Connection Panel

Connection panel of the Cell is located at the back of the device. It contains
power switch and the following sockets for connecting the Cell to approriate
devices and to the mains.
Socket
3 USB Sockets
USB B
Ethernet
DisplayPort
DVI-D
Mains
Purpouse
USB sockets are intended for peripherals of
the Cell (for example keyboard and mouse)
For control input
For control input
Display signal input
Display signal input
Power connection to the mains supply
