Soft Key:
ALARMS
Setting and Using Alarms
The Super II has three alarm outputs which can be used to signal when the measured weight or count is
within a pre-programmed range. To access the ALARMS soft key, be certain it has been enabled through
the SET PTS soft key of theTechnical setups menu (See "Supervisor and Technical Manual"). Then follow
the steps below:
1. Press the menu hard key on the controller, and then the MORE soft key. The soft keys will change to:
tare
menu
abc
2. Press the ALARMS soft key and the soft keys change to the following:
3. Press the START soft key to enable the alarm outputs to respond to the weight/count presently on the scale.
Press the STOP soft key to freeze the alarm outputs in their present state.
4.
5. Press the RESET soft key to change the alarm outputs to their zero weight/count state.
Press the SET PTS soft key to set the alarms and the soft keys change to the following:
6.
Super II
User Functions
•
Select Menu Option:
OK!
ALARMS
MORE
remote
reset
ALARM1 ALARM2
LOW: 0.0 TARGET:
OK!
START STOP
LOW: 0.0 TARGET:
Enter Low, Target or High setpoint or
press % to enter deviation from target.
OK!
LOW TARGET
1000
UNITS COUNTER SET UPS
ALARM3 Stopped
0.0 HIGH: 0.0
O . O
Grams
RESET SET PTS GO BACK
0.0 HIGH: 0.0
Weight: O . O
HIGH % GO BACK
Base 1
Pieces
EXIT
