Page 1: User Manual
User Manual Innovative LCD Display Solutions AP — 10AV Series DP — 10AV Series OP — 10AV Series UMUV.10-045V2... -
Page 2: Table Of Content
AP-10AV / DP-10AV / DP-10AV Series Table of Content Introduction Installation Using the System Apr 05 1. Table of Content A) Overview B) Features C) Dimension Diagrams D) Technical Specifications A) Package Contents B) Caution to the user C) Cleaning D) Precautions A) Product Views B) I/O Outlet... - Page 3 AP-10AV / DP-10AV / DP-10AV Series Overview This LCD monitor incorporates 10.4”color active matrix thin-film-transistor (TFT) liquid crystal display to provide superior display performance. A maxi- mum resolution of 800 x 600 is ideal for displaying complex graphics and high definition images.
- Page 4 AP-10AV / DP-10AV / DP-10AV Series User Manual 2. Introduction Dimension Diagrams AP-10AV series Apr 05...
- Page 5 AP-10AV / DP-10AV / DP-10AV Series User Manual 2. Introduction Dimension Diagrams DP-10AV series Apr 05...
- Page 6 AP-10AV / DP-10AV / DP-10AV Series User Manual 2. Introduction Dimension Diagrams OP-10AV series Apr 05...
-
Page 7: Technical Specifications
AP-10AV / DP-10AV / DP-10AV Series Monitor Power Supply Connectors Video Product Dimension Packing Dimension Net / Gross Weight Apr 05 2. Introduction Technical Specifications Panel 10.4" LCD Panel Display Type TFT LCD active matrix colour Resolutions 800 x 600 Response Time Tr=15ms, Tf=25ms Contrast Ratio... -
Page 8: Installation
AP-10AV / DP-10AV / DP-10AV Series Package Contents After unpacking the carton, check and see if the following items are included in good condition. Contact your supplier as soon as possible for replacing the missing / damaged items. 10.4” TFT LCD monitor ●... - Page 9 AP-10AV / DP-10AV / DP-10AV Series Precautions Read all of these instructions and save them for later use. Follow all warnings and instructions on the product. Product Do not cover or block the vent holes in the case. ● Do not insert sharp objects or spill liquid into the LCD monitor through ●...
- Page 10 AP-10AV / DP-10AV / DP-10AV Series Precautions (Cont.) Power and extension cords 1. Do not allow anything to rest on the power cord. 2. Do not locate this product where persons will walk on the cord. 3. Use the proper power cord with correct attachment plug type. If the power source is 120V AC, use a power cord that has UL and C-UL approvals.
- Page 11 AP-10AV / DP-10AV / DP-10AV Series User Manual 3. Installation Product Views AP Series - Front View AP Series - Rear View Apr 05 P.10...
- Page 12 AP-10AV / DP-10AV / DP-10AV Series User Manual 3. Installation Product Views (Cont.) DP Series - Front View DP Series - Rear View Apr 05 P.11...
- Page 13 AP-10AV / DP-10AV / DP-10AV Series User Manual 3. Installation Product Views (Cont.) OP Series - Front View OP Series - Rear View Apr 05 P.12...
-
Page 14: Using The System
AP-10AV / DP-10AV / DP-10AV Series I/O Outlet DC IN PC IN RCA IN S-Video IN ： Connect to the S-Video cable connector. (for AV series only) USB IN SERIAL IN Apr 05 4. Using the System ： Connect to DC power cable. ：... -
Page 15: Installation Procedures
AP-10AV / DP-10AV / DP-10AV Series Installation Procedures This monitor is equipped with an auto-sensing power supply for voltage ranges 100~240V, 50~60Hz. Please follow the following instruction to install LCD monitor. 1. Make sure that the system power is turned off. 2. - Page 16 Windows desktop and control panel. TouchWare will also determine multiple monitor configurations at this time. For details of Custom option, please refer to the website of 3M and download the user guide of TouchWare software. (http:// www.3m.com/3MTouchSystems/downloads/tecdoc.jhtml) P.15...
- Page 17 AP-10AV / DP-10AV / DP-10AV Series Setup Touchscreen For Windows 95, 98, Me, NT4.0, 2000 & XP (Cont.) Once installation is complete, restart the system. As the system restarts, Windows detects and loads the driver. For serial controllers, restart the system. As the system restarts, Win- ●...
- Page 18 AP-10AV / DP-10AV / DP-10AV Series Setup Touchscreen For DOS (Cont.) Type INSTALL followed by the source disk drive, the destination drive, and the destination directory. For example, the following command copies the files from Drive A (source drive) to Drive C (destination drive) and the \MTS\TOUCH directory : INSTALL A: C:\MTS\TOUCH Press Enter.
- Page 19 AP-10AV / DP-10AV / DP-10AV Series Setup Touchscreen For DOS (Cont.) Loading the DOS Touchscreen Driver After you install the files for the DOS touchscreen driver, you must load the driver before you can run a DOS touch application or open the DOS Touchscreen control panel.
- Page 20 AP-10AV / DP-10AV / DP-10AV Series OSD Switch Power Apr 05 4. Using the System Menu/Selection Right Exit Left Input Select: This button is used to select CVBS for composite video input, RGB for VGA input and S-Video for Super-Video input OSD Menu: This button is used to enter OSD main Menu Increase(à):...
-
Page 21: Main Menu
AP-10AV / DP-10AV / DP-10AV Series OSD Control For VGA Input Vesion LCD Membrane Diagram Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ●... - Page 22 AP-10AV / DP-10AV / DP-10AV Series OSD Control For VGA Input Version Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● Use the Left & Right button to adjust and button ● 2. Contrast To adjust the contrast level of the input signal ●...
- Page 23 AP-10AV / DP-10AV / DP-10AV Series OSD Control For VGA Input Version MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●...
-
Page 24: Colour Configuration Page
AP-10AV / DP-10AV / DP-10AV Series OSD Control For Video Input Version Apr 05 4. Using the System Colour Configuration Page Colour Brightness Contrast Colour Adjust Exit Brightness ︰ Adjust the brightness value from 1 to 100 using (à) and (ß) buttons. Contrast ︰... - Page 25 AP-10AV / DP-10AV / DP-10AV Series OSD Control For Video Input Version Apr 05 4. Using the System Picture Configuration Page Picture H.Position V.Position Sharpness Phase Clock Exit H.Position ︰ Press (à) shifting display image to right with value from 0 to 100; Press (ß) shifting display image to left from value 0 to 100.
-
Page 26: Auto Adjust
AP-10AV / DP-10AV / DP-10AV Series OSD Control For Video Input Version Apr 05 4. Using the System Function Configuration Page Function Auto Adjust Auto Position Auto Phase Auto Clock Exit Auto Adjust ︰ Enable or disable function for auto adjusting brightness, contrast, color etc. Yes ︰... -
Page 27: Osd Timer
AP-10AV / DP-10AV / DP-10AV Series OSD Control For Video Input Version Apr 05 4. Using the System OSD Menu Configuration Page OSD Menu Language OSD H.Position OSD V.Position OSD Timer Translucent Exit Language ︰ Change language of OSD Menu for English or traditional Chinese OSD H.Position ︰... -
Page 28: Miscellaneous Configuration Page
AP-10AV / DP-10AV / DP-10AV Series OSD Control For Video Input Version Apr 05 4. Using the System Miscellaneous Configuration Page Miscellaneous Mode Select Reset Exit Mode Select ︰ Switch the display size for 640 x 400 or 720 x 400 in DOS mode Reset ︰...
