OWNER'S MANUAL
Double Play Model# 5252
Charcoal and LP
Gas Grill
A propane gas cylinder is required for
operation. This gas grill is not intended
for commercial use.
SAVE THESE INSTRUCTIONS FOR FU-
TURE REFERENCE. IF YOU ARE ASSEM-
BLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO
SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE, CALL 912-
638-4724
WARNING:
Improper installation, adjustment, al-
teration, service or maintenance could
cause injury or property damage Read
the installation, operation and mainte-
nance instructions thoroughly before
assembling or servicing this equip-
ment.
OM5252 B.1
Keep your receipt with this manual for
Warranty.
(outside any enclosure)
DANGER:
DO NOT use gas grill for indoor cook-
ing or heating. TOXIC fumes can accu-
mulate and cause asphyxiation. Do
not use in or on boats or recreational
vehicles.
PROP 65 WARNING:
Chemicals known to the state of Cali-
fornia to cause cancer, birth defects
or other reproductive harm are creat-
ed by the combustion of propane.
™ & © Char-Griller / A&J Mfg.
WARNING
!
For Outdoor Use Only
Advertisement
Table of Contents
Related Manuals for King-Griller 5252
Summary of Contents for King-Griller 5252
- Page 1 OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
-
Page 2: If You Smell Gas
1-912-638-4724 (USA), Mon- day-Friday 8:30am-5pm (EST). Have your grills serial number (located on the back of the grill body or on the leg) when calling. ™ & © Char-Griller / A&J Mfg. OM5252 B.1... - Page 3 Page intentionally left blank for notes OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 4 8. DO NOT use this grill or any gas product near unprotected combustible constructions. 9. Do not use in an explosive atmosphere. Keep grill area clear and free from combus- tible materials, gasoline and other flammable vapors and liquids. ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
- Page 5 This grill is shipped from the factory for propane gas use only. Never use a propane cylinder with a damaged body, valve, collar or footing. Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier. OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 6 ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
-
Page 7: Table Of Contents
GREASE TRAY 10-0011 CATCH PAN 20-0012 DAMPER CIRCLE 10-0020 POT STAND 20-0005 FIRE GRATE HANGERS, 8.5 20-0024 HEAT SHIELD 10-0015 ASH PAN 20-0025 HUB CAP` 55-0007 SIDE HANDLE 20-0027 GRATE LIFTER 10-0045 OM5252 B.1 ™ & © Char-Griller / A&J Mfg. - Page 8 2/5” FLAT WASHER….2 PCS ¼” FLAT WASHER…16 PCS ¼-20 HEX NUT……..14 PCS ¼” LOCK WASHER…38 PCS HINGE PINS………..2 PCS LARGE HAIR COTTER PIN….2 PCS SMALL HAIR COTTER PIN….6 PCS CENTER HINGE PIN…...1 PC ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
-
Page 9: Om5252 B.1 ™ & © Char-Griller / A&J
LEGS are facing out. Please note that the wheel legs have inside and outside sides. Install one leg assembly at a time as shown. On back LEG Assembly, insert an additional (2) ½”BOLTS and (2) ¼” FLAT WASH- ERS as shown. OM5252 B.1 ™ & © Char-Griller / A&J Mfg. - Page 10 Step 4 Install the LEG BRACES to the LEGS using four (4) LOCK WASHERS and four (4) ½” BOLTS as shown. Remember to NOT tighten the bolts until completing step 6. ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
-
Page 11: Charcoal Grill Body
Make sure to insert the bolt first through the lock washer then the flat washer then through the grill body as shown. Turn grill assembly up on end as shown and tighten ALL nuts and bolts. OM5252 B.1 ™ & © Char-Griller / A&J Mfg. -
Page 12: Ga Grill Body.
GAS GRILL BODY. Secure the other end of the BURNER to the GAS GRILL BODY with the SMALL HAIR COTTER PIN provided. ™ & © Char-Griller / A&J Mfg. OM5252 B.1... - Page 13 WIRE to the backside of the ELECTRONIC IGNITER, which is at- tached to the back side of the CONTROL PANEL. Any wire can go into any of the three sockets on the Electronic Igniter. Burner Electronic Igniter Igniter Wire OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 14 BOLT should first go through a FLAT WASHER then the DAMPER then the GRILL BODY then another FLAT WAHSER then a LOCK WASHER and then secured with a HEX NUT. See below. Inside of Charcoal Grill Body ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
-
Page 15: Thermometer
(4) LOCK WASHERS and four (4) WING NUTS as shown below. Bezel Thermometer Hood Handle Wing Nut Heat Shield Step 15 Insert the THERMOMETERS through the BEZEL, into the GRILL HOODS and secure with two (2) WING NUTS as shown above. OM5252 B.1 ™ & © Char-Griller / A&J Mfg. -
Page 16: Hinge Pin
HINGE PIN from inside the charcoal grill through the HOOD then through the Gas HOOD and Body as shown. Then insert COTTER PINS through the holes in the three HINGE PINS. Hinge Pin Center Hinge Pin ™ & © Char-Griller / A&J Mfg. OM5252 B.1... -
Page 17: Flare-Up Shield
UP SHIELDS over the BURNER TUBES then hang the FIRE GRATE/ ASH PAN from the FIRE GRATE HANGERS on the catch tabs that are welded to the inside of the CHAR- COAL GRILL BODY sides. Install the cooking grates. OM5252 B.1 ™ & © Char-Griller / A&J Mfg. - Page 18 Slide the GREASE TRAY into place on the guide rails under the Side Burner as shown below. Insure that the GREASE TRAY is centered under the burner. Side Burner Grease Tray Housing ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
-
Page 19: Leg Brace.
LP. Gas cylinder evacuation can be accomplished during each purging by using a Type 1 connection. The Type 1 valve outlet has an external 1 5/16” ACME right hand tread which will accept this connection.. OM5252 B.1 ™ & © Char-Griller / A&J Mfg. - Page 20 Then re-attach the igniter button by turning it clockwise. Press the igniter button and make sure all 3 igniters that are attached to the burner tubes are creating a spark. Step 23 Tighten ALL BOLTS and NUTS. ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
- Page 21 Any remaining glue residue can be cleaned off with a spray lubri- cant like WD-40 . Do NOT use any other type of solvent or cleaner because this will damage the finish/paint/coating on the grill. OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
-
Page 22: Cooking Grate
2. Press in knob and rotate counter-clockwise to the High setting and burner should light immediately. 3. Adjust burners to desired cooking settings Cooking Grate Match Holder Chain Burner Ports ™ & © Char-Griller / A&J Mfg. OM5252 B.1... -
Page 23: Side Burner
Flame should be a Blue / Yellow color. To visually check that the burner is operating, look at the burner flame through the flame viewing hole. The flame should be approximately 1/2-3/4 inch long with the high setting. OM5252 B.1 ™ & © Char-Griller / A&J Mfg. -
Page 24: Connecting Gas Cylinder
(refer to illustration under step 22 of page 17). DANGER Never store a spare propane cylinder near this grill. A fire causing death or serious injury may occur if the above is not followed exactly. ™ & © Char-Griller / A&J Mfg. OM5252 B.1... - Page 25 PROPERLY CARED FOR. 3. You may fill unwanted holes with Nuts & Bolts (Not Provided). NOTE: Smoke will escape from areas other than the vents. This will not affect your cooking . OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
-
Page 26: Cleaning The Burner Assembly
Inspect burner for any damage (cracks or holes). If damage is found, replace with new burner. Reinstall burner; check to insure that gas valve orifices are cor- rectly positioned inside burner inlet (venturi). Also check position of spark elec- trode. ™ & © Char-Griller / A&J Mfg. OM5252 B.1... - Page 27 Note: Make sure control knobs are off. Spray solution on the tank valve to regulator connection, the “Y” joint in the hose, the connection to the manifold behind the main control panel, and the connection OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
-
Page 28: Lighting Your Grill
5 minutes before re-lighting. Clean your grill after each use, DO NOT use abrasive or flammable cleaners, as it will damage the parts of this product and may start a fire. ™ & © Char-Griller / A&J Mfg. OM5252 B.1... - Page 29 30 seconds and then light the grill. Irregular flame pattern, Burner ports are clogged Clean Burner ports flame does not run the or blocked. full length of burner. OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 30 Baked on grease buildup has Clean inside of lid thorough- be peeling turned to carbon and is flak- ly. The lid is not painted on - like paint peeling ing off. the inside ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
-
Page 31: Grease Tray
12. You may fill unwanted holes with Nuts & Bolts (Not Provided). NOTE: Smoke will escape from areas other than the smokestacks. This will not affect your cooking OM5252 B.1 ™ & © Char-Griller / A&J Mfg. - Page 32 (hot) position for 1 min each side before lowering grate and closing lid. *OR SMOKE by placing birds in center of GRID with fire in both ends of FIRE BOX. ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
- Page 33 50 minutes. Turn after 25 minutes (no need to turn if smoked). Squeeze to check for doneness. SWEET CORN IN HUSKS: Trim excess silk from end and soak in cold salted water 1 hour before grilling. Grill 25 minutes – turning several times. OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 34 15 minutes before end of cooking time. HAM GLAZE: 1 cup of light brown sugar, firmly packed, 1/2 cup orange juice, 1/2 cup honey, combine sugar, juice and honey. Let marinade sit for at least 4 hours. ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
- Page 35 Place ribs in center of grid above drip pan and smoke ap- proximately 1 1/2 hours or until meats pulls away from bone. Baste with barbecue sauce during last 30 minutes. OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 36 SHISH KABOB MARINADE: Mix 1 cup soy sauce, 1/2 cup brown sugar, 1/2 cup vinegar, 1/2 cup pineapple juice, 2 teaspoons salt, 1/2 teaspoon garlic powder and bring to a boil. Marinate beef in mixture a minimum of 4 hours. ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
- Page 37 Fits standard and 20lb, LP tank Velcro Close Elastic at Top and Bottom Visit our online store at: Cover Only Tank Not Included…...$9.99 www.chargriller.com for more Char-Griller ® Professional Accessories ™ (continued on next page) OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 38 Rotisserie $35.99 Adjustable Fit Apron $14.99 Side Fire Box #5224 $59.99 Cover For Grill $34.99 Raw Cast Iron Grate $8.99 Warming Rack $19.99 Charcoal Basket $9.99 Shipping Charge ORDER NOW! Total ™ & © Char-Griller / A&J Mfg. OM5252 B.1...
- Page 39 Page intentionally left blank for notes OM5252 B.1 ™ & © Char-Griller / A&J Mfg.
- Page 40 Char-Griller will repair or re- place any defective part of its side fire boxes for a period up to one year from the date of purchase.
