Summary of Contents for Austin Hughes Electronics HAP—15AV Series

  • Page 1: User Manual

    User Manual Innovative LCD Display Solutions HAP — 15AV Series HDP — 15AV Series HOP — 15AV Series UMUV.15H-045V1...
  • Page 2: Table Of Content

    HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 1. Table of Content Table of Content Page.1 Introduction A) Overview Page.2 B) Features Page.2 C) Dimension Diagrams Page.3-5 D) Technical Specifications Page.6 Installation A) Package Contents Page.7 B) Caution to the user Page.7 C) Cleaning Page.7...
  • Page 3 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 2. Introduction Overview This LCD monitor incorporates 15”color active matrix thin-film-transistor (TFT) liquid crystal display to provide superior display performance. A maximum resolution of 1024 x 768 is ideal for displaying complex graphics and high definition images.
  • Page 4 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 2. Introduction Dimension Diagrams HAP-15AV series Apr 05...
  • Page 5 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 2. Introduction Dimension Diagrams HDP-15AV series Apr 05...
  • Page 6 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 2. Introduction Dimension Diagrams HOP-15AV series Apr 05...
  • Page 7 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 2. Introduction Technical Specifications Panel 15" LCD Panel Display Type TFT LCD active matrix colour Resolutions 1024 x 768 Response Time Tr=5ms, Tf=20ms Contrast Ratio 500:1 typical Brightness 1400 cd/m typical Monitor Pixel Pitch 0.297(H) x 0.297(V) Panel Colour...
  • Page 8 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 3. Installation Package Contents After unpacking the carton, check and see if the following items are included in good condition. Contact your supplier as soon as possible for replacing the missing / damaged items. 15”...
  • Page 9 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 3. Installation Precautions Read all of these instructions and save them for later use. Follow all warnings and instructions on the product. Product Do not cover or block the vent holes in the case. ●...
  • Page 10 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 3. Installation Precautions (Cont.) Power and extension cords 1. Do not allow anything to rest on the power cord. 2. Do not locate this product where persons will walk on the cord. 3.
  • Page 11: Using The System

    HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Product Views HAP Series - Front View HAP Series - Rear View Apr 05 P.10...
  • Page 12 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Product Views (Cont.) HDP Series - Front View HDP Series - Rear View Apr 05 P.11...
  • Page 13 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Product Views (Cont.) HOP Series - Front View HOP Series - Rear View Apr 05 P.12...
  • Page 14 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System I/O Outlet Front AP Series DP Series OP Series : Connect to power cable. (1) DC IN : Connect to D-Sub 15 pin signal connector. (2) PC IN (3) S-Video IN :...
  • Page 15 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Installation Procedures This monitor is equipped with an auto-sensing power supply for voltage ranges 100~240V, 50~60Hz. Please follow the following instruction to install LCD monitor. 1. Make sure that the system power is turned off. 2.
  • Page 16 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Setup Touchscreen Touchscreen used for UltraView products are manufactured by 3M. Here provide TouchWare Software includes touch screen drivers for your installing. Note: To configure the settings of the touchscreen, please refer to the TouchWare User Guideline Note: If you have a Microsoft®...
  • Page 17 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Setup Touchscreen For Windows 95, 98, Me, NT4.0, 2000 & XP (Cont.) Once installation is complete, restart the system. As the system restarts, Windows detects and loads the driver. For serial controllers, restart the system.
  • Page 18 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Setup Touchscreen For DOS (Cont.) Type INSTALL followed by the source disk drive, the destination drive, and the destination directory. For example, the following command copies the files from Drive A (source drive) to Drive C (destination drive) and the \MTS\TOUCH directory : INSTALL A: C:\MTS\TOUCH Press Enter.
  • Page 19 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System Setup Touchscreen For DOS (Cont.) Loading the DOS Touchscreen Driver After you install the files for the DOS touchscreen driver, you must load the driver before you can run a DOS touch application or open the DOS Touchscreen control panel.
  • Page 20 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Switch Power Menu/Selection Right Exit Left Input Select: This button is used to select CVBS for composite video input, RGB for VGA input and S-Video for Super-Video input OSD Menu: This button is used to enter OSD main Menu Increase(à):...
  • Page 21: Main Menu

    HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For VGA Input Version LCD Membrane Diagram Power Menu/Selection Exit Right Left MAIN MENU BRIGHT/CONTRAST AUTO ADJUST PHASE/CLOCK H/V POSITION MISC RESET Main Menu Bright / Contrast To enter into the Bright, Black level &...
  • Page 22 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For VGA Input Version Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● to “Brightness” Use the Left & Right button to adjust and button ●...
  • Page 23 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For VGA Input Version MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ●...
  • Page 24 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For Video Input Version Main Menu Image To enter into the Brightness, Contrast, Sharpness, Saturation, Hue sub- ● menu Geometry To enter into Auto Conflg., H. Position, V. Position, Clock, phase sub-menu ●...
  • Page 25 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For Video Input Version OSD Control For Video Input Version Image Brightness To adjust brightness level of the input signal Use the q button to select the function, then use t/u button to adjust from 0-100 Contrast To adjust the contrast level of the input signal button to select the function, then use t/u button to adjust from 0-100...
  • Page 26 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For Video Input Version Geometry Auto Conflg To perform auto adjustment of the screen output. button to select the function, then use the t/u button to select “ Auto Conflg” Use the H.
  • Page 27 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For Video Input Version Function OSD Position To perform OSD position selection of the screen button to select the function, then use the t/u button to select the digit for Use the the OSD display region.
  • Page 28 HAP-15AV / HDP-15AV / HOP-15AV Series User Manual 4. Using the System OSD Control For Video Input Version OSD Control For Video Input Version System Language To perform Language selection of the function display use the t/u button to select suitable Use the button to select the function, then display language “...
