Tote Vision LCD-1047HD Owner's Manual

High definition color lcd monitor
Hide thumbs

Advertisement

LCD-1047HD
1047HDR/HDL
High Definition
Color LCD Monitor
Owner's Manual
LCD-1047HD series
www.totevision.com

Advertisement

loading

  Related Manuals for Tote Vision LCD-1047HD

  Summary of Contents for Tote Vision LCD-1047HD

  • Page 1 LCD-1047HD 1047HDR/HDL High Definition Color LCD Monitor Owner’s Manual LCD-1047HD series www.totevision.com...
  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS Improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your Color TFT-LCD monitor product, please read the following precautions carefully before using the product.
  • Page 3 SAFETY PRECAUTIONS may cause damage, which often requires extensive adjustment work by a qualified technician. e. When the product has been dropped or damaged. f. When the product displays an abnormal condition. Any noticeable abnormality in the product indicates that the product needs servicing. ■...
  • Page 4 LCD-1047HDR <19” standard rack mount kit> LCD-1047HDL, Flush Mount Kit...
  • Page 5: Supplied Accessories

    LCD-1047HD/HDR/HDL 1. LCD-1047HD (stand alone unit) 2. LCD-1047HDL (unit in flush mount kit) 3. LCD-1047HDR (unit in rack kit) OPERATION MANUAL SUPPLIED ACCESSORIES Please check to make sure the following accessories are included with this product. -Power supply -Remote Control...
  • Page 6 PREPARATION ■ Use the remote control by pointing it towards the remote sensor window. Objects between the remote control and sensor window may prevent proper operation. Cautions regarding use of remote control ■ Do not drop the remote control . In addition, do not expose the remote control to liquids, and do not place in an area with high humidity.
  • Page 7 PREPARATION Rear view of main unit 1. BNC Video OUT is passive loop out. 2. If BNC Video IN is applied, RCA Video IN will be disabled. (option) BNC Video IN & loop out S-Video Y is active output for Video 1 or Video 2 input. VIDEO OUT If S-Video or component input is selected, display of this output will be changed to black and white because the color of the original input signal is...
  • Page 8: Location Of User Controls

    LOCATION OF USER CONTROLS Control Panel (C/P) on the front of main unit IR window Remote control (R/C) Vol (▲)/(▼) ▲ Increase volume (up) ▼ Decrease volume (down) Select input source POWER ▼ VOL ▲ Power Power Decrease volume Indicator Increase volume Menu move down Menu move up...
  • Page 9: Basic Osd Usage

    BASIC OSD USAGE Main Menu Screen Menu Press the of R/C or press MENU for 2 sec. of C/P to access the OSD menu screen. ▲/▼ Press the to move the cursor to Menu Press the to select the menu icon. Press the Menu to exit menu.
  • Page 10: Pc Setup

    PC Setup Press the Selected item or press the Color PICTURE Function V-Position H-Position Vol▼ of R/C ▼ of Color Contrast Picture Brightness Function Gamma OSD Menu Color Temp Misc. Color Adjust Sound Color H.Position Picture V.Position Function Phase OSD Menu Clock Misc.
  • Page 11: Video Setup

    Video Setup Press the Selected item or press the Under Scan Normal Screen ... The screen takes the source of 4:3 aspect ratio as its full-sized regular picture. You may loose some of the edge of the original image. Under scan mode ... This mode enables the user to display 100% of input image without hiding any image of Source.
  • Page 12: Osd Setup

    OSD Setup Press the Selected item or press the Language 1 Press the Menu of R/C or C/P to select the Language. The language select menu screen will appear. 2 Press the Vol▲/▼ of R/C or press the ▲/▼ of C/P to move the cursor to the English or other.
  • Page 13: Specifications

    YPbPr accept 480i, 480p, 720p and 1080i/p BNC Video-2 OUT, selected Video 1/ 2 Output RS-232, External IR Input 1047HD:270x230x50(without desk stand) 1047HDL:337x247x42, 1047HDR:482x177x50mm Approx. 15 Watt @ DC 12V 0 – 50 °C -20 – 60 °C 1.5 Kgs,2.5 Kgs(with desk stand) LCD-1047HD/HDR/HDL...
  • Page 14 Applicable PC Mode V-Frequency Resolution (Hz) 640x350 640x400 720x400 320x200 640x215 680x350 59.477 640x480 800x600 1024x768 H-Frequency Pixel Rate (KHz) (MHz) 37.9 31.5 VESA 37.9 31.5 VESA 37.9 35.5 VESA 15.75 15.75 23.169 31.5 25.175 Industrial 37.9 31.5 VESA 37.5 31.5 VESA 31.5 37.9...
  • Page 15: Warranty

    Warranty ToteVision w arrants to the original purchaser that this product is free from defects in workmanship and material under normal use and conditions for a period of 1 year from the date of original purchase, subject to the limitations below. Should service be required by reason of any defect or malfunction during the warranty period, ToteVision will repair or at its discretion replace this product, without charge (except for a $15.00 charge for handling, packing, return shipping, and subject to verification of the defect or malfunction), upon delivery of this product to the Factory Service Center listed below w ith proof of date of purchase.
