MultiTouch MT420S Specifications

l

Display Specifications

MT420S MultiTaction Cell 42" Full HD LCD Stackable
Display Specifications
Display Technology
Display Size
Native Resolution
Display Colors
Display Active Area
Pixel Pitch
Pixel Response Time
Brightness
Contrast Ratio
Picture Frame Rate
Backlight
Viewing Angle
Touch Sensing Hardware
Touch technology
Tracking Speed
IR Source & cameras
IR Wavelength
Touch Surface
Display Safety Glass
Interfaces
Video Input
Control Input
Auxiliary input for keyboard,
mouse, and extra memory
Power Connector
Electrical Specifications
Power Supply
Power Consumption
Touch Details
Tracking Software
Touch Input Types
Hand Recognition
Object Recognition
Number of Simultaneous Touch Inputs Unlimited
Number of Simultaneous Users
Positional accuracy
Relative accuracy
Touch Latency
Tracking Data Outputs/APIs
Operating System Support
Development Environment Support
Software Development Kit
Stackability
Environment Specifications
Operating Temperature
Storage Temperature
Relative Humidity
MT420S
TFT LCD
42'' 16:9 Wide
Full HD 1920 x 1080
16.7 million
930 x 523 mm
0.48 x 0.48 mm
8 ms grey to grey
400 cd/m
2
3500 :1 typical
60 Hz
White LED Matrix Array
178°
Computer Vision Through Screen
Up to 200 Hz
Integrated Backlight Emitter Camera modules
850 nm
Tempered 4 mm Optiwhite Glass covering
whole front surface
DVI-D, DisplayPort*
Ethernet, USB B*
3 x USB A
IEC C14
100-240 VAC 50/60 Hz
450 W
Embedded MultiTaction Extensible Hybrid
Tracking Engine
Single finger, multiple fingers, single hand,
multiple hands and users, objects with opti-
cal markers. Click, hold and drag
Each finger identified to certain hand
Supported with 2D fiducial markers
(1
Unlimited (separate hands)
(1
2 mm, directional compensation
Sub-pixel accuracy
10 ms typical (2
Multi-Format Tracking Output: Low level C++,
TUIO, XML stream, Windows 7 Touch
Windows 7, Linux, Mac OS X
Most major programming languages and
environments (MS surface 2 SDK, TUIO-
compatible systems)
(3
Cornerstone SDK available for C++/OpenGL
(Windows 7, Linux, Mac OS X)
Up to 24 Cells can be connected to run a
single Multi-touch application
0 to +35 degrees C
-10 to +60 degrees C (4
Non-condensing 80%
Dimensions and Weight
Physical Dimensions
Bezel width
Weight
Color
Shipping Dimensions
Shipping Weight
Display Mounting
VESA Mount
Mounting positions
Cooling
Cooling system
Convection method
Noise Level
Miscellaneous
Agency Approvals
RoHS Compliant
Expected Life-time
Warranty
Sales Package Contents
Display Unit
Power Cords
Digital Video Cable
USB A-B Cable
Cat5e Ethernet Cable
Display stand
Protective/autocalibration sheet
Mounting rail bits
Warranty Card
Quick Start Guide
Product Manual
1) Practically limited by how many people can fit next to display array.
2) Measured from touch to processed tracking data output. Overall latency is more and
depends on the computer, operating system and application used.
3) See Cornerstone data sheet for more details.
4) Allow at least two hours for temperature normalization before switching on.
Specifications subject to change without notice.
* Not operational. Reserved for future use.
965 x 557 x 200 mm
16 mm (bottom & sides), 17 mm (top)
32 kg (+5kg for two legs)
Black
tbd
tbd
600 x 200 mm, M8 screws
Vertical
Horizontal
Angled position
Table position
Display Array 2–24 Units
Symmetric or asymmetric layouts
Forced Air
Low Noise Variable Speed Internal Fans
15 - 25 dBA
CE
Yes
Over 60,000 h
1 Year
1
5 m, EUR, US, GB
DVI-D 5 m
5 m
5 m
Table stand for landscape/portrait use
1
2 pcs
English version
