To enter a value into one of the above registers , use the function key F1 - F3 that corresponds to the
desired soft key (ex: F2 for entering an APW value). Use the F9 key to enter a tare value. Use the F5 Key to
EXIT.
Entering Alphanumeric ID Information
Once a letter is pressed, the scale's display changes to the ID entry mode. At this point, there are two ways
of entering the information into the ID register. The function keys F1 - F4 are available to select registers
and move throughout the menu. Another method is to press the ALT key followed by a number between 0
and 9, depending upon the register to be accessed.
Alphanumeric ID entry
using ALT key:
ALT + 1 = OPRTR
ALT + 2 = ORDER #
ALT + 3 = LOT #
ALT + 4 = DESC
ALT + 5 = VENDOR
ALT + 6 = REV #
ALT + 7 = ID7
ALT + 8 = ID8
ALT + 9 = ID9
ALT + 0 = PART ID
22
Enter ID Field Value:
ABC
PART ID LOT # DESC
F1 F2 F3
F8
tare
F9
MORE EXIT
menu
F10
F4 F5
abc
Alphanumeric ID entry
using function key:
F1= PART ID
F2= LOT #
F3= DESC
F4= MORE
F1= OPRTR
F2= ORDER #
F3= VENDOR
F4= MORE
F1= REV#
F2= ID7
F3= ID8
F4= ID9
F5= EXIT
User Functions
F11
remote
F12
reset
