Required Tools
• Drill
• 5/32" Drill Bit
• 1/4" Socket Drill Bit
• 1/4" Wrench
PACKAGE CONTENTS
EVAPORATOR PREPARATION
1. Remove the access panel.
2. Install bottle probe connector.
3. Install 3/8" drain line on drain pan.
4. Depending on your desired installation, remove the rear or bottom knockouts for the line set and drain line.
5. Using a 5/32" drill bit on a drill, from the outside of the unit
cut holes through the unit's insulation for the line
set and drain line.
2
1738 E. Alpine Ave • Stockton, CA 95205 • 1(800) 343-9463 • www.whisperkool.com
• Phillips Screwdriver
• Tape Measure
• Brazing Torch
• Drywall Saw
(1) Mini-Split Evaporator Unit
(1) 12 Foot Bottle Probe
(4) 2" #8 Hex Head Screws
(1) 10 FT. 3/8"Drain Line
(1) ¼" Sight Glass
(1) ¼" Filter Drier
UNIT SPECIFIC INSTALLATION GUIDE
• Ladder
• Level
• Pliers
• Pencil
1
3
PLATINUM MINI-SPLIT
TO BE USED WITH THE
SPLIT SYSTEM OWNERS MANUAL
(1) 10" Piece of Cork Tape
(1) Split System Owner's Manual
(1) Unit Specific Installation Guide
(1) Evaporator Mounting Template
(1) Warranty Registration Card
Page 1
Advertisement
Table of Contents
Related Manuals for WhisperKool Platinum 042610
Summary of Contents for WhisperKool Platinum 042610
-
Page 1: Package Contents
5. Using a 5/32” drill bit on a drill, from the outside of the unit cut holes through the unit’s insulation for the line set and drain line. 1738 E. Alpine Ave • Stockton, CA 95205 • 1(800) 343-9463 • www.whisperkool.com UNIT SPECIFIC INSTALLATION GUIDE • Ladder • Level... - Page 2 16. Reinstall the access panel removed in step 1 of Evaporator Preparation. 17. Plug in the evaporator and condensing unit. 18. Follow standard refrigeration system charging processes. WhisperKOOL recommends pressurizing the sys- tem using dry nitrogen, then allow unit to hold pressure for 30 minutes prior to charging.
