FEATURE – 2D BARCODE SCANNING
Using the 2D barcode Scanner
The Infinea TAB 4 2D model uses a scan engine that supports one-dimensional
(1D) and two-dimensional (2D) barcode symbols. The effective reading
distance of the barcode reader varies depending on the barcode size.
Scanning 2D Barcodes
To scan a 2D barcode first activate the scanner. Then position the scan head
so that the light green rectangle is aimed at the barcode and the barcode is
within the width of the red illumination box.
Slowly pull back the device, which increases the distance between the barcode
and scanner until the barcode has been read by the scanner.
Tips:
Depending on the size of the barcode being scanned, you may need to slowly
pull back the unit increasing the distance between the barcode and scan head
until the barcode is within the imager's illumination box is shown in the figure
above.
