Akai ARC120 User Manual

Clockradio/cd-player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Clockradio/CD-player
User manual
Gebruiksaanwijzing
Manuel de l'utilisateur
Manual de instrucciones
Gebrauchsanleitung
Οδηγίες χρήσεως
ARC120
GB
2
NL 15
FR 29
ES 43
DE 57
EL 71

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARC120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Akai ARC120

Summary of Contents for Akai ARC120

  • Page 1 Clockradio/CD-player ARC120 User manual NL 15 Gebruiksaanwijzing FR 29 Manuel de l’utilisateur ES 43 Manual de instrucciones DE 57 Gebrauchsanleitung Οδηγίες χρήσεως EL 71...

  • Page 2: Table Of Contents

    Table of contents Safety ................3 Intended use ..............3 Labels in this manual ............3 General safety instructions ..........3 Preparations for use ........... 4 Unpacking ................4 Package contents ............4 Installation ..............5 Battery backup ..............5 Functions ..............7 Clockradio/CD player ............7 Operation ..............

  • Page 3: Safety

    ARC120 Safety Intended use The Clockradio/CD player wakes you up with music from CD or radio broadcast. The clock function includes an alarm and sleep program. Read the manual carefully before the first use. Labels in this manual WARNING A warning means that injury or death is possible if the instructions are not obeyed.

  • Page 4: Preparations For Use

    This appliance is double insulated; therefore no earth wire is required. Always check that the mains voltage corresponds to the voltage on the rating plate. This appliance employs a laser system. To prevent direct exposure to the laser beam, do not open the appliance. Visible laser radiation when open and interlock defeated.

  • Page 5: Installation

    ARC120 Installation ● Put the appliance on a horizontal flat surface. ● Connect the appliance to the mains. CAUTION ● Do not put the appliance near a heat source. ● Do not expose the appliance to direct sunlight. This appliance is equipped with rubber feet to prevent it from moving.
  • Page 6 ● Batteries are not included with this appliance. ● Batteries are not necessary for normal operation. Install batteries ● Remove the battery cover. ● Insert the batteries matching the (+) and (-) polarity markings. ● Re-install the battery cover. CAUTION Incorrect installation can cause battery leakage and corrosion which will damage the appliance.

  • Page 7: Functions

    ARC120 Functions Clockradio/CD player 10 11 12 13 14 Headphone jack VOLUME dial ALARM1 button ALARM2 button CLOCK ADJ button PROGRAM button REPEAT/RANDOM button DISPLAY button SLEEP button 10 Display 11 PLAY/PAUSE button 12 STOP button 13 SKIP FORWARD/HOUR button...
  • Page 8 Display 22 23 24 25 26 27 21 ALARM1 indicator 22 ALARM2 indicator 23 SLEEP indicator 24 PROGRAM indicator 25 REPEAT indicator 26 SNOOZE indicator 27 PM indicator 28 RANDOM indicator 29 POWER ON indicator...

  • Page 9: Operation

    ARC120 Operation ● To switch on the appliance, press the ON/OFF button (17). The POWER ON indicator (29) on the display lights up. To switch off the appliance, press the ON/OFF button (17) again. ● To adjust the volume level, turn the VOLUME dial (2) until the desired level is set.

  • Page 10: Alarm Function

    Alarm function This function is available in CD, AM/FM and BUZZER mode. Two time slots are available (ALARM1 and ALARM2). ● Switch the appliance off. ● Slide the FUNCTION switch (16) to the desired position (CD, AM/FM or BUZZER). Adjust the volume. - For AM/FM alarm, tune to the desired radio station ●...

  • Page 11: Cd Functions

    ARC120 CD functions ● To select the CD function, slide the FUNCTION switch (16) to the CD position. ● To insert a CD: - Open the appliance with the OPEN button (18). - Insert the CD with the label upwards.

  • Page 12: Cleaning And Maintenance

    ● Press the SKIP BACKWARD/MINUTE button (14) or the SKIP FORWARD/HOUR button (13) to select a desired track. ● Press the PROGRAM button (6) to confirm the selection. Repeat the previous step to select more tracks and confirm every selection with the PROGRAM button (6).

  • Page 13: Troubleshooting

    ARC120 Troubleshooting Trouble Action No display Switch on the appliance. Connect the appliance properly. Select the correct function with the FUNCTION switch (16). No sound Connect the appliance properly. Adjust the volume. Adjust tuning control. Check if the CD is inserted with the label upwards.

  • Page 14: Disposal Of Used Electrical And Electronic Equipment

    For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. For more information and warranty conditions, please visit: www.akai.eu...
