MultiTouch MT550W7 Specifications

l

Display Specifications

Multiuser interactive LCDs for single display applications
MT550W7 MultiTaction Cell 55" Full HD LCD Embedded Windows 7
Display Specifications
Display Technology
Display Size
Native Resolution
Display Colors
Display Active Area
Pixel Pitch
Pixel Response Time
Brightness
Contrast Ratio
Picture Frame Rate
Backlight
Viewing Angle
Touch Sensing Hardware
Touch technology
Tracking Speed
IR Source & cameras
IR Wavelength
Touch Surface
Display Safety Glass
Embedded Computer Specifications
CPU
RAM
Hard disk
Graphics
Operating system
Interfaces
Video Input
Control Input
Auxiliary input for keyboard,
mouse, and extra memory
Audio out
Power Connector
Electrical Specifications
Power Supply
Power Consumption
Touch Sensing Details
Tracking Software
Touch Input Types
Hand Recognition
Object Recognition
Number of Simultaneous Touch Inputs Unlimited
Number of Simultaneous Users
Positional accuracy
Relative accuracy
Touch Latency
Tracking Data Outputs/APIs
Operating System Support
Development Environment Support
MT550W7
TFT LCD
55'' 16:9 Wide
Full HD 1920 x 1080
16.7 million
1209 x 680 mm
0.63 x 0.63 mm
8 ms grey to grey
400 cd/m
2
4000 :1 typical
60 Hz
White LED Matrix Array
178°
Computer Vision Through Screen
Up to 200 fps
Integrated Backlight Emitter Camera modules
850 nm
Tempered 4 mm Optiwhite Glass covering
whole front surface
Intel® Core™ i7 Quad Core
8 GB
128 GB SSD
NVIDIA GTS450 1GB
Windows 7 64-bit ENG
DVI-D, DisplayPort*
Ethernet, USB B*
3 x USB A
RCA
IEC C14
100-240 VAC 50/60 Hz
490 W
Embedded MultiTaction Extensible Hybrid
Tracking Engine
Single finger, multiple fingers, single hand,
multiple hands and users, objects with opti-
cal markers. Click, hold and drag.
Each finger identified to certain hand
Supported with 2D fiducial markers
(1
Unlimited (separate hands)
(1
2 mm, directional compensation
Sub-pixel accuracy
10 ms typical
(2
Multi-Format Tracking Output: Low level C++,
TUIO, XML stream, Windows 7 Touch
Windows 7. (Linux, Mac OS X with external
computer)
Most major programming languages and
environments (e.g. MS Surface 2 SDK, Win 7
tools, TUIO-compatible systems)
(3
Software Development Kit
Stackability
Environment Specifications
Operating Temperature
Storage Temperature
Relative Humidity
Dimensions and Weight
Physical Dimensions
Bezel width
Weight
Color
Shipping Dimensions
Shipping Weight
Display Mounting
VESA Mount
Mounting positions
Cooling
Cooling system
Convection method
Noise Level
Miscellaneous
Agency Approvals
RoHS Compliant
Expected Life-time
Warranty
Sales Package Contents
Display Unit
Power Cords
Digital Video Cable
USB A-B Cable
Cat5e Ethernet Cable
Display stand
Protective/autocalibration sheet
Mounting rail bits
Warranty Card
Quick Start Guide
Product Manual
1) Practically limited by how many people can fit next to display array.
2) Measured from touch to processed tracking data output. Overall latency is more and
depends on the computer, operating system and application used.
3) See Cornerstone data sheet for more details.
4) Allow at least two hours for temperature normalization before switching on
Specifications subject to change without notice.
* Not operational. Reserved for future use.
Cornerstone SDK available for C++/OpenGL
(Windows 7, Linux, Mac OS X)
Up to 24 Cells can be connected to run a
single Multi-touch application with external
computer
0 to +35 degrees C
-10 to +60 degrees C
(4
Non-condensing 80%
1242 x 715 x 199 mm
16 mm (bottom & sides), 17 mm (top)
40 kg(+5 kg for two legs)
Black
tbd
tbd
800 x 400 mm, M8 screws
Vertical
Horizontal
Angled position
Table position
Forced Air
Low Noise Variable Speed Internal Fans
15 - 25 dBA
CE
Yes
Over 60,000 h
1 Year
1
5 m, EUR, US, GB
DVI-D 5 m
5 m
5 m
Table stand for landscape/portrait use
1
2 pcs
English version
