- Page 1 PLATINUM SPLIT TWIN OWNER’S MANUAL 24V Thermostat Conversion Kit Option The Coolest Thing In Wine Storage...
- Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Before You Start . -
Page 4: Introduction
INTRODUCTION Customer Service Thank you for purchasing a WhisperKOOL cooling system. We strive to provide the highest-quality products and the best possible customer service. If you have any questions about your system, please call us at 1-800-343-9463 or visit WhisperKOOL.com. -
Page 5: Before You Start
If you encounter a problem with your WhisperKOOL system, please refer to the Troubleshooting Guide. If you have any further questions or concerns, or need assistance, please contact WhisperKOOL’s Customer Service at 1-800-343-9463. Please be sure all testing has been completed prior to contacting Customer Service. -
Page 6: Receiving & Inspecting The System
Allow the condensing unit to sit for 24 hours prior to start-up. The condensing unit can be placed in the installation location, piped, and evacuated during this time. NOTE: WhisperKOOL units are manufactured in the USA and tested prior to shipment. •... -
Page 7: Quick Reference Guide
THROUGH THE WALL Option 1 Knockout for wiring Line set knockout Knockout for drain line Thermostat wire routing for optional 24-volt thermostat (NOT INCLUDED) INSIDE CELLAR Option 2 Knockout for drain line Knockout for wiring Line set knockout www.whisperkool.com | Page 5... -
Page 8: Fully Ducted Evaporator Unit
Fully Ducted — Front / Side View Supply air Return air Duct plenum Fully Ducted — Rear / Side View Mounting keyholes (4) R E A R V I E W THROUGH THE WALL Option 1 Knockout for wiring Line set knockout Knockout for drain line INSIDE CELLAR Option 2... -
Page 9: Wall-Mounted Twin Specifications
Evaporator units are installed in the cellar. Condensing unit is installed outside in a protective Installation enclosure. Thermostat Aftermarket (24V thermostat not included) Temp. Delta 55°F temperature differential between cellar environment and condensing unit intake air Warranty 2 years (parts and labor) www.whisperkool.com | Page 7... -
Page 10: Fully Ducted Twin Specifications
FULLY DUCTED TWIN SPECIFICATIONS Supply air Return air Duct plenum 9000 Master Evaporator 9000 Slave Evaporator Model (Fan Coil Unit) (Fan Coil Unit) Cellar Size (cu. ft.) Approx. 3000 Approx. 3000 Dimensions 20.5”W x 15.5”H x 20”D 20.5”W x 15.5”H x 20”D BTUh with 90°F air entering 7850 7850... -
Page 11: Condensing Unit Quick Reference Guide
Evaporator units are installed in the cellar or up to 25 ducted feet away. Condensing unit is Installation installed outside in a protective enclosure. Temp. Delta 55°F temperature differential between cellar environment and condensing unit intake air Warranty 2 years (parts and labor) www.whisperkool.com | Page 9... -
Page 12: Preparing The Wine Cellar
Insulation Insulation is REQUIRED in order to properly use WhisperKOOL products. It is vital that all walls and ceilings be insulated to keep the cellar temperature as consistent as possible during the summer and winter months. Standard fiberglass or rigid foam insulation is normally used in cellar construction;... - Page 13 In cases where glass doors are used and the room size is close to the recommended system size, the next larger size WhisperKOOL system should be used. This will compensate for the insulation loss due to the lower insulating rating of glass.
- Page 14 However, you must have a fresh air inlet as well. NOTE: If you are unsure about having adequate ventilation in your install location, please contact us to assess your specific installation at support@whisperkool.com or 1-800-343-9463. Evaporator units...
-
Page 15: System Operation
55°F. NOTE: To ensure correct system operation, the 24V thermostat must be placed inside the wine cellar, preferably in a central location away from any airflow. www.whisperkool.com | Page 13... - Page 16 NOTES 102417 Page 14 | 1-800-343-9463...
-
Page 17: Troubleshooting Guide
If so, contact your installing technician to assist with troubleshooting. System runs constantly Possible cause Solution Leaky door seal or poorly insulated cellar Fix leaky door seal and insulate cellar www.whisperkool.com | Page 15... - Page 18 Units leak water Possible cause Solution Evaporator units are not level Evaporator units should be level on the wall to prevent leaking Drain lines clogged or kinked Check drain lines to make sure water can flow freely Drains are clogged, preventing water from escaping Disconnect drains and clear them out;...
- Page 19 Fan switch on thermostat set to "on" Set fan switch to the "auto" position Fan relay in thermostat or 24V conversion kit stuck on Call Customer Service for details on how to perform the bypass plug test www.whisperkool.com | Page 17...
-
Page 20: Maintenance Schedule
MAINTENANCE SCHEDULE Monthly 1. Check coils 2. Check for unusual noise or vibration 3. Check the drain lines to see if they are above the waterline (if draining into a vessel) Quarterly 1. Use a vacuum with brush attachment to clean coils; be careful not to crush coil fins when cleaning 2. -
Page 21: Technical Assistance & Accessories
Platinum Twin TECHNICAL ASSISTANCE WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. Pacific Standard Time. The appointed customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: •... -
Page 22: Installation Terms And Conditions
WhisperKOOL warrants against defects in material and workmanship as follows: 1. LABOR — For a period of two (2) years commencing on the date of purchase, WhisperKOOL will, at its option and discretion, reimburse up to $250 to the End User for cost incurred for servicing, repairing, removing or installing warranty parts. - Page 23 6. Proof of purchase of the Product in the form of a bill of sale, receipted invoice or serial number, which is evidence that the Product is within the Limited Warranty Period, must be presented by the End User to WhisperKOOL in order to obtain limited warranty service.
- Page 24 WhisperKOOL Customer Service to arrange for replacement under the warranty guidelines. When a claim for warranty is submitted for a condenser skid, the End User must purchase a new condenser skid from WhisperKOOL at retail price. Upon installation of the new condenser skid by a certified HVAC/R Technician, the HVAC/R Technician must complete the Installation Checklist and End User must submit the Installation Checklist to WhisperKOOL Customer Service for approval.
-
Page 25: Customer Service
WhisperKOOL and Purchaser. Any dispute will be resolved by the courts in and for the County of San Joaquin, State of California, and all parties, WhisperKOOL, Purchaser and End User, hereby irrevocably submit to the personal jurisdiction of such courts for that purpose. No waiver by WhisperKOOL of any breach or default of the contract of sale (including these Terms and Conditions of Sale) concerning a Product will be deemed to be a waiver of any preceding or subsequent breach or default. - Page 26 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1-800-343-9463 www.whisperkool.com...
