- Page 1 4 3 1 2 F A 4 3 1 2 F A 4 3 1 2 F A 4 3 1 2 F A LCD-Bildschirm / Moniteur / Monitor / Skärm / Beeldscherm / Billedskærm BETRIEBSANLEITUNG BETRIEBSANLEITUNG BETRIEBSANLEITUNG BETRIEBSANLEITUNG OPERATING MANUAL OPERATING MANUAL OPERATING MANUAL OPERATING MANUAL...
-
Page 2: Table Of Contents
Contents Introduction...1 Notational conventions ...2 Important notes ...2 Safety ...2 Cleaning notes...3 Transport notes ...3 Manufacturer’s notes ...4 FCC Class B Compliance Statement ...4 Important note on power cable ...5 Declaration of Conformity ...5 Disposal and recycling...6 Checking the contents of the consignment ...6 Installing an ergonomic video workstation ...7 Height adjustment and ability to turn...8 Connecting the monitor...9... -
Page 4: Introduction
This Operating Manual contains important information you require to start up and run your LCD monitor. A screen controller with VGA interface is required to control the 4312 FA LCD monitor. The monitor processes the data supplied to it by the screen controller. The screen controller/the associated driver software is responsible for setting the modes (resolution and refresh rate). -
Page 5: Notational Conventions
Colour monitor 4312 FA Notational conventions The meanings of the symbols and fonts used in this manual are as follows: Pay particular attention to text marked with this symbol. Failure to observe this warning endangers your life, destroys the device, or may lead to loss of data. -
Page 6: Cleaning Notes
Transport the monitor with care and only in its original packaging or another corresponding packaging fit to protect it against knocks and jolts. Never drop the LCD monitor (danger of glass breakage). S26361-K841-V150-1-5E19 Colour monitor 4312 FA English - 3... -
Page 7: Manufacturer's Notes
20 million tons of carbon dioxide into the atmosphere - the equivalent of 5 million automobiles. As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product meets the Energy Star guidelines for energy efficiency. -
Page 8: Important Note On Power Cable
FCC Rules under the most accurate measurement standards possible, and that all the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commissions requirements. S26361-K841-V150-1-5E19 Colour monitor 4312 FA Color LCD Monitor Fujitsu Siemens Computers 4312 FA... -
Page 9: Disposal And Recycling
Colour monitor 4312 FA Disposal and recycling This device has been manufactured to the highest possible degree from materials which can be recycled or disposed of in a manner that is not environmentally damaging. The device may be taken back after use to be recycled, provided that it is returned in a condition that is the result of normal use. -
Page 10: Installing An Ergonomic Video Workstation
Position the monitor for Keep ventilated areas clear. optimum viewing. The viewing distance to the monitor should be approximately 50 cm. S26361-K841-V150-1-5E19 Colour monitor 4312 FA edge of desk permissible permissible reaching sector reaching sector 600 mm... -
Page 11: Height Adjustment And Ability To Turn
Colour monitor 4312 FA Height adjustment and ability to turn You can conveniently adjust the height of your monitor by first removing the transport lock (1) and then slightly lifting the display (2). In addition, you can also turn the display by 90° into the vertical position (portrait mode). -
Page 12: Connecting The Monitor
Ê Connect the other connector of the data cable to the (active) monitor port on the system unit and secure the plug-in connection by tightening the safety screws (2). S26361-K841-V150-1-5E19 Colour monitor 4312 FA English - 9... -
Page 13: Operation Of The Monitor
Colour monitor 4312 FA If your system unit has two monitor ports ("onboard" screen controller and separate graphics card), the monitor port for the separate graphics card is usually active. Ê Plug the power adapter cable into the power connector (3) of the monitor. Ensure that it snaps firmly in place. -
Page 14: Switching The Monitor On/Off
To completely switch off the power consumption, switch off the system unit or pull the plug of the monitor power cable out of the monitor socket of the system unit. S26361-K841-V150-1-5E19 Colour monitor 4312 FA Suspend mode flashes green (1 s) -
Page 15: Changing The Monitor Settings
Colour monitor 4312 FA Changing the monitor settings When putting the monitor into operation for the first time, the screen display should be optimally adapted to the screen controller used and adjusted in accordance with your needs. Basic monitor settings with the floppy disk supplied... - Page 16 Press the MENU button to activate the OSD menu. The main menu appears on the screen with icons for the setting functions. Brightness S26361-K841-V150-1-5E19 Colour monitor 4312 FA The last icon set is marked (in this case Brightness). At the same time, the corresponding setting window appears.
- Page 17 Colour monitor 4312 FA Depending on the function (in this case Contrast), additional adjustment functions are offered. Bright Colors Dark Colors All modifications are automatically stored if no button is pressed in an active setting window for approx. 3 seconds.
- Page 18 With the submenus R (Red), G (Green) and B (Blue) you can increase or decrease the corresponding colour ratios (Red, Green, Blue). Selecting reddish colour setting Reddish Bluish Selecting bluish colour setting S26361-K841-V150-1-5E19 Colour monitor 4312 FA English - 15...
- Page 19 Colour monitor 4312 FA Switching full-screen mode on or off Calling the Image Size setting window (activate with MENU button). If your graphic card is only capable of displaying a resolution lower than 1280 x 1024, the scaling process of the monitor can extend the addressability to 1280 x 1024 pixels by determining intermediate values (with interpolation).
-
Page 20: Notes On Ergonomic Colour Adjustment
Colour combination very suitable Colour combination not suitable because colour locations are too close together, thin characters are not identifiable or rigorous focusing is demanded of the human eye. S26361-K841-V150-1-5E19 Colour monitor 4312 FA . In the digital mode some Characters blue... -
Page 21: Technical Data
Colour monitor 4312 FA Technical data Dimensions and weight (LCD monitor) Visible diagonals: Dot pitch: Screen size: Maximal resolution: Dimensions (W x H x D): Weight: Accessories: Storable display modes: Power adapter Input data Rated mains voltage: Frequency: Output data... -
Page 22: Vesa-Ddc-Compatible Vga Interface
If the monitor 4312 FA is not yet displayed in the list of monitors, you can select the following monitor instead:... -
Page 23: Pin Assignment D-Sub
Colour monitor 4312 FA Pin assignment D-SUB Meaning Video input red Video input green Video input blue Ground DDC ground Red video ground Green video ground Blue video ground Trouble shooting Should an error occur, first check the following points. If the distortion is still not eliminated, the monitor should, if possible, be checked on another PC and/or with another data cable. - Page 24 According to ISO 13406-2 (Class II), a maximum of 6 pixels and 7 subpixels may be defective, i. e. a total of 25 faulted dots. This corresponds to approx. 0,00062 % of the entire screen surface! The flat screen monitors from Fujitsu Siemens Computers are typically considerably better than requirements defined in this standard.
-
Page 25: Why Do We Have Environmentally Labelled Computers
TCO'99 Congratulations You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. -
Page 26: Environmental Requirements
TCO'99 Below you will find a brief summary of the environmental requirements met by this product. The complete environmental criteria document may be ordered from: TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements...
