- Page 1 InCellar OWNER’S MANUAL The Coolest Thing In Wine Storage...
- Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.
-
Page 3: Table Of Contents
Technical Assistance & Accessories ......Installation Terms and Conditions ......www.whisperkool.com | Page 1... -
Page 4: Quick Reference Guide
QUICK REFERENCE GUIDE Front / Side View Exhaust Collar Rear Intake Plenum Supply Probe Input Controller Power Inlet Return Fan Speed Control Condensate Pump Access Panel Rear / Side View Exhaust Plenum Drain Port Rear Intake Plenum Unattached Intake Plenum Register Power Inlet Filter... -
Page 5: Controller
Condenser Side Drainline 1/4” I.D Installation Partially Ducted System. Maximum Ducted feet: 15’ Thermostat Digital Control Display Temp. Delta 55°F Temperature differential between the cellar temperature and condenser air intake temperature. Warranty 2 year parts and labor www.whisperkool.com | Page 3... -
Page 6: Fan Speed & Specifications
FAN SPEED REFERENCE Your fan speed selection will depend on the amount of heat that needs to be removed from the cellar. Fan speed selection will depend on the cellar size, insulation factor, door seal and desired wine temperature. When initially installing the unit, set the fan speed to High setting for a quick chill down. -
Page 7: Introduction
Temperature Setting The WhisperKOOL InCellar unit can be set at any temperature within the acceptable wine-aging range of 50°F to 70°F. It is designed to cool up to 55°F cooler than the ambient temperature of the space to which it is exhausting. -
Page 8: Receiving & Inspecting The Unit
Tubing adapter Please leave the WhisperKOOL unit in its original box until you are ready for installation. This will allow you to move the product safely without damaging it. When you are ready to remove the product from the box, refer to the installation instructions. -
Page 9: Quick Start Guide
QUICK START GUIDE This guide is meant to serve as a quick reference for installation of the WhisperKOOL unit. The remainder of this Owner’s Manual will provide more detailed information and instructions. Upon receiving the WhisperKOOL unit: 1. Inspect the unit before installation. If damage is found, please contact your distributor or WhisperKOOL Customer Service at 1.800.343.9463 ext 799. -
Page 10: Preparing The Wine Cellar
How to Build a Wine Cellar Instructional Video WhisperKOOL has a construction tutorial available on line at our website: www.whisperkool.com. This tutorial will walk you through the steps of constructing a properly built wine cellar and the installation of our WhisperKOOL product line. Wall & Ceiling Framing Build wine cellar walls using standard 2x4 or 2x6 construction methods and ceiling joists following the guidelines of local and state codes in your area. - Page 11 In cases where glass doors are used and the room size is close to the recommended unit size, the next larger size WhisperKOOL should be used. This will compensate for the insulation loss due to the lower insulating rating of glass.
- Page 12 However, you must have a fresh air inlet as well. Note: If you are unsure about having adequate ventilation in your install location, please contact us to assess your specific installation at support@whisperkool.com or 1.800.343.9463. Ambient Temperature Factor The cooling unit has the ability to cool a wine cellar efficiently to 55°F as long as the ambient temperature of the...
-
Page 13: Pre-Installation
Remove Bottle Probe Electrical Needs The WhisperKOOL InCellar Unit requires a dedicated 115-volt 20-amp circuit. The unit draws a large amount of amps at initial start up. By designating a dedicated circuit breaker, you will guarantee the unit has enough power to run effectively. -
Page 14: Preparing The Installation Location
PREPARING THE INSTALLATION LOCATION Through-the-Wall Minimum Tools Needed Level Hammer Screwdriver Locate the desired installation location. Using a stud finder, locate the studs on either side. Place the unit against the wall to determine the height of the Intake Plenum on the rear of the Cooling Unit. -
Page 15: Installing The Cooling Unit
3. Position the Rear Intake Plenum through the cellar wall. This will provide the intake on the condenser side of the unit with fresh air. It is not required to place the cooling unit directly against the cellar wall, however, having the unit as close to the wall as possible is recommended. FIGURE 3 www.whisperkool.com | Page 13... - Page 16 INSTALLING THE UNIT From outside the cellar: Make sure to remove all insulation or debris left inside either Plenum prior to sliding the cooling unit against the cellar wall and connecting the Intake Plenum and the rear unattached Intake Plenum. 4.
-
Page 17: Installing The Drain Line
Device in (Figure 5). FIGURE 5 Failure to install the drain line voids the warranty. To prevent mold from growing, allow the drain line to hang above the water line. WRONG: Drain line is under water. www.whisperkool.com | Page 15... -
Page 18: Drain Line Pump System
DRAIN LINE PUMP SYSTEM CORRECT: Typical sequence of operation for correct Discharge Hose installation with Anti-Siphon Device 1. Drain pan fills with water which flows into reservoir. Intake hose between reservoir and pump is empty (filled with air). 2. Raising water lifts float, activating pump, which self primes by drawing water up from reservoir. During this period the pump is operating hot and dry and will click loudly. - Page 19 COMPLAINS OR THE PUMP RESERVOIR BREATHER TUBE RESERVOIR BREATHER TUBE EVENTUALLY FAILS. THIS CAN EASILY BE AVOIDED BY INSTALLING THE DISCHARGE HOSING CORRECTLY WITH AN ANTI-SIPHON DEVICE WHICH WILL EQUALIZE THE ATMOSPHERIC PRESSURE AND ELIMINATE THE SIPHONING. www.whisperkool.com | Page 17...
-
Page 20: Installing The Liquid Measuring Thermostat
LIQUID MEASURING THERMOSTAT The WhisperKOOL Series cooling units come equipped with a liquid temperature measuring thermostat. This incorporates the following advantages: Self-Calibrating Probe The probe contains a sensor chip, which actually communicates back and forth to the thermostat. This results in a consistent temperature setting and accuracy. -
Page 21: Ducted Installation Duct Work Option 1
Figure 5 below is an example that may be followed to create a facade to extend to the Ceiling using: 1/2” Plywood, 1/2” Drywall (2) 2x2, (2) 3x3. “ Measure the space between the cooling unit and the wall and add “ the distance to these dimensions for the total length. “ FIGURE 5 www.whisperkool.com | Page 19... -
Page 22: Duct Work Option 2
INSTALLING THE DUCT WORK Custom Duct Work Another Option that might be considered is building Insulated Custom Duct Work. Figure 6 below is an example that may be followed to create Insulated Custom Duct Work to extend to the attic using 1/2” Plywood, 1/2” Insulation Board and (24) Angle Brackets. -
Page 23: Ducting Overview
Use short and straight ductwork where possible. • Check that all fan blades move freely. • Keep air paths free of loose foreign objects and debris. Do not: Locate the Exhaust where it will be blocked for any reason. www.whisperkool.com | Page 21... -
Page 24: Multi Speed Fan Control
MULTI SPEED FAN CONTROL Designed for wine cellars up to 2000 cubic feet, the InCellar 8000 features multi-speed fans with a “high” setting for maximum performance in high-temperature (+110°F) environments and a “low” setting for super-quiet operation. Fan Speed Selector Switch (Low/High): The cooling unit fans may operate on two speed settings: Low and High. -
Page 25: Unit Operation
PB1 (bottle probe) and Set Point: PB2 (evaporator probe). The set point is set from the factory (WhisperKool) at 55°. It Safety Features: can be adjusted by the customer between 50° and 70° in one degree increments. -
Page 26: Control Functions
CONTROLLER FUNCTIONS Button/Symbol Normal Functions ON/OFF • Press and hold the on/off button for approximately 3 seconds to turn the unit on or off. Note: This does not disconnect power from the unit. In order for the power to be shut off from the unit, the power cord must be unplugged from the wall receptacle. -
Page 27: Alarm Codes
Change this parameter from “n” to “y” to lock the keyboard from changes to the set point. Select one of these numbers to display your preference: 0 = Set Point 1 = Bottle Probe Temperature 2 = Evaporator Probe Temperature 3 = Condenser Probe Temperature www.whisperkool.com | Page 25... -
Page 28: Incellar 8000 Wire Diagram
INCELLAR 8000 WIRING DIAGRAM Black White Purple Gray Green White Black Crankcase Heater 052413 Page 26 | 1-800-343-9463... -
Page 29: Maintenance Schedule
2. Use a vacuum with brush attachment to clean coils. Be careful not to crush coil fins when cleaning. 3. Inspect for corrosion. 4. Check wiring connections and integrity of cords. 5. Examine duct work for cracks or possible leaks. 6. Pour a 50/50 bleach solution into the drain line every spring. www.whisperkool.com | Page 27... -
Page 30: Troubleshooting Guide
TROUBLESHOOTING GUIDE Unit has ice forming on the Evaporator Solution Possible Cause Evaporator coil is dirty. Clean coil with a vacuum. If coil is very dirty, use a small hand spray with a small amount of liquid dish washer detergent. Spray coil, let set for 5 min, then flush with fresh water. - Page 31 Please contact the installing technician to troubleshoot. Compressor and /or starting components faulty Please contact the installing technician to troubleshoot. Humidity in cellar too low Possible Cause Solution Not enough moisture Raise the Fdc setting to increase the humidity level www.whisperkool.com | Page 29...
- Page 32 TROUBLESHOOTING GUIDE Pump runs all the time Possible Cause Solution Float is positioned with the magnet facing downwards. Reposition the float with the magnet facing up wards. The float is not in the correct location. Check that the float is located inside the reservoir around the sensor column.
-
Page 33: Technical Assistance & Accessories
TECHNICAL ASSISTANCE & ACCESSORIES WhisperKOOL Customer Service is available Monday through Friday from 8:00 a.m. to 4:00 p.m. Pacific Time. The customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: •... -
Page 34: Installation Terms And Conditions
Manual are shipped with each unit and, if another copy is needed, replacement copies can be downloaded from the company website (whisperkool.com) or by contacting WhisperKOOL directly for a new copy. WhisperKOOL reserves the right, in its sole discretion, to change its Terms and Conditions at any time, for any reason, without notice. - Page 35 12. No one has any authority to add to or vary the limited warranty on this Product. 3. Product Installation Requirements: A. Prior to installing a WhisperKOOL Product, the End User must read the WhisperKOOL Owner’s Manual and thereafter the End User must follow the required installation, use and maintenance procedures set forth by WhisperKOOL in WhisperKOOL’s Owner’s Manual.
- Page 36 D. End User is responsible for all costs incurred for the installation and/or removal of the Product, or any part thereof, unless such cost has been agreed by WhisperKOOL to be a warranty repair prior to the work being performed.
- Page 37 WhisperKOOL, Purchaser and End User, hereby irrevocably submit to the personal jurisdiction of such courts for that purpose. No waiver by WhisperKOOL of any breach or default of the contract of sale (including these Terms and Conditions of Sale) concerning a Product will be deemed to be a waiver of any preceding or subsequent breach or default.
- Page 38 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1(800) 343-9463 www.whisperkool.com...
