Weber Summit 475 NG General Information Manual

Summit 475 NG
THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY.
Built-In Construction General Information
A Weber-Stephen Products Co. insulated sleeve must be used for any built-in installation.

LOCATING YOUR BARBECUE

When determining a suitable location for your barbecue installation, give attention to concerns such as exposure to wind, proximity to
traffic paths, and keeping any gas supply lines as short as possible. Never locate the Weber Gas Barbecue in a garage, breezeway,
shed, under an unprotected overhang, or other enclosed area. Locate the barbecue and structure so there is enough room to safely
evacuate the area in case of a fire.
CLEARANCE FROM NON-COMBUSTIBLE SURFACES OR
STRUCTURES
Warning: Clearance from the outside walls of the sides and
back of the insulated sleeve must be a minimum of 6 inches
from a non-combustible surface. Measure from the outside
wall of the insulated surface to the non-combustible
surface. Figure 1. Refer to "Install Gas Supply" on page 2
before starting installation.
NON- COMBUSTIBLE SURFACE
6 inches
Insulated sleeve
WARNING: All countertop finished surfaces must be
constructed of a noncombustible material.
Countertop
Figure 1
G
ENERAL
SUMMIT 475 & 675
Natural Gas Barbecues
Summit 675 NG
THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY.
WARNING
CLEARANCE FROM COMBUSTIBLE SURFACES OR
STRUCTURES
Warning: Clearance from the outside walls of the sides and
back of the insulated sleeve must be a minimum of 24
inches from a combustible surface. Measure from the
outside wall of the insulated surface to the combustible
surface. Figure 2. Refer to "Install Gas Supply" on page 2
before starting installation.
WARNING: All countertop finished surfaces must be
constructed of a noncombustible material.
I
NFORMATION
COMBUSTIBLE SURFACE
24 inches
Insulated sleeve
Figure 2
Countertop
98251 3/99
