- Page 3 Operating Instructions Thank you for purchasing this high-resolution multi-scan color monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 4 Safety Precautions This monitor is manufactured and tested on the principle that the user’ s safety comes first. However, improper use or installation may not only damage the monitor but endanger the user as well. As a safety precaution, go over the following WARNINGS carefully before installation, and keep this guide handy.
- Page 5 Care and Maintenance Care Avoid exposing your monitor directly to sunlight or other heat sources. Place your monitor away from the sun to reduce glare. Put your monitor in a well-ventilated area. Do not place anything heavy on top of your monitor. Make certain that your monitor is installed in a clean and moisture-free area.
-
Page 6: Before Installing Your Monitor
CHAPTER 1 Introduction BEFORE INSTALLING YOUR MONITOR Read this manual cover to cover. PAY ATTENTION to all WARNING and CAUTIONS DO NOT use computer components not recommend by the manufacture Do not attempt to service the monitor your self. If a problem occurs, contact the manufacture's authorized service center ABOUT YOUR MONITOR This monitor is a microprocessor-controlled, color monitor that... -
Page 7: Factory-Preset Modes
FACTORY-PRESET MODES Table 1 shows standard video mode setting that has been pre-adjusted at the factory for accurate video display. These setting are stored in the monitor's memory Table 1. Factory-Preset Modes PC mode Mode Resolution 640x400 640x350 720x400 640x480 640x480 640x480 SVGA... - Page 8 LCD-1900VR 19” LCD 8U Rack Display Monitor Overall Dimension (HxWxD): 394.5 x 436 x 62 mm Effective Display area (H/V): Display colors: Scan Frequencies: Horizontal Vertical Number of Pixels: Pixel pitch: Picture Tube: Power: Input Consumption PC RGB Connector: Audio connector...
- Page 9 Operations: User Controls On Screen Display Control Type: Compatibility: Environmental Limits: Operating Temp Storage Temp. Operating Humidity Storage Humidity Agency Approval Emissions Energy Saving Safety On/Off Power Button, +/- and Up/down keys Auto adjustment, Brightness, contrast color temperature, Hue, Tint, Source select, PIP setup H-position, V-position, OSD position Audio volume, bass, treble, mute...
-
Page 10: Product Package
RODUCT Open the shipping carton and check the contents. If any items are missing or damaged, contact your dealer immediately. The package should include the following items Analog Color TFT LCD Monitor Accessory Box: VGA cable x 1 AC to DC adapter x 1 Power Cord x 1 User’... -
Page 11: Control Functions
ONTROL The Monitor control functions are located on the lower center of the front view side. They are shown in the figure below and described in the following paragraphs. The control key description 6. MENU : Activate the on screen display UNCTIONS : Power Switch : Decrement... - Page 12 DESCRIPTION : Power switch Use the power switch to turn ON or OFF power. We recommend turning your system power on first, then the LCD monitor. & + : decrement or increment the value The two keys are decrement or increment the value or enter into the sub-menu.
- Page 13 CHAPTER 3 1024x768 48.5K 60.2 Auto Adjustment - Execute XGA-KDC45-5100 DJUSTING THE MONITOR VGA OSD main screen...
- Page 14 1. Each time, when pressing the menu key, the screen will show as above. You can see the 3mark that means the selected item. Then you can change the setting through + or -.key. 2. Pressing Sel key to move the arrow down or up. If the selected item has many option to choose, press –...
- Page 15 Color 1024x768 do the balance Color balance Intensity R Intensity G Intensity B Contrast R Contrast G Contrast B automatically. Intensity R: Adjust the R color intensity, the range is from 0 to 63 Intensity G: Adjust the G color intensity, the range is from 0 to 63 Intensity B: Adjust the B color intensity, the range is from 0 to 63 Contrast R: Adjust the R color contrast value, the range is from 0 to 63 Contrast G: Adjust the G color contrast value, the range is from 0 to 63...
- Page 16 Geometry setup § We provide Pixel Clock, Phase, H Position, V Position, OSD H Position, OSD V Position and Txt/Gft option to change. § Pixel Clock: Adjust the viewing screen size. The range is from 0 to 99 Phase: Adjust phase tracking to reduce the display flicker. The range is from 0 to 31 §...
- Page 17 Note: The PIP function is only valid on video on VGA screen. We can’ t support video on video screen Speaker volume control § We provide Volume, Bass, Treble, Mute and PIP audio for audio setup. § Volume: Adjust the speaker volume. The range is from 0 to 32. §...
-
Page 18: Video Adjustment
VIDEO ADJUSTMENT NTSC XGA-KDC45-5100 1. Each time, when pressing the menu key, the screen will show as above. You can see the 3mark, that means the selected item Then you can change the setting through + or -.key. 2. Pressing Sel key to move the arrow down or up. If the selected item has many option to choose, press –... - Page 19 § Adjust the screen contrast value. The range is from 0 to 127 Intensity adjustment § Adjust the screen intensity value. The range is from 0 to 255 Tint adjustment § Adjust the screen Tint value. The range is from 0 to 127 Hue adjustment §...
-
Page 20: Troubleshooting Procedures
Troubleshooting Procedures This LCD Monitor was pre-adjusted in the factory with standard VGA timing. Due to output timing differences among various VGA cards, you may initially experience an unstable or unclear display when a new display mode or new VGA card is selected. This LCD Monitor Supports Multiple VGA Modes.
