DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, Keep away from the
appliance and immediately call your
gas supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death or damage to property.
WARNING
1. Do not store spare LP Cylinder within
10 feet (3m) of this appliance.
2. Do not store or use gasoline or other
flammable liquids or vapors within 25
feet (8m) of this appliance.
SUMMIT
NATURAL GAS COOKING MODULES
®
4 BURNER
™
& 6 BURNER
Operating Guide
Read before assembly
Summit 6 Burner NG
Serial Number
Summit 4 Burner NG
Serial Number
WARNING: Follow all leak check procedures
carefully in this manual prior to barbecue
operation. Do this even if barbecue was
dealer assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this appliance
without reading "Lighting" instructions
section of this manual.
92774
10/98

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Summit 92774 and is the answer not in the manual?

Questions and answers

Related Manuals for Weber Summit 92774

Summary of Contents for Weber Summit 92774

  • Page 1 NATURAL GAS COOKING MODULES CANADIAN GAS ASSOCIATION ® A P P R O V E D DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid. 4. If odor continues, Keep away from the appliance and immediately call your gas supplier or your fire department.

  • Page 2: Warnings

    Open the lid and wait five minutes before attempting to relight, using the lighting instructions. Do not use charcoal or lava rock in your Weber Gas Barbecue. Never lean over open grill or place hands or fingers on the front edge of the cooking box.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warnings Warranty A Word of Thanks Standards and Codes Information Storage Operating Area Natural Gas Supply Testing *REFER TO YOUR STEP-BY-STEP SECTION AT THIS TIME Lighting Crossover Ignition System To Extinguish Manual Lighting To Extinguish Cooking Storage Cleaning Steam-N-Chips Smoker Maintenance...

  • Page 4: Warranty

    Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no such representations are binding on Weber.

  • Page 5: Standards And Codes Information

    The Weber Gas Barbecue is portable so you can easily change its location in your yard or on your patio. Portability means you can take your Weber Gas Barbecue with you if you move. The natural gas supply is easy to use and gives you more cooking control than charcoal fuel.

  • Page 6: Lighting

    LIGHTING EACH HEAT ZONE OPERATES INDEPENDENTLY. Summary lighting instructions are on the control panel. High Medium DANGER Failure to open lid while igniting the barbecue, or not waiting 5 minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flame- up which can cause serious bodily injury or death.

  • Page 7: Lighting

    LIGHTING (CONTINUED) Crossover Ignition System Summit 425 or 450 Crossover Ignition System Summit 475 Crossover Ignition System Summit 625 or 650 Crossover Ignition System Summit 675 Figure 1...

  • Page 8: Manual Lighting

    MANUAL LIGHTING EACH HEAT ZONE OPERATES INDEPENDENTLY. Summary lighting instructions are on the control panel. High Medium DANGER Failure to open lid while igniting the barbecue, or not waiting 5 minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flame- up which can cause serious bodily injury or death.

  • Page 9: Manual Lighting

    MANUAL LIGHTING (CONTINUED) 5) Put a match in the match holder and strike the match. 6) Insert match holder and lit match through matchlight hole to ignite LEFT burner. Figure 3. matchlight hole in control panel Control panel Left burner tube Figure 3 WARNING: Do not lean over open barbecue.

  • Page 10: Cooking

    You can adjust the LEFT and RIGHT burners as desired. The control settings High (H), Medium (M), Low (L), or Off (O) are described in your Weber cookbook. The cookbook uses these notations to describe the settings of the LEFT and RIGHT burners.

  • Page 11: Using The Steam-N-Chips Smoker

    Steam-N-Chips Smoker. To a lesser degree a "smoke" residue will accumulate on the inside of your Weber Gas Barbecue. This residue need not be removed and will not adversely affect the function of your Weber Gas Barbecue.

  • Page 12: Maintenance

    Lightly tap the burner to get debris and dirt out of the burner tube. Once the spider/insect screens and burners are clean replace the burners. If the spider/insect screen becomes damaged or cannot be cleaned, call Weber-Stephen Products Customer Service for replacement parts.

  • Page 13: Main Burner Flame Pattern

    CAUTION: Do not enlarge the burner ports when cleaning. Replacing Main Burners 1. Your Weber Gas Barbecue must be OFF and cool. 2. Turn OFF gas at source. 3. To remove control panel refer to “Remove the control panel and the front panel” in the Step-By-Step Guide.
  • Page 14 MAINTENANCE 7. Disconnect white and black wire from each igniter. Figure 11. White wire Figure 11 8. Pull the manifold out of the burners. Figure 12. Black wire Manifold Summit 4 Burner Manifold Summit 6 Burner Figure 12...
  • Page 15 MAINTENANCE 9. Slide the burner assembly from each Heat Zone. The left and right burners are connected by the Crossover tube. Figure 13 (a). Pull out of here Crossover tube Figure 13 10. Lift and twist the burner assembly slightly to separate the crossover tube from the burners.

  • Page 16: Maintenance

    Check to see if the igniter is loose in the frame. Tighten if necessary; See Step “Install igniter” for correct procedure. If the Crossover Ignition System still fails to light, contact Weber-Stephen Customer Service. White wire Black wire Figure 16...

  • Page 17: Troubleshooting

    Inside of lid appears to be “peeling.” (Resembles paint peeling.) If the problem cannot be corrected using these methods, please contact your Weber-Stephen Customer Service. Check Inspect Spider/Insect Screens for possible obstructions. (Blockage of holes.)

  • Page 20: Patents And Trademarks

    Flavorizer and Crossover are registered U.S. trademarks; Summit, Grill Cozy, Gas Catcher, Spider Stopper, and Steam-N-Chips, are trademarks, all of Weber-Stephen Products Co., 200 East Daniels Road, Palatine, IL 60067-6266. U.S.A. Summit Series Gas Barbecues are covered by U.S. Patent Nos. 4,677,964; 4,727,853; 4,777,927;...
