- Page 1 LCD-1047VT LCD-1047VR/TL Color TFT-LCD TV Monitor Operation Manual www.totevision.com...
-
Page 2: Table Of Contents
LCD-1047VT/VR/TL COLOR TFT-LCD TV Monitor 1. LCD-1047VT (stand alone unit) 2. LCD-1047TL (unit in flush mount kit) 3. LCD-1047VR (unit in rack kit) OPERATION MANUAL CONTENTS SAFETY PRECAUTIONS SUPPLIED ACCESSORIES PREPARATION ………………………7 Remote Control Cable Connection ……………………8 LOCATION OF USER CONTROLS BASIC OPERATION ……………………10 Monitor Installation... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your color TFT-LCD TV monitor product, please read the following precautions carefully before using the product. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Improper adjustment of controls not described in the instruction can cause damage, which often requires extensive adjustment work by a qualified technician. e. When the product has been dropped or damaged. f. When the product displays an abnormal condition. Any noticeable abnormality in the product indicates that the product needs servicing. -
Page 5: Supplied Accessories
SUPPLIED ACCESSORIES Please check to make sure the following accessories are included with this product. TM390 ... XGA LCD-2200VT TM400 ... SXGA WSXGA Color TFT-LCD TV Monitor (NTSC) Operation Manual Operation Manual (x1) Size AAA Battery (x2) Remote Control (x1) DESK Stand (x1) AC Adapter (x1) AC Cord (x1) -
Page 6: Preparation
PREPARATION ■ Use the remote control by pointing it towards the remote sensor window. Objects between the remote control and sensor window may prevent proper operation. Cautions regarding use of remote control ■ Do not drop the remote control . In addition, do not expose the remote control to liquids, and do not place in an area with high humidity. -
Page 7: Cable Connection
PREPARATION Rear view of main unit 1. BNC Video OUT is passive loop out. 2. If BNC Video IN is applied, RCA Video IN will be disabled. (option) BNC Video IN & loop out ANALOG RGB S-VIDEO is active output for VCR recording for TV or composite video VIDEO OUT input. -
Page 8: Location Of User Controls
LOCATION OF USER CONTROLS Control Panel (C/P) on the front of main unit IR window Remote control (R/C) Sound mute Select Under Scan Menu Vol (▲)/(▼) ▲ Increase volume (up) ▼ Decrease volume (down) Select input source POWER Power Power Indicator Decrease volume Increase volume... -
Page 9: Basic Operation
BASIC OPERATION POWER On / Off / Standby IR Window Power Indicator Switching PC / TV / VIDEO / S-VIDEO Mode Available Mode ■ PC ■ Video ■ S-Video ■ TV ■ by Control Panel (C/P) Press the POWER power indicator lights green. Press again the Power button to turn off. -
Page 10: Monitor Installation
Monitor Installation [Control Panel ] icon Double click from [My Computer] folder [Settings] Select in [Display Properties] window. [Advanced...] Click Available Mode ■ PC □ Video □ S-Video □ TV Double click [Control Panel] folder. Select [Monitor] in the window shown above. -
Page 11: Basic Osd Usage
BASIC OSD USAGE Main Menu Screen Menu Press the of R/C or C/P to display the OSD menu screen. Ch▲/▼ Press the of R/C or C/P to move the cursor to Press the of R/C or Exit Press the of R/C or select the Note: R/C - Remote Control &... -
Page 12: Pc Setup
PC Setup Vol▼ Press the Selected item or press the Color Color Picture Function OSD Menu Misc. Sound PICTURE Color Picture Function OSD Menu Misc. Sound Color Function Picture Function OSD Menu Misc. Sound Move down V-Position Move left H-Position ideo Available Mode ■... -
Page 13: Under Scan
TV &Video Setup Press the Selected item or press the Channel UP/DOWN Edit Add/Erase Select AUTO Search Fine Tune Under Scan Normal Screen ... The screen takes the source of 4:3 aspect ratio as its full-sized regular picture. You may loose some of the edge of the original image. -
Page 14: Osd Setup
OSD Setup Press the Selected item or press the Language 1 Press the Menu of R/C or C/P to select the Language. The language select menu screen will appear. 2 Press the Vol▲/▼ of R/C or press the Ch▲/▼ of C/P to move the cursor to the English or other. -
Page 15: Before Calling For Repair Service
Before calling for repair service... ■ Before calling for repair service, check the following items for possible remedies to the encountered symptoms. Problem • Make sure the AC adapter is properly inserted in the There is no picture or sound power outlet. -
Page 16: Specifications
SPECIFICATIONS Color TFT-LCD TV Monitor Resolution Color Standard Color Brightness Contrast Ratio Viewing Angle Panel Type Actual Display Size Diagonal Length PC Signal H-Frequency (Analog RGB) V-Frequency Signal Level Video / TV Input Signal Color Signal Type Sound Signal Type Power Voltage Power Consumption Standard... -
Page 17: Available Pc Vga Mode
SPECIFICATIONS VGA Input Signal V-Frequency Resolution (Hz) 640 x 350 640 x 400 720 x 400 640 x 480 800 x 600 1024 x 768 1152 x 864 H-Frequency Pixel Rate (KHz) (MHz) 37.9 31.500 37.9 31.500 37.9 35.500 31.5 25.175 37.9 31.500... -
Page 18: Warranty Card
Warranty ToteVision warrants to the original purchaser that this product is free from defects in workmanship and material under normal use and conditions for a period of 1 year from the date of original purchase, subject to the limitations below. Should service be required by reason of any defect or malfunction during the warranty period, ToteVision will repair or at its discretion replace this product, without charge (except for a $15.00 charge for handling, packing, return shipping, and subject to verification of the defect or malfunction), upon delivery of this product to the Factory Service Center listed below with proof of date of purchase.
