WhisperKool 81310 Owner's Manual

Whisperkool split system owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SPLIT SYSTEM
OWNER'S MANUAL
To be used wiTh your sysTem's
uNiT specific iNsTallaTioN Guide
The Coolest Thing In Wine Storage

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 81310 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WhisperKool 81310

Summary of Contents for WhisperKool 81310

  • Page 1 SPLIT SYSTEM OWNER’S MANUAL To be used wiTh your sysTem’s uNiT specific iNsTallaTioN Guide The Coolest Thing In Wine Storage...
  • Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction ... Receiving & Inspecting The Unit... Preparing the Wine Cellar ... 7 Installation ... 7 Remote Keypad ... Ducted Installation ... Liquid Measuring Thermometer ... System Operation ... Control Panel Operation ... Maintenance Schedule ... Troubleshooting Guide ... Wiring Diagrams ...

  • Page 4: Introduction

    Thank you for purchasing a WhisperKOOL split system. We strive to provide the highest quality products and the best possible customer service. If you have any questions about your WhisperKOOL unit, please call us at 1(800) 343-9463 or visit www.whisperkool.com.

  • Page 5: Receiving & Inspecting The Unit

    Note: Refer to the Unit Specific Installation Guide (USIG) for a detailed packing list for your specific split system order. Please leave the WhisperKOOL system in its original boxes until you are ready for installation. This will allow you to move the product safely without damaging it. WhisperKOOL highly recommends that you save your boxes and all packaging materials.

  • Page 6: Preparing The Wine Cellar

    In cases where glass doors are used and the room size is close to the recommended unit size, the next larger size WhisperKOOL should be used. This will compensate for the insulation loss due to the inefficient door.
  • Page 7 How to Build a Wine Cellar Instructional Video WhisperKOOL has a construction tutorial available on line at www.whisperkool.com, or you can call 1-800- 343-9463 and contact our Customer Service (ext. 799) or Sales Department (ext. 751) for information on how to obtain a DVD version.

  • Page 8: Installation

    General Installation Guidelines and Instructions WhisperKOOL requires that a certified HVAC technician install and charge all split systems. Please take a moment to review state and city building codes to ensure the safe and proper installation of the system. Electrical Needs WhisperKOOL split systems requires a dedicated 110-volt 20-amp circuit.
  • Page 9 Installing the Condensing Unit The condensing unit can be mounted inside a utility area of the home or outside utilizing the required outdoor condensing unit housing. The condenser requires a dedicated 20 amp circuit, non-GFI. Make sure there is a minimum three-foot horizontal clearance in front and rear of the unit. The unit may either be hard wired or plug-in depending on local electrical codes.
  • Page 10 Depending on temperature, the “high side” should be approximately 175 lbs, and the ”low side” 28 lbs or more to keep the evaporator from icing. It is recommended while charging to use a digital refrigerant scale for better accuracy in measuring the amount of charge. Page 8 GSM-01 081310...

  • Page 11: Remote Keypad

    REMOTE KEYPAD: INSTALLATION AND CONFIGURATION If you have a system with a remote keypad, please review this section for installation. Note: 50 feet of communication line is included, the keypad can be installed up to 300 line feet away. Lon- ger lengths of communication line can be ordered by calling 1-800-343-9463 ext.

  • Page 12: Ducted Installation

    • Check that all fan blades move freely • Keep air paths free of loose foreign objects and debris • Connect the round flexible ducts to the WhisperKOOL system using the duct collars provided with the duct accessory kit • Pull the outer plastic wrapping and insulation away from the end of the duct to expose the reinforced inside duct liner • Fasten the duct collar using tie straps or clamps around the inside liner...

  • Page 13: Liquid Measuring Thermometer

    LIQUID MEASURING THERMOMETER Most WhisperKOOL systems come equipped with a liquid temperature measuring thermometer probe . This self calibrating probe contains a sensor chip, which actually communicates back and forth to the thermostat. This results in a consistent liquid temperature as air temperature fluctuates Measuring liquid temperature has a couple unique advantages: 1. The temperature of the wine can be more precisely controlled, ensuring a more consistent overall...

  • Page 14: System Operation

    5 minutes, which is a feature of the WhisperKOOL Humidity Management (WHM) sys- tem. The WHM is an adjustable feature which allows the customer the convenience of managing the hu- midity enhancement of their wine cellar.

  • Page 15: Control Panel Operation

    CONTROL PANEL OPERATION Defrost Energy Reduction Button Energy Reduction Set Button •View Set Point •Change Set Point •SET + Down = CPSM •Reset Hi & Lo Button ALARM Note: The 1 or the 3-5 stands for the amount of time (in seconds) that the button must be held. Button ON/OFF • The ON/OFF button allows the customer the convenience of turning the refrigeration system ON or OFF, from the control panel.
  • Page 16 OFF cycle time for the fan, during the compres- sor OFF cycle. However, the parameter is located within the CPSM as a convenience to the cus- tomer, should it need to be adjusted. Page 14 GSM-01 081310...
  • Page 17 CPSM CCS – Cellar Pre-Chill Set Point: This parameter is set at 52°f, but can be adjusted to a set point Mode between 45°f - 67°f. (Cont.) bLL/Act – Compressor Off or On for Low (bLL) or High (Act) Temperature Alarm: These param- eters are set at “n”.

  • Page 18: Maintenance Schedule

    1. Remove grille/ducting on the evaporator 2. Remove the filter covering the coil 3. Wash with warm water 4. Dry off filter by shaking excess water from filter 5. For ducted applications, replace filer (call WhisperKOOL for replacements) Page 16 MAINTENANCE SCHEDULE GSM-01 081310...

  • Page 19: Troubleshooting Guide

    Message Cause “P1” Room probe failure “P2” Evaporator probe failure “HA” Max bottle probe temp alarm “LA” Min bottle probe temp alarm “EA” External alarm Fault Cause Water leaking from unit 1. Condensate drain clogged 2. Evaporator coil frozen 3. Drain line improperly installed Wine cellar temperature above thermostat set point 1.
  • Page 20 Call a CERTIFIED HVAC service technician to diagnose and repair. Provide source of cool air to condenser space in accordance with directions in this manual. Call a CERTIFIED HVAC service technician to diagnose and recover excess refrigerant. GSM-01 081310...
  • Page 21 7. System low on refrigerant. 8. Thermostatic expansion valve power element losing its charge. 9. Low voltage to compressor, below 103V with compressor running. 10. Cooling system not sufficient for load Evaporator blower runs, but compressor does not 1. System “Anti-Frost“ 2.
  • Page 22 50° Check refrigerant “sight glass” in 1/4” tubing. Check for bubbles after system has run for several minutes. If bubbles present, call a CERTIFIED HVAC service technican. If sight is clear of bubbles, refrigerant level is OK. GSM-01 081310...
  • Page 23 5. Evaporator blower not running 6. Obstruction to air flow 7. Anti-frost control not working Humidity in cellar too high 1. Compressor short cycling 2. Refrigeration not running properly 3. Cellar vapor barrier not sufficient • Faulty blower motor or broken wire connection. •...

  • Page 24: Wiring Diagrams

    Platinum Split 4000 & 8000 Evaporator Terminal Board Serves Color Line 1 Black Neutral White Solenoid Valve Blue Evap B Black Remote to Keypad - Black + Red Page 22 WIRING DIAGRAMS GSM-01 081310...
  • Page 25 Platinum Split 4000 & 8000 Condenser Terminal Board Page 23...
  • Page 26 Mini-Split Evaporator Terminal Board Page 24 GSM-01 081310...
  • Page 27 Mini-Split Condenser Terminal Board Page 25...

  • Page 28: Technical Assistance

    WhisperKOOL Customer Service is available Monday through Friday from 8:00 am to 4:00 pm PST. The Customer Service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: • The model and serial number of your WhisperKOOL split system...

  • Page 29: Installation Terms And Conditions

    WhisperKOOL warrants against defects in material and workmanship as follows: (a) LABOR: For a period of two (2) years commencing on the date of purchase, WhisperKOOL will, at its option and discretion, either repair or replace the product at no charge to the Purchaser if the product is determined by WhisperKOOL to be defective.
  • Page 30 Some states do not allow the exclusion or limitation of incidental or consequential damages or on the duration of express and/or implied warranties, so the above limitations or exclusions may not apply to you. WhisperKOOL’s Limited Warranty gives you specific legal rights and you may have other rights, which vary from state to state.
  • Page 31 WhisperKOOL will cover the costs of the evaluation by the certified HVAC technician. If the product is malfunctioning due to the improper installation or some other act or omission by a party other than WhisperKOOL, then the user is responsible for the costs of the on-site evaluation by the technician in addition to any repair costs.
  • Page 32 Terms and Conditions and Limited Warranty. The parties may modify these Terms and Conditions or the Limited Warranty only in writing signed by each. No waiver by WhisperKOOL of any breach or default hereunder will be deemed to be a waiver of any preceding or subsequent breach or default.
  • Page 33 NOTES...
  • Page 34 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1(800) 343-9463 www.whisperkool.com...
