Weber Summit 475 Step-By-Step Manual

Weber Summit 475 Step-By-Step Manual

Natural gas barbecues
Hide thumbs Also See for Summit 475:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual, Operating Manual
Summit 475 NG
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: F o l l ow all leak ch e ck pro c e d u r e s
carefully in this manual prior to barbecue
operation. Do this even if barbecue was
dealer assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
FOR YOUR SAFETY: Do not store or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
S U M M I T
Natural Gas Barbecues
Summit 675 NG
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
475 & 675
™
Step-By-Step Guide
gas supplier or your fire department.
97822
3/97

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Summit 475 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weber Summit 475

Summary of Contents for Weber Summit 475

  • Page 1 Summit 475 NG THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY. WARNING: F o l l ow all leak ch e ck pro c e d u r e s carefully in this manual prior to barbecue operation. Do this even if barbecue was dealer assembled.

  • Page 2: Install Gas Supply

    . This will result in a fire or ex p l o s i o n w h i ch can cause serious bodily injury or d e a t h , and damage to pro p e rt y. If you have any questions, contact the Weber-Stephen Customer Service Center at 1-888-33-SUMMIT (1-888-337-8664).
  • Page 3 Never locate the Weber Gas Barbecue in a garage, breezeway, shed, under an unprotected overhang, or other enclosed area. Locate the barbecue and structure so there is enough room to safely evacuate the area in case of a fire.
  • Page 4 BUILT-IN STRUCTURE CUTOUT DIMENSIONS All dimensions are to finished surfaces. Figure 3 BUILT-IN CUTOUT DIMENSIONS ⁄ ” ⁄ ” ⁄ ” ⁄ ” 25” 25” Weight (expressed in pounds) represents the total weight of the insulated sleeve and the cooking unit and does not include the permanent structure housing the sleeve.
  • Page 5 BUILT-IN SLEEVE GAS LINE LOCATIONS Support tubes Figure 6 BUILT-IN SLEEVE GAS LINE LOCATIONS 5.0” 5.0” 10.1” 10.1” 2.5” 2.5” The dimensions shown indicate the location of the gas line inlet flange in the insulated sleeve. The support members of the built-in structure must not impede passage of the gas lines.

  • Page 6: Remove Packaged Contents

    While we give much attention to our products, unfortunately an occasional error may occur. If a part is missing, do not go back to the store. Call the Weber Customer Service Center toll free 1-888-33-SUMMIT (1-888-337-8664) to receive immediate assistance.

  • Page 7: Add Cooking Module

    ADD COOKING MODULE Caution: Use two people to lift and install the cooking module. Lift the cooking module out of the packaging. The gas line will hang below the module. Lower the module on an angle into the sleeve so the control panel is under the front top rail.

  • Page 8: Install Flavorizer Bars

    Regulator Figure 11 INSTALL FLAVORIZER BARS You will need: seven (Summit 475) or eleven (Summit 675) flavorizer bars Set the Flavorizer bars front to back over the burners in the slots of the Flavorizer Bar/cooking grill support. Figure 12 (a).

  • Page 9: Add Cooking Grates

    Operating Guide. Summit 675 Figure 13 ADD COOKING GRATES You will need: two (Summit 475) or three (Summit 675) cooking grates. The cross-wire of the cooking grate goes down. Set the cooking grates in place next to each other. Figure 14.

  • Page 10: Install Burner Control Knobs

    Figure 15 (a). Figure 15 INSTALL BURNER CONTROL KNOBS You will need: four (Summit 475) or six (Summit 675) burner control knobs. Push on the burner control knobs. Figure 16. To regulator To regulator...

  • Page 11: Install Bottom Tray

    INSTALL BOTTOM TRAY You will need: Bottom tray, catch pan holder, catch pan, and one drip pan. Figure 17 Note: It may be easier to install the catch pan holder by removing the catch pan from the holder. Hook the ends of the catch pan holder into the hole in the bottom tray.

  • Page 12: Check For Gas Leaks

    CHECK FOR GAS LEAKS WARNING The gas connections of your Weber Gas Barbecue have been factory tested. We do h ow ever recommend that you leak ch e ck all gas connections before operating yo u r Weber Gas Barbecue.

  • Page 13: Check For Gas Leaks

    WA R N I N G : D o n o t i g n i t e bu r n e rs when leak ch e ck i n g . Manifold Summit 475 Figure 24 Manifold...

  • Page 14: Reinstall Control Panel

    R E I N S TALL FRONT PA N E L You will need: front panel. With the Weber logo to the left, slide front panel down into place. Figure 25. Figure 25 REINSTALL CONTROL PANEL You will need: control panel.

  • Page 15: Reinstall Burner Control Knobs

    REINSTALL BURNER CONTROL KNOBS You will need: four (Summit 475) or six (Summit 675) burner control knobs. Push on the burner control knobs. Figure 27. Figure 27 INSTALL TOOL HOLDERS You will need: four tool holders. Place the tool holder under the control panel and over the front panel on the right side.
