Extech Instruments MultiMaster MM560A User Manual page 21

AC & AC+DC Voltage
RANGE
500.00mV, 5.0000V,
50.000V
500.00V, 1000.0V
500.00mV
5.0000V, 50.000V
500.00V,
1000.0V
500.00mV
5.0000V, 50.000V,
500.00V
1000.0V
500.00mV
5.0000V, 50.000V
500.00V
1000.0V
500.00mV
5.0000V, 50.000V
500.00V
1000.0V
*From 5% to 10% of range: accuracy % of reading (or in dB) + 80d
**From 5% to 10% of range: accuracy % of reading (or in dB) + 180d
**From 10% to 15% of range: accuracy % of reading (or in dB) + 100d
CMRR: >80dB @ DC to 60Hz, Rs=1k
Input Impedance: 10M, 30pF nominal (80pF nominal for 500mV range)
Residual reading less than 50 digits with test leads shorted.
V1.1 8/12
MM570A
20Hz -- 45Hz
1.5% + 60d
Unspecified
45Hz -- 300Hz
0.3% + 20d
0.8% + 20d
0.4% + 40d
300Hz -- 5kHz
0.3% + 10d
0.4% + 40d
0.8% + 40d
(300Hz--1kHz)
5kHz -- 20kHz
0.5%+20d
0.8%+20d
0.5%+20d
Unspecified
20kHz -- 100kHz
2.5%+40d
4.0%+40d**
Unspecified
21
Accuracy*
20Hz -- 45Hz
45Hz -- 300Hz
0.8%+60d
300Hz -- 1kHz
0.8%+40d
2.0%+60d
1.0%+40d
1kHz -- 20kHz
Unspecified
20kHz -- 100kHz
Unspecified
MM560A-MM570A-EU-EN
MM560A
Unspecified
1dB**
2dB**
3dB**
