SeaLand 1 2500 Series Owner's Manual

Cassette vacuum tank portable or permanent holding tank system for use with vacuflush ceramic toilet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2500 Series
CASSETTE VACUUM TANK
OWNER'S MANUAL
Portable (2510) or Permanent (2520, 2521) Holding Tank System
for use with VacuFlush
Ceramic Toilet
®
2520
2510
NOTICE:
!
WARNING
This product is
This manual must be read and understood
not recommended
before service or maintenance is performed.
for use on sailboats.
Modification of this product can result in
property damage.
Dometic Corporation • Sanitation Systems
13128 State Rt. 226, P.O. Box 38
Big Prairie, OH 44611-0038 USA
SeaLand Product Hotline 1-800-321-9886
(8:00 a.m. - 5:00 p.m. ET)
www.DometicSanitation.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1 2500 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SeaLand 1 2500 Series

Summary of Contents for SeaLand 1 2500 Series

  • Page 1 Modification of this product can result in property damage. Dometic Corporation • Sanitation Systems 13128 State Rt. 226, P.O. Box 38 Big Prairie, OH 44611-0038 USA SeaLand Product Hotline 1-800-321-9886 (8:00 a.m. - 5:00 p.m. ET) www.DometicSanitation.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction ......2 For Your Safety......2 System Components .

  • Page 3: Installation

    INSTALLATION DOCKING PLATFORM RISER 1. The riser section of the docking platform is mounted on a level floor using four screws (not supplied). The floor must be strong enough to support the weight of the cassette when full (about 40 lbs. – 18 kg). BACK DOCKING PLATFORM BASE 1.

  • Page 4: Inserting Cassette Tank

    INSTALLATION (cont’d) INSERTING CASSETTE TANK Place the cassette tank on the dock- ing platform, then push the cassette tank toward the back of the docking platform until the latch engages (A). CONNECTING SANITATION HOSE Maximum difference in height from toilet to cassette is 3 ft. (1 m).

  • Page 5: How To Make Installation Easier

    INSTALLATION (cont’d) HOW TO MAKE SYSTEM INSTALLATION (AND MAINTENANCE) EASIER When connecting flexible hose to plastic fittings, use liquid dish soap on end of fitting and inside hose end to make connection easier. A clockwise twist of the fitting while inserting it into the hose makes connection easier.

  • Page 6: Electrical Installation

    INSTALLATION (cont’d) ELECTRICAL INSTALLATION Electrical installation must be performed by qualified personnel only! The 12V DC connection to the toilet electronics is shown in the photo. Connect by correct polarity: RED + WHITE – The connection wire must be 14-gauge stranded copper wire, and must be protected by a 5-amp fuse (see wiring diagram).

  • Page 7: Wiring Diagram

    WIRING DIAGRAM 1 – “Tank Full” Float Switch 2 – Tank Interlock Switch 3 – Vacuum Switch 4 – Vacuum Pump Motor...

  • Page 8: Removing Cassette Tank

    OPERATION DISPLAY PANEL GREEN – Ready to flush. RED – Cassette full, or cassette removed, or undervoltage. Toilet cannot be flushed. YELLOW – Vacuum pump is running. Do not flush toilet. START-UP CHECKLIST Before first-time use of the 2500 series sanitation system, check the following: •...

  • Page 9: Operation

    OPERATION (cont’d) EMPTYING CASSETTE TANK (model 2510) 1. Carry cassette tank to disposal facility. 2. With tank sitting level, open large cap (A), and pour contents into disposal receptacle. 3. If possible, rinse the cassette with fresh water each time it is emptied.

  • Page 10: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Problem 1. Vacuum pump will not run. 2. Vacuum pump will not shut off. 3. Vacuum pump is running too slow, overheating, blowing fuses or circuit breaker. 4. Toilet will not flush. 5. Tank will not discharge us- ing dockside pump (model 2520/2521).

  • Page 11: Specifications

    You may also contact or have your local dealer contact the Parts Distributor nearest you for quick response to your replacement parts needs. They carry a complete inventory for the SeaLand product line. Fax: U.S.A. - Southwest (AZ, CO, NV, UT, CA-south)

  • Page 12: Manufacturer's One-Year Limited Warranty

    MANUFACTURER’S ONE-YEAR LIMITED WARRANTY Dometic Corporation warrants, to the original purchaser only, that this product, if used for personal, family or household-like purposes, and if installed according to Dometic’s recommended procedures, is free from defects in material and workmanship for a period of one year from the date of purchase. If this Dometic product is placed in commercial or business use, it will be warranted, to the original purchaser only, to be free of defects in material and workmanship for a period of ninety (90) days from the date of purchase.
