Extech Instruments MultiMaster MM560A User Manual page 23

Thermocouple range & accuracy not included
Hz Line Level Frequency
RANGE
500mV
5V
50V
500V
1000V
Accuracy: 0.02%+4d
Hz Logic Level Frequency
RANGE
5.0000Hz--2.00000MHz
Sensitivity: 2.5Vp square wave
%Duty Cycle
RANGE
0.1% -- 99.99%
Input Frequency: 5Hz -- 500 kHz, 5V Logic Family
Diode Tester
Range
5.0000V
Capacitance
*Accuracies with film capacitor or better
**In manual-ranging mode, measurements not specified below 45.0F and 450F for 500.0F and
9999F ranges respectively
Copyright © 2012 Extech Instruments Corporation (a FLIR company)
All rights reserved including the right of reproduction in whole or in part in any form
V1.1 8/12
Sensitivity (Sine RMS)
Accuracy
1%+1d
RANGE
50.00nF
500.0nF
5.000F
50.00F
500.0F**
9999F**
100mV
1V
10V
100V
900V
Test Current (Typical)
0.4mA
www.extech.com
23
Range
10Hz ~ 200kHz
10Hz ~ 200kHz
10Hz ~ 100kHz
10Hz ~ 100kHz
10Hz ~ 10kHz
Accuracy
0.002%+4d
Accuracy
3d/kHz+2d
Open Circuit Voltage
< 3.5 VDC
Accuracy*
0.8% + 3d
0.8% + 3d
1.5% + 3d
2.5% + 3d
3.5% + 5d
5.0% + 5d
MM560A-MM570A-EU-EN
