WARNING: Follow all leak check procedures
carefully in this manual prior to barbecue
operation. Do this even if barbecue was
dealer assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
FOR YOUR SAFETY: Do not store or use
gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
SUMMIT
Serial Number
WARNING: Do not try to light this appliance
without reading "Lighting" instructions section
of this manual.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
475 & 675
™
Built-in Sleeve
gas supplier or your fire department.
97070
12/96

Advertisement

loading
Need help?

Need help?

Do you have a question about the Summit 475 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weber Summit 475

Summary of Contents for Weber Summit 475

  • Page 1 SUMMIT 475 & 675 ™ Built-in Sleeve Serial Number WARNING: Do not try to light this appliance without reading "Lighting" instructions section WARNING: Follow all leak check procedures of this manual. carefully in this manual prior to barbecue operation. Do this even if barbecue was THIS GAS APPLIANCE IS DESIGNED FOR dealer assembled.
  • Page 2 REMOVE PACKAGED ASSEMBLE BACK PANEL PARTS TO BOTTOM PANEL Place the back panel perpendicular to the bottom panel. Insert screws and tighten. Figure 1. Back panel Bottom panel Figure 1 Left panel ASSEMBLE LEFT PANEL TO BOTTOM PANEL Place the left panel perpendicular to the bottom panel. Right panel Insert screws and tighten.
  • Page 3 ASSEMBLE RAILS TO ASSEMBLE BACK PANEL LEFT PANEL TO SIDE PANELS Insert screws along the side of the back panel. Tighten. Insert the rails into the left panel. Figure 3. Figure 5. View from back Figure 3 Figure 5 ASSEMBLE RIGHT PANEL TO BOTTOM PANEL Place the right panel perpendicular to the bottom panel.
  • Page 4 ADD SPACERS AND Once the bottom wire is in place, push it down so it snaps into the bottom flange to lock it in place. Figure 8. Close BUSHINGS the door. Turn the knob clockwise to close. Figure 9. Push in the bushings into the bottom holes of the side panels.
