GAS GRILL
LP Gas Grill Owner's Guide
Guía del Propietario del Asador de Gas Licuado de Propano - Pg. 37
ESNA
Guide de L'Utilisateur du Grill à Gaz PL - Pg. 73
470
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury,
death, or damage to property.
WARNING:
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
#56211
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not ignite this appliance
without first reading the BURNER
IGNITION sections of this manual.
56211 02/28/11 LP
US - ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for Weber 470

Summary of Contents for Weber 470

  • Page 1 GAS GRILL LP Gas Grill Owner’s Guide Guía del Propietario del Asador de Gas Licuado de Propano - Pg. 37 ESNA Guide de L’Utilisateur du Grill à Gaz PL - Pg. 73 #56211 YOU MUST READ THIS OWNER’S GUIDE WARNING: Follow all leak-check BEFORE OPERATING YOUR GAS GRILL.

  • Page 2: Warnings

    WARNINGS DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. WARNINGS Do not attempt to disconnect any gas fitting while your barbecue is in operation.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS WARNINGS ......... . 2 SEAR STATION ®...

  • Page 4: Exploded View

    EXPLODED VIEW SUMMIT_470_LP_US_012011...

  • Page 5: Exploded View List

    EXPLODED VIEW LIST ® Shroud Hardware 22. Sear Station Knob 43. Smoker Burner Shroud 23. Battery Housing 44. Sear Station ® Burner Thermometer 24. Water Baffle / Heat Shield 45. Side Burner Thermometer Bezel 25. Disposable Drip Pan 46. Cookbox Handle 26.

  • Page 6: Warranty

    WARRANTY Weber-Stephen Products LLC (Weber) hereby warrants to the ORIGINAL PURCHASER of this Weber ® gas grill that it will be free of defects in material and workmanship from the date of purchase as follows: Aluminum castings: 25 years (2 years on paint; excludes fading) Stainless steel shroud: 25 years Porcelain-enameled shroud:...

  • Page 7: General Instructions

    GENERAL INSTRUCTIONS Your Weber ® gas barbecue is a portable outdoor cooking appliance. With the Weber ® STORAGE AND/OR NONUSE gas barbecue you can grill, barbecue, roast and bake with results that are difficult to ® ® duplicate with indoor kitchen appliances. The closed lid and Flavorizer bars produce barbecue is not in use.

  • Page 8: Gas Instructions

    GAS INSTRUCTIONS SAFE HANDLING TIPS FOR LIQUID PROPANE GAS CYLINDERS gas is a gas at regular temperatures and pressures. Under moderate pressure, inside a cylinder, LP gas is a liquid. As the pressure is released, the liquid readily vaporizes and becomes gas. dispersion.

  • Page 9: Important Lp Cylinder Information

    GAS INSTRUCTIONS IMPORTANT LP CYLINDER INFORMATION DANGER NEVER store a spare LP cylinder under or near Weber ® appliances. NEVER fill the tank beyond 80% full. Failure to follow these statements exactly may result in a fire causing death or serious injury. Weber ®...
  • Page 10 GAS INSTRUCTIONS A) Locate hose retention clip (1) on regulator hose. Secure into slot (2) on underside of tank scale. WARNING: The hose must be secured to the tank scale with the Hose Retention Clip. Failure to do so could cause damage to the hose resulting in a fire or explosion which can cause serious bodily injury or death, and damage to property.

  • Page 11: Check For Gas Leaks

    C) Remove the screws from the underside of the control panel with a Phillips screwdriver (2). D) Tilt the control panel forward and lift up and away from the grill (3). (For Summit ® models with LED features: Be careful not to break or disconnect the wires for the control panel LEDs.)
  • Page 12 GAS INSTRUCTIONS Check A) Main gas line to manifold connection (1). B) Rotisserie (I.R. Burner) gas line connection (2). C) Bulkhead and gas supply hose connection (3). D) Side burner hose to bulkhead connection (4). WARNING: If there is a leak at connection (1, 2, 3, or 4), retighten the fitting with a wrench and recheck for leaks with soap and water solution.

  • Page 13: Refilling The Liquid Propane Cylinder

    GAS INSTRUCTIONS REFILLING THE LIQUID PROPANE CYLINDER We recommend that you refill the LP cylinder before it is completely empty. Removal of the LP cylinder: A) Close cylinder valve (turn clockwise) (1). B) Unscrew regulator coupling by turning counterclockwise, by hand only (2). C) Loosen cylinder lock wing nut and turn cylinder lock up out of the way (3).

  • Page 14: Before Using The Grill

    BEFORE USING THE GRILL FUEL LEVEL There are two ways to check the fuel level in your tank; electronically and manually. To check the level using the Electronic Tank Scale, press the tank scale button, located on the right of the control panel, for 2-3 seconds. The LED indicates the fuel level in the tank.

  • Page 15: Snap Ignition Operation

    SNAP IGNITION OPERATION Always open the lid before igniting the burners. A) Each control knob has its own igniter electrode built in. To create a spark, you must push the control knob in (1) and turn it to START/HI (2). B) This action will generate gas flow and a spark to the burner lighting tube (3).

  • Page 16: Main Burner Ignition & Usage

    MAIN BURNER IGNITION & USAGE MAIN BURNER IGNITION Summary lighting instructions are inside the left-hand cabinet door. DANGER Failure to open the lid while igniting the barbecue’s burners, START/HI MEDIUM or not waiting five minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up which can cause serious bodily injury or death.

  • Page 17: Main Burner Manual Ignition

    MAIN BURNER IGNITION & USAGE MAIN BURNER MANUAL IGNITION DANGER Failure to open the lid while igniting the barbecue’s burners, or not waiting five minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up which can cause serious bodily injury or death.

  • Page 18: Grilling Tips & Helpful Hints

    GRILLING TIPS & HELPFUL HINTS FLAVORIZER ® SYSTEM ® bars, they create smoke that gives foods an irresistible barbecued flavor. Thanks to the unique design of the burners, Flavorizer ® bars, and the flexible temperature controls, more cooking time on cold or windy days, or at higher altitudes. Allow less cooking uncontrolled flare-ups are virtually eliminated, because YOU control the flames.

  • Page 19: Cooking Methods

    COOKING METHODS The most important thing to know about grilling is which cooking method to use for a 4 BURNER specific food, direct or indirect. The difference is simple: place the food directly over the fire, or arrange the fire on either side of it. Using the right method is the shortest route to great results—and the best way to ensure doneness safety.

  • Page 20: Side Burner Ignition & Usage

    SIDE BURNER IGNITION & USAGE SIDE BURNER IGNITION Summary lighting instructions are inside the left hand cabinet door. DANGER Failure to open the lid while igniting the side burner, or not START/HI waiting five minutes to allow the gas to clear if the side burner does not light, may result in an explosive flare-up which can cause serious bodily injury or death.

  • Page 21: Side Burner Manual Ignition

    SIDE BURNER IGNITION & USAGE SIDE BURNER MANUAL IGNITION DANGER Failure to open the lid while igniting the side burner, or not waiting five minutes to allow the gas to clear if the side burner does not light, may result in an explosive flare-up that can cause serious bodily injury or death.

  • Page 22: Sear Station Ignition & Usage

    SEAR STATION ® IGNITION & USAGE SEAR STATION ® BURNER IGNITION APAGADO Summary lighting instructions are inside the left hand cabinet door. ARRÊTÉ DANGER Failure to open the lid while igniting the barbecue’s burners, or not waiting five minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up which can cause serious bodily injury or death.

  • Page 23: Sear Station Burner Manual Ignition

    SEAR STATION ® IGNITION & USAGE ® SEAR STATION BURNER MANUAL IGNITION DANGER Failure to open the lid while igniting the barbecue’s burners, or not waiting five minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up which can cause serious bodily injury or death.

  • Page 24: Smoker Burner Ignition & Usage

    SMOKER BURNER IGNITION & USAGE SMOKER BURNER IGNITION APAGADO ARRÊTÉ DANGER Failure to open the lid while igniting the grill, or not waiting five minutes to allow the gas to clear if the grill does not light, may result in an explosive flare-up which can cause START/HI serious bodily injury or death.

  • Page 25: Smoker Burner Manual Ignition

    SMOKER BURNER IGNITION & USAGE SMOKER BURNER MANUAL IGNITION WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only Weber ®...

  • Page 26: Using The Smoker

    SMOKER BURNER IGNITION & USAGE USING THE SMOKER The smoker uses presoaked wood chips. For best results with faster cooking foods like steaks, burgers, and chops, etc., we recommend using finer wood chips because they ignite and create smoke faster. For longer cooking foods such as roasts, chicken, and turkeys, etc., we recommend using larger wood chunks because they ignite slowly and provide smoke for a longer period of time.

  • Page 27: Rotisserie Burner Ignition & Usage

    ROTISSERIE BURNER IGNITION & USAGE ROTISSERIE BURNER IGNITION APAGADO Rotisserie Burner Snap Ignition ARRÊTÉ Note: Each control knob snap igniter creates a spark from the igniter electrode to the burner lighting tube. You generate the energy for the spark by pushing in the control knob and turning to START/HI.

  • Page 28: Rotisserie Burner Manual Ignition

    ROTISSERIE BURNER IGNITION & USAGE ROTISSERIE BURNER MANUAL IGNITION ATTENTION: READ BEFORE LIGHTING ROTISSERIE BURNER After a period of non-use, before lighting the Rotisserie Burner, a few seconds must pass for the gas supply line to fill. When holding a match to the rotisserie burner you will see a flash of flames moving from left to right across the Rotisserie Burner surface, the Rotisserie Burner is not lit until the entire ceramic surface is aflame.

  • Page 29: Important Safeguards

    ROTISSERIE BURNER IGNITION & USAGE IMPORTANT SAFEGUARDS OPERATING THE ROTISSERIE Note: Before using your rotisserie, measure your food at the widest point. If it exceeds WARNING: Set up the rotisserie with food before lighting 9½" (241.8 mm), it is too large to fit the rotisserie. If it is too large, food can be prepared rotisserie burner.

  • Page 30: Rotisserie Cooking

    ROTISSERIE BURNER IGNITION & USAGE F) Insert the pointed end of the rotisserie shaft into the motor. Lower the rotisserie spit into the grooves on the cookbox (6). G) The rotisserie shaft should rotate so that the heavy side of the meat or poultry rotates down to the bottom.

  • Page 31: Troubleshooting

    TROUBLESHOOTING PROBLEM CHECK SOLUTION Burners burn with a yellow or orange flame, in Inspect Spider/Insect screens for possible obstructions. Clean Spider/Insect screens. Refer to “ANNUAL conjunction with the smell of gas. (This is normal for (Blockage of holes.) MAINTENANCE” . the burner lighting tube.) Symptoms: The excess flow safety device, which is part of the...

  • Page 32: Sear Station Troubleshooting

    SEAR STATION ® TROUBLESHOOTING PROBLEM CHECK SOLUTION Burners burn with a yellow or orange flame, in Inspect Spider/Insect Screens for possible obstructions. Clean Spider/Insect Screens. conjunction with the smell of gas. (This is normal for (Blockage of holes.) Refer to “ANNUAL MAINTENANCE” . the burner lighting tube.) Sear Station ®...

  • Page 33: Maintenance

    MAINTENANCE ® CLEANING WEBER SPIDER/INSECT SCREENS ® Your Weber gas barbecue, as well as any outdoor gas appliance, is a target for spiders WARNING: Turn your Weber ® gas barbecue off and wait for and other insects. They can nest in the venturi section (1) of the burner tubes. This it to cool before cleaning.

  • Page 34: Replacing Main Burners

    C) Remove the screws from the underside of the control panel with a Phillips screwdriver (2). D) Tilt the control panel forward and lift up and away from the grill (3). (For Summit ® models with LED features: be careful not to break or disconnect the wires for the control panel LEDs.)

  • Page 35: Side Burner Maintenance

    MAINTENANCE ® Removing The Sear Station Burner To remove the Sear Station Burner ® , pull the burner tube toward you. This removes it from the burner tube notch (7). Then rotate the tube clockwise (8), taking care to rotate it so that the screw at the end of the tube (9) fits through the notch in the heat shield opening (10).

  • Page 36: Annual Maintenance

    MAINTENANCE ANNUAL MAINTENANCE Inspection and Cleaning of the Spider/Insect Screens To inspect the spider/insect screens, remove the control panel. If there is dust or dirt on the screens, remove the burners to clean the screens. Brush the spider/insect screens lightly with a soft bristle brush (i.e., an old toothbrush). CAUTION: Do not clean the Spider/Insect screens with hard or sharp tools.
