SeaLand 3300 Series Owner's Manual

Gravity discharge all-ceramic toilets
Hide thumbs Also See for 3300 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
GRAvITy dISchARGe ToILeT
!
WARNING
This manual must be read and under-
stood before installation, adjustment,
service, or maintenance is performed.
Modification of this product can
result in property damage.
oWNeR'S MANuAL
SeaLand
3300 Series
(with flush handle)

SeaLand
3300, 3400 Series
®
All-ceramic Toilets
(with remote flush switch)
dometic Sanitation corporation
SeaLand Product Customer Service: -800-32-9886
3400 Series
328 State Rt 226, PO Box 38
Big Prairie, OH 446
www.DometicUSA.com
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SeaLand 3300 Series

Summary of Contents for SeaLand 3300 Series

  • Page 1 This manual must be read and under- stood before installation, adjustment, service, or maintenance is performed. dometic Sanitation corporation Modification of this product can 328 State Rt 226, PO Box 38 result in property damage. Big Prairie, OH 446 SeaLand Product Customer Service: -800-32-9886 www.DometicUSA.com...

  • Page 2: Table Of Contents

    Your cooperation in having this information ready is appreciated and allows us to better meet your needs. Please refer to the Parts Distributor list in the Customer Service section. . Toilet Model Number 2. Serial Number 3. Part Number, Description and Quantity (see Parts List) SeaLand and flush and forget are registered trademarks of Dometic Corporation.

  • Page 3: Toilet Dimensions

    • 1/2-inch (12.7 mm) water line terminating in 1/2-inch MPT fitting (to connect to toilet water supply hose). • 4-bolt floor (closet) flange. SeaLand flanges available include 3-inch spigot, socket, MPT, or 45-degree swivel socket. • 2 VDC through 7- or 8-amp fuse or circuit breaker. Use 4-gauge stranded copper wire.
  • Page 4 STEP 5a: For through-the-floor water line and electrical wires, mark another centerline 6 inches (152 mm) from below-floor Installation the back wall (fig. 4). fig. 4 STEP 5b: For through-the-wall water line and electrical Above-floor Installation wires, mark a centerline 8 inches (203 mm) up from the floor centerline (fig.
  • Page 5 IMPoRTANT: If replacing an existing toilet that uses foR ModeL 3400 ToILeT a 2-bolt floor flange, drill two 5/16-inch dia. holes in old floor flange that align with two additional holes WITh ReMoTe SWITch in floor flange adapter. Use two #10 or 12 x 1-1/2-inch oPeRATIoN, see page 7 wood screws and washers for these drilled holes, for wall switch installation...
  • Page 6 STEP 16: With toilet close to floor flange, connect flex- STEP 19: Set the toilet in place (fig. 19) and secure to ible water supply hose to the water line fitting (fig. 17). floor with the #14x2-1/2 inch long lag bolts (fig. 20). Install decorative bolt caps by pushing them onto bolt heads (fig.

  • Page 7: Remote Flush Switch Installation

    ModeL 3400 ReMoTe fLuSh SWITch INSTALLATIoN 3400 series toilets feature a remote flush switch to control the “Flush” and “Add Water” functions. Follow the instructions below for switch installation. STEP : Select a location for the switch. 8 feet of cable (2.4 m) is provided. You may need to supply more wire, depending on how far you locate the switch from the toilet.

  • Page 8: Important Information Before Operation

    4. Never use drain openers, alcohol, solvents, etc. in the toilet. 5. If the toilet does not function properly, refer to the Troubleshooting section of this manual and repair as neces- sary. If problem persists, contact your local SeaLand product dealer or see the Customer Service section of this manual.

  • Page 9: Operating Instructions

    oPeRATING INSTRucTIoNS 1. Adding More Water To Toilet Bowl Pull up the flush handle (3300 model) or push "Add Water" switch (3400 model) until the desired water level is attained. To prevent overflowing the toilet, a timer inside the control module limits the amount of water that can be added.

  • Page 10: Manual Flush Operation

    Restore the shine with this cleaner. If you cannot find our brand in your area, contact SeaLand Product Customer Service for your nearest dealer. If it is not available, fig. A you can also use Bar Keepers Friend cleanser.

  • Page 11: Winterizing

    Vacuum Breaker Assembly deodoRANTS ANd SPecIAL TISSue Your SeaLand toilet requires the regular addition of a deodorant product to reduce malodors and to help break down holding tank contents. Several factors should be considered in selecting a deodorant product. Liquid or dry: Liquid products obviously work more quickly by readily going into solution. Granulated powder formulations, on the other hand, have the advantage of requiring less storage space and are less likely to leak if the package is inadvertently damaged.

  • Page 12: Flush Mechanism Components

    2. Remove access cover and/or flush switch from top of ceramic and wires if necessary. set it aside. Mode coNTRoL ModuLe fLuSh hANdLe coMPoNeNTS Switch (3300 series) Input flush cable flush handle flush Switch flush handle cable...

  • Page 13: Electrical Specifications

    ToILeT SySTeM eLecTRIcAL SPecIfIcATIoNS 12VDC Maximum standby current (amps): .070 Maximum operating current (amps): Flush motor locked rotor current (amps): 14.5 Maximum voltage Minimum voltage: Input power wire size 4 ga. All other wires size: 8 ga. Fuse size (amps)

  • Page 14: Troubleshooting

    TRoubLeShooTING A volt/ohmmeter (VOM) and the Toilet Wiring Diagram may be required for this section. caution: Portions of this section will require that power be applied to the toilet. Keep hands away from the flush ball, motor drive arm and rotor shaft to prevent personal injury during testing and troubleshooting. The control module uses a microprocessor to provide all the automatic and timing functions.

  • Page 15: Toilet Operation

    TRoubLeShooTING (cont’d) eRRoR code coRRecTIve PRoceduReS Condition Corrective Action Mode Switch in SERVICE position. Return Mode Switch to NORMAL position. Valve Open Limit Switch problem. With the flush valve fully open, check the “VALVE OPEN” status light. If the light is off, then the Valve Open Limit Switch is out of alignment or defective, or related wiring is defective.
  • Page 16 TRoubLeShooTING (cont’d) SyMPToM 3. flush valve will not close. Condition/Procedure Corrective Action • Return switch to the “Normal” position. Mode Switch is in SERVICE position: • Reset the control circuit by putting the Mode Switch in the SERVICE Foreign object prevents the flush position temporarily, then returning to the NORMAL position.
  • Page 17 TRoubLeShooTING (cont’d) SyMPToM 6. Water will not stay in bowl. Condition/Procedure Corrective Action Put Mode Switch in “Service” • Clean underside of flush valve ball seal of dirt and debris. position: Worn or damaged flush valve ball • Remove toilet from floor and remove base assembly from toilet and and seal: replace flush valve ball and seals.

  • Page 18: Wiring Diagrams

    WIRING dIAGRAMS 3300 SERIES (with flush handle) 3400 SERIES (with remote flush switch)

  • Page 19: Customer Service

    Distributor nearest you for quick response to your replacement Center near you, please call from 8:00 a.m. to 5:00 p.m. (ET) parts needs. They carry a complete inventory for the SeaLand Monday through Friday. You may also write us at Dometic product line.
  • Page 20 MANufAcTuReR’S TWo-yeAR ANd TeN-yeAR LIMITed WARRANTIeS MANufAcTuReR’S TWo-yeAR ANd TeN-yeAR LIMITed WARRANTIeS Dometic Corporation warrants, to the original purchaser only, that this SeaLand gravity discharge toilet, if used for ® personal, family or household-like purposes, is free from defects in material and workmanship for a period of two (2) years from the date of purchase.
