect the battery and clean and tighten the terminals CAUTION! as required.
Page 463 MAINTENANCE SCHEDULES 461 8,000 Miles (13,000 km) or 16,000 Miles (26,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 464: Service Schedule
462 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 32,000 Miles (52,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 465 MAINTENANCE SCHEDULES 463 40,000 Miles (65,000 km) or 48,000 Miles (78,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 466 464 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56,000 miles (91 000 km). ❏...
Page 467 MAINTENANCE SCHEDULES 465 64,000 Miles (104,000 km) or 48 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 64,000 miles (104 000 km). ❏...
Page 468 466 MAINTENANCE SCHEDULES 72,000 Miles (117,000 km) or 80,000 Miles (130,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 469 MAINTENANCE SCHEDULES 467 88,000 Miles (143,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (143 000 km). ❏...
Page 470 468 MAINTENANCE SCHEDULES 96,000 Miles (156,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (156 000 km). ❏...
Page 471 MAINTENANCE SCHEDULES 469 104,000 Miles (169,000 km) or 112,000 Miles (182,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 472 470 MAINTENANCE SCHEDULES 120,000 Miles (195,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (195 000 km). ❏...
Page 473 MAINTENANCE SCHEDULES 471 128,000 Miles (208,000 km) or 96 Months Maintenance Service 136,000 Miles (221,000 km) or Schedule 102 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 474 472 MAINTENANCE SCHEDULES 144,000 Miles (234,000 km) or 108 Months Maintenance Service 152,000 Miles (247,000 km) or Schedule 114 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 475 MAINTENANCE SCHEDULES 473 WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 477: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Customer Assistance For The Hearing Or Vehicle......477 Speech Impaired (TDD/TTY) .
Page 478 476 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Traction Grades ..... 483 Quality Grades ......483 Temperature Grades .
Page 479: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 477 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 480: Chrysler Group Llc Customer Center
478 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer’s service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 Phone: (866) 726–4636 •...
Page 481: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 479 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 482: Warranty Information
480 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 483: In Canada
IF YOU NEED CONSUMER ASSISTANCE 481 If NHTSA receives similar complaints, it may open an In Canada investigation, and if it finds that a safety defect exists in If you believe that your vehicle has a safety defect, you a group of vehicles, it may order a recall and remedy should contact the Customer Service Department imme- campaign.
Page 484 482 IF YOU NEED CONSUMER ASSISTANCE • Service Manuals • Owner’s Manuals These comprehensive Service Manuals provide the These Owner’s Manuals have been prepared with the information that students and professional technicians assistance of service and engineering specialists to need in diagnosing/troubleshooting, problem solving, acquaint you with specific Chrysler Group LLC ve- maintaining, servicing, and repairing Chrysler Group hicles.
Page 485 IF YOU NEED CONSUMER ASSISTANCE 483 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
Page 486 484 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 487 INDEX...
Page 488 486 INDEX Adding Engine Coolant (Antifreeze) ..423 Alarm System (Security Alarm) ....18 Adding Fuel ......346 Alarm, Panic .
Page 489 INDEX 487 Automatic Transmission Brake System ......312,427 Adding Fluid ..... . . 433 Anti-Lock (ABS) .
Page 490 488 INDEX Carbon Monoxide Warning ....79,345 Clock ......225,234 Cargo Light .
Page 491 INDEX 489 Drain, Flush, and Refill ....422 Disabled Vehicle Towing ....399 Inspection .
Page 492 490 INDEX Emergency, In Case of Temperature Gauge ....190 Freeing Vehicle When Stuck ... . . 396 Enhanced Accident Response Feature .
Page 493 INDEX 491 Fluid Leaks ......82 Octane Rating ..... . . 341 Fluid Level Checks Requirements .
Page 494 492 INDEX Grocery Bag Retainer ..... 180 Switch ......148 Gross Axle Weight Rating .
Page 495 INDEX 493 Information Center, Vehicle ....204 Key, Sentry (Immobilizer) ....16 Inside Rearview Mirror .
Page 496 494 INDEX Automatic Headlights ....148 Interior ......151,164 Brake Warning .
Page 497 INDEX 495 Power Door ......30 Heated ......91 Lower Anchors and Tether for CHildren Memory .
Page 498 496 INDEX Oil, Engine ......410,454 Overhead Console ..... . . 163 Capacity .
Page 499 INDEX 497 Sliding Rear Window ....181 Recreational Towing ..... . 368 Steering .
Page 500 498 INDEX Restraints, Occupant ..... . 39 Front Seat ......40 Rotation, Tires .
Page 501 INDEX 499 Settings, Personal ......218 Speed Control (Cruise Control) ....160 Shift Lever Override .
Page 502 500 INDEX Supplemental Tire Pressure Information ..336 Dual ......340,388 Synthetic Engine Oil .
Page 503 INDEX 501 Tow Hooks, Emergency ....397 Transfer Case ......431 Towing .
Page 504 502 INDEX UCI Connector ......249 Water Uconnect™ (Hands-Free Phone) ....93 Driving Through .
Page 505 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehi- The antenna cable should be as short as practical and routed cle’s electronic system to provide immunity to radio frequency away from the vehicle wiring when possible. Use only fully signals.
Page 506 Chrysler Group LLC 2nd Edition 12DD43-126-AB Printed in U.S.A.
