Owner's Manual
1
2
SmartOnline
3-Phase UPS System
™
3
Model: SU80K
Input/Output: 120/208V AC, 50/60 Hz, 3Ø, 4-wire + ground
4
Not suitable for mobile applications.
5
6
7
8
9
10
11
12
13
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2010 Tripp Lite. All trademarks are the sole property of their respective owners.
