- Page 1 TFT LCD COLOR MONITOR User’s manual Model: LCD-1042VB 10.4” Model: LCD-1211VB 12.1” Model: LCD-1512VB 15.1” ® 1319 DEXTER AVE N, STE 020 SEATTLE, WA 98109 TEL:206/623-6000 FAX:206/623-6609...
-
Page 2: Table Of Contents
Thank you for Purchasing this ToteVision product. Before attempting to operate your video Monitor, please carefully read this manual. Content 1. Precautions 2. Package contents 3. Location of Controls 4. Monitor Use 5. Cleaning instructions 6. Adjust the monitor 7. Specifications... -
Page 3: Package Contents
1. PRECAUTIONS Item\Model LCD-1042 LCD-1211 LCD-1512 -This unit has been engineered and made to assure your personal Display 10.4TFT 12.1TFT 15.1TFT safety; however, improper use may cause potential electrical shock Back light 2 CCFL Type L 8 CCFL 12 CCFL and fire hazard. -
Page 4: Location Of Controls
3. Location of Controls 7. SPECIFICATION: 10.4” Front View On screen display for: brightness, contrast, back light, hue & Tint S-video capability Sunlight readable Very High Brightness LCD panel For color applications Wide viewing angle High contrast ratio Active matrix technology eliminates distortion 10.4”... - Page 5 12.1” Front View Miscellaneous¡ G Signal Source¡ G To choice signal for D-SUB¡ B CVBS or S-VIDEO. Mode Select¡ G To choice mode by 640x400 or 720x400. Reset¡ G Select this function can make the monitor have the best efficiency. Volume¡...
- Page 6 15.1” Front View Function¡ G Auto Adjust¡ G Select this function can make the monitor have the best efficiency. Auto Colour¡ G Select this function can make the color have the best efficiency. OSD Menu¡ G 15.1” Rear View Language¡ G There are 8 type languages can be selected. OSD H.
-
Page 7: Cleaning Instructions
4. Monitor use a. Make sure your video source ( CCD CAMERA,VTR, e.t.c.) Colour¡ G power is on Contrast¡ G Adjust the contrast using ¡ Ï and ¡ Ð buttons. b. Connect your video source to video input (VGA, RCA video Brightness¡... -
Page 8: Adjusting The Monitor
6. Adjusting the monitor Inputs Diagram Control Button ¡ i 1¡ j ¡ i 2¡ j ¡ i 3¡ j ¡ i 4¡ j Power Power Decrease Increase Menu / Enter ¡ i 1¡ j DC IN¡ G This is for connecting the power cable. ( - ) Switch ( + )
