Digital Projection
TITAN HD-500, HD-250
Source (3702)
Projector source select
Value
00h
RGB1
01h
RGB2
02h
DVI
03h
SDI
04h
Composite
05h
SVideo
06h
Component
Examples
Set Source (DVI)
BEEF 03 1900 5858 01 3702 0000 00000000 02000000 00000000 00000000 00000000
Response
1E BEEF 03 1900 5858 01 3702 0000 00000000 02000000 00000000 00000000 00000000
Set Source (SVideo)
BEEF 03 1900 5858 01 3702 0000 00000000 05000000 00000000 00000000 00000000
Response
1E BEEF 03 1900 5858 01 3702 0000 00000000 05000000 00000000 00000000 00000000
Get Source
BEEF 03 1900 5858 02 3702 0000 00000000 00000000 00000000 00000000 00000000
Response (SVideo)
1E BEEF 03 1900 5858 02 3702 0000 00000000 05000000 00000000 00000000 00000000
Rev B 02/2007
User Manual
7. Appendix
Notes
Spaces in example messages
are for visual clarity and should
not be sent as part of the
message.
In the example messages
the CRC is set to 5858h. This
value will be ignored. However,
the CRC should ideally be
calculated, as described in the
Titan Projector Series External
Control Protocol.
Page 7.19
