- Page 1 Betriebsanleitung / Operating Manual Monitor SCENICVIEW B15-1A Deutsch - English...
- Page 2 Sie haben ..technische Fragen oder Probleme? Wenden Sie sich bitte an unseren Help Desk (siehe Garantieheft). Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet: http://www.fujitsu-siemens.com Are there ..any technical problems or other questions you need clarified? Please contact our Help Desk (see Warranty Booklet).
- Page 4 Este manual ha sido impreso sobre papel reciclado. Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH A26361-K938-Z100-1-5E19 Bestell-Nr./Order No.: Printed in China AG 1103...
-
Page 5: Lcd Monitor
Deutsch English SCENICVIEW B15-1A LCD-Bildschirm LCD monitor Betriebsanleitung Operating Manual TCO'99 Ausgabe November 2003 November 2003 edition... - Page 6 Dieses Handbuch wurde erstellt von cognitas. Gesellschaft für Technik-Dokumentation mbH www.cognitas.de Copyright Fujitsu Siemens Computers GmbH 2003 VESA, DDC and DPMS are registered trademarks of Video Electronics Standards Association. All rights, including rights of translation, reproduction by printing, copying or similar methods, even of parts are reserved.
-
Page 7: Table Of Contents
Contents Introduction............................1 Notational conventions.......................2 Important notes ..........................2 Safety notes..........................2 Cleaning ............................3 Transport ...........................3 Power cable..........................4 Energy Star Guidelines ......................4 CE marking..........................4 FCC Class B Compliance Statement ..................4 Declaration of Conformity ......................5 Disposal and recycling .......................6 Checking the contents of the consignment ..................6 Installing an ergonomic video workstation..................7 Mounting and removing the monitor base ..................8 Folding monitor base out and in....................8... -
Page 9: Introduction
This operating manual contains important information you require to start up and run your LCD monitor. A screen controller with VGA interface is required to control the SCENICVIEW B15-1A LCD monitor. The monitor processes the data supplied to it by the screen controller. The screen controller/the associated driver software is responsible for setting the modes (resolution and refresh rate). -
Page 10: Notational Conventions
Colour monitor SCENICVIEW B15-1A Notational conventions The meanings of the symbols and fonts used in this manual are as follows: Pay particular attention to text marked with this symbol. Failure to observe this warning endangers your life, destroys the device, or may lead to loss of data. -
Page 11: Cleaning
Colour monitor SCENICVIEW B15-1A • If you use a different data cable from the one supplied, ensure that it is adequately shielded. CE conformance and optimum picture quality are guaranteed only if you use the data cable supplied. • No data transfer cables should be connected or disconnected during a thunderstorm. -
Page 12: Power Cable
20 million tons of carbon dioxide into the atmosphere - the equivalent of 5 million automobiles. As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product meets the Energy Star guidelines for energy efficiency. -
Page 13: Declaration Of Conformity
• Consult the dealer or an experienced radio/TV technician for help. Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused by unauthorised modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The correction of interference caused by such unauthorised modification, substitution or attachment will be the responsibility of the user. -
Page 14: Disposal And Recycling
Colour monitor SCENICVIEW B15-1A Disposal and recycling This device has been manufactured to the highest possible degree from materials which can be recycled or disposed of in a manner that is not environmentally damaging. The device may be taken back after use to be recycled, provided that it is returned in a condition that is the result of normal use. -
Page 15: Installing An Ergonomic Video Workstation
Colour monitor SCENICVIEW B15-1A Installing an ergonomic video workstation Before you set up your equipment, you should select a suitable position for working at the monitor. Please observe the following advice when installing a video workstation. 600 mm 600 mm... -
Page 16: Mounting And Removing The Monitor Base
Colour monitor SCENICVIEW B15-1A Mounting and removing the monitor base The monitor surface is susceptible to scratching! Therefore, lay the monitor on a soft surface when mounting or removing the monitor base. Folding monitor base out and in On delivery the monitor base is folded in. - Page 17 Colour monitor SCENICVIEW B15-1A ► Lay the monitor on its face on a soft surface. ► Remove the cover (2) and disconnect all cables. ► Remove the four screws on the rear of the monitor (1). ► Remove the covers (3 and 4) by pressing on the plastic parts and simultaneously pulling them outward.
-
Page 18: Connecting The Monitor
Colour monitor SCENICVIEW B15-1A Connecting the monitor Observe the "Safety notes" in the "Important notes" chapter in this operating manual. CE conformance and optimum picture quality are guaranteed only if you use the data cable supplied. Do not cover the ventilation openings of the monitor. -
Page 19: Connecting Cables To The Computer
Colour monitor SCENICVIEW B15-1A Connecting cables to the computer Information on the computer connections and interfaces is contained in the operating manual for your computer. If your computer has two monitor ports ("onboard" screen controller and separate graphics card), the monitor port for the separate graphics card is usually active. -
Page 20: Switching The Monitor On/Off
Colour monitor SCENICVIEW B15-1A Switching the monitor on/off 1 = Buttons for the OSD menu (On-Screen-display) 2 = Power indicator 3 = ON/OFF switch 4 = Headphones port The ON/OFF switch (3) is used for switching the monitor on and off. -
Page 21: Changing The Monitor Settings
Colour monitor SCENICVIEW B15-1A Once an input is made at the computer the screen contents are redrawn and full power is restored. For detailed information on how energy-saving mode operates refer to the operating manual or technical manual of the computer. -
Page 22: Monitor Settings Using The Osd Menu
Colour monitor SCENICVIEW B15-1A Adjusting background lighting ► Press the button for calling the Brightness setting window. ► Press the button to adjust the brightness. This setting window can also be called, when the OSD menu is locked. Activating/deactivating muting ►... - Page 23 Colour monitor SCENICVIEW B15-1A To set the OSD menu, perform the following steps: ► Press the SELECT/MENU button to activate the OSD menu. The main menu appears on the screen (on the left-hand side) with icons for the setting functions.
- Page 24 Colour monitor SCENICVIEW B15-1A Adjusting the brightness and contrast Calling the Brightness / Contrast setting window. Setting the brightness of the display Brightness With this function you change the brightness of the background lighting. Setting the contrast of the display Contrast With this function you modify the contrast of bright colour tones.
- Page 25 Colour monitor SCENICVIEW B15-1A Setting colour temperature and colours Calling the Colour setting window Selecting the colour temperature The "warmth" of the screen colours is set using the colour temperature. The colour temperature is measured in K (= Kelvin). You can select from 6500 K , 9300 K , Native and Custom Colour .
-
Page 26: Notes On Ergonomic Colour Adjustment
Colour monitor SCENICVIEW B15-1A Factory Recall Activating the factory settings With this function all settings are reset to the factory settings without prompting for confirmation. Press the SELECT/MENU button to activate the function. The Auto Processing message is displayed. Displaying information... -
Page 27: Technical Data
Colour monitor SCENICVIEW B15-1A Technical data Dimensions and weight (LCD monitor) Visible diagonals: 38 cm Dot pitch: 0.297 mm Screen size: 304 mm x 228 mm Maximal resolution: 1024 x 768 pixels Dimensions (W x H x D) incl. monitor base: 354 mm x 338 mm x 190 mm (folded out) 354 mm x 338 mm x 96.8 mm (folded in) -
Page 28: Vesa-Ddc-Compatible Vga Interface
VGA interface, it can automatically read the data for ensuring optimum operation from your monitor and select the appropriate settings. If the monitor SCENICVIEW B15-1A is not yet displayed in the list of monitors, you can select the following monitor instead:... -
Page 29: Pin Assignment D-Sub
Colour monitor SCENICVIEW B15-1A Pin assignment D-SUB Meaning Meaning Video input red +5 V (DDC) Video input green Sync. ground Video input blue Ground Ground DDC-Data Ground H. sync Red video ground V. sync Green video ground DDC Clock Blue video ground Trouble shooting Should an error occur, first check the following points. - Page 30 Colour monitor SCENICVIEW B15-1A Having this problem? Check the following points: Message: The input signal (horizontal frequency and refresh rate) at the displayed input does not Frequency out of range: correspond to the technical monitor data. ## kHz / ## Hz ►...
- Page 31 Colour monitor SCENICVIEW B15-1A Having this problem? Check the following points: Permanently unlit or lit pixels The standard of production techniques today cannot guarantee an absolutely fault-free screen display. A few isolated constant lit or unlit pixels may be present. The maximum permitted...
-
Page 32: Why Do We Have Environmentally Labelled Computers
TCO'99 Congratulations You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. -
Page 33: Environmental Requirements
TCO'99 Below you will find a brief summary of the environmental requirements met by this product. The complete environmental criteria document may be ordered from: TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements...
