SeaLand
®
GRAvITy DISChARGe ToILeT
oWNeR'S MANuAL
SeaLand
500 Plus Series, 2000 Series,
®
Model 111 Toilet
WARNING
!
This manual must be read and under-
stood before installation, adjustment,
service, or maintenance is performed.
Modification of this product can result
in property damage.
Dometic Sanitation Corporation
328 State Rt 226, PO Box 38
Big Prairie, OH 446
SeaLand Product Customer Service: -800-32-9886
www.DometicUSA.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SeaLand 510+
Summary of Contents for SeaLand 510+
- Page 1 This manual must be read and under- stood before installation, adjustment, service, or maintenance is performed. Modification of this product can result in property damage. Dometic Sanitation Corporation 328 State Rt 226, PO Box 38 Big Prairie, OH 446 SeaLand Product Customer Service: -800-32-9886 www.DometicUSA.com...
-
Page 2: Table Of Contents
2. Do not permit foreign objects (paper towels, paper cups, diapers, sanitary napkins, etc.) to be flushed through the toilet. 3. Mechanical seal toilets, like SeaLand units, are designed to only discharge directly into a holding tank. Horizontal pipe runs as found in conventional residential or commercial plumbing systems cannot be accommodated. -
Page 3: Installation
Fig. B glazing compound around the circumference of the floor flange (Figure C). 5. SeaLand toilet models , 50 and 5 will accept handicap or household deco- rative seats. Remove existing seat and replace with new seat if desired. 6. Position floor seal by pressing the floor bolts up through holes in the seal. -
Page 4: Proper Bowl Cleaning
SeaLand toilets. In certain locations where water is hard, a build-up fig. A of lime may dull the toilet bowl finish. Restore the shine with this SeaLand cleaner. If you cannot find it in your area, contact Dometic for your nearest dealer. If the cleaner... -
Page 5: Deodorants And Special Tissue
DeoDoRANTS AND SpeCIAL TISSue SeaLand toilets require the regular addition of a deodorant product to reduce holding tank malodors and to help break down holding tank contents. Several factors should be considered in selecting a deodorant product. Liquid or Granulated: Liquid products obviously work more quickly by readily going into solution. Granulated powder formulations, on the other hand, have the advantage of requiring less storage space and are less likely to leak if the package is inadvertently damaged. -
Page 6: Troubleshooting Guide
CoNNeCTIoN problem possible Cause Service Instructions a. Odor emitting from base of toilet. a. Use SeaLand brand deodorants. 1. Toilet emits odor (flush ball open). b. Plugged holding tank vent line. b. Clear obstruction from vent line. a. Loose band clamp. - Page 7 Loosen mounting bolts and push completely. Applies to ball rotation. toilet base back. If this does not short-base units mounted solve problem, install a SeaLand on step or riser only. Universal Mounting Kit (part no. 310139, 310140, or 310141) with existing floor flange.
-
Page 8: Ordering Parts
Email: sealand@dometicusa.com MANufACTuReR’S TWo-yeAR AND TeN-yeAR LIMITeD WARRANTIeS Dometic Corporation warrants, to the original purchaser only, that this SeaLand gravity discharge toilet, if used for personal, ® family or household-like purposes, is free from defects in material and workmanship for a period of two (2) years from the date of purchase.
