THE GENERATOR

Figure 1.1 – 7 kW, Single Cylinder GH-410 Engine
Figure 1.2 – 12 kW/15 kW, V-twin GT-990/760 Engine
Oil
Dipstick
Exhaust
Enclosure
Oil Filter
Oil
Dipstick
Exhaust
Enclosure
Oil Filter
Section 1 — General Information
Air-cooled 7 kW, 12 kW and 15 kW Generators
Control
Panel
Data
Decal
Battery
Compartment
Control
Panel
Data
Decal
Battery
Compartment
GFCI
Outlet
Fuel
Regulator
Fuel
Inlet
GFCI
Outlet
Fuel
Regulator
Fuel
Inlet
Composite Base
