- Page 1 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 115333110 (001) OWNER’S MANUAL BRUSHCUTTERS BCZ4505DW BCZ4505CL BCZ5010DL BCZ5010DW BCZ5010CL Original Language GB-1...
- Page 2 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL EC DECLARATION OF CONFORMITY (Applies to Europe only) The undersigned manufacturer, Husqvarna Zenoah Co.,Ltd., 1-9, Minamidai, Kawagoe, Saitama, Japan, declares under sole responsibility that the following products referred to in this declaration conform with the requirement of the following COUNCIL’S DIRECTIVE.
- Page 3 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL EXPLANATION OF SYMBOLS AND SAFETY WARNINGS WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. MODEL SOUND LEVEL VIBRATION LEVEL ISO 22868 ISO 22867 (guaranteed) hv,eq pAeq BCZ4505DW Blade 45.2 cm...
-
Page 4: Table Of Contents
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL SAFETY FIRST Contents Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken 1. Parts location ..........4 into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions 2. -
Page 5: Specifications
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 2. Specification Model BCZ4505DW BCZ5010DL/DW BCZ4505/5010CL Overall size (LxWxH) DL: 1915x420x260 DW: 1915x655x450 1915x655x530 Dry weight Engine Model Zenoah GZ45N Zenoah GZ50N Zenoah GZ45N/GZ50N Displacement 45.2 50.6 45.2/50.6 Fuel Mixture (Gasoline 50 : Oil 1)(when using ZENOAH genuine oil) -
Page 6: For Safe Operation
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 5. For safe operation b. At night, at times of heavy fog, 1. Read this manual carefully until or at any other times when you completely understand and your field of vision might be... - Page 7 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 5. For safe operation BEFORE STARTING stacle when the engine starts. THE ENGINE 1. The area within a perimeter of WARNING 15 m (50 ft) of the person using the product should be considered a haz-...
- Page 8 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 5. For safe operation • IF SOMEONE COMES HANDLING FUEL 1. Guard against hazardous situa- 1. The engine of the ZENOAH prod- tions at all times. Warn adults to uct is designed to run on a mixed...
-
Page 9: Set Up
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 6. Set up A Package contains the items as illustrated. BCZ4505DW BCZ5010DW BCZ5010DL BCZ4505CL BCZ5010CL BCZ4505DW BCZ4505CL BCZ5010DW BCZ5010CL BCZ5010DL BCZ5010DL BCZ4505CL BCZ4505DW BCZ5010CL BCZ5010DW BCZ5010DL (1) Unit (9) Trimmer head... -
Page 10: Angle Transmission
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 6. Set up INSTALLING HANDLE (BCZ5010DL) INSTALLING BLADE • Set the handle and the barrier on the bracket. Attach 1. Put the angled bar(1) into the side holes of the inner them with the 4bolts provided securely. -
Page 11: Fuel
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 7. Fuel ■ FUEL 4. Pour in the rest of gasoline and agitate again for at least one minute. As some oils may be difficult to agitate depending on oil ingredients, sufficient agi- •... -
Page 12: Operation
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 8. Operation STARTING ENGINE WARNING WARNING • The product is equipped with a centrifugal clutch mechanism, so the cutting attachment begins to • The cutting head will start rotating upon the en- rotate as soon as the engine is started by putting gine starts. - Page 13 848-JL0-6914 • Be sure to use genuine parts made of Zenoah for blades.In particular, never use special blades such as shredder blades.If you use a special blade, the 848-JTA-6910 (BCZ4505CL / BCZ5010CL) unit may fail.
- Page 14 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 8. Operation CUTTING METHOD d. Keep the blade sharp. A dull blade increase the (a)Use the front left side cutting. chance of bounce. (b) Guide the blade from your right to left with it tilted e.
- Page 15 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 8. Operation 6. Take precautions to avoid wire, grass and dead, dry, long-stem weeds from wrapping around the head shaft. Such materials can stall the head and cause the clutch to slip, resulting in damage to the clutch system if repeated frequently.
-
Page 16: Maintenance
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 9. Maintenance REFILLING TRIMMING LINE Spool Latch (BCZ4505CL / BCZ5010CL) WARNING • For safety reasons, do not use metalreinforced line. Press Cover 1. Press the latches oppositely on the housing side wall. - Page 17 BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 9. Maintenance 9. Maintenance REFILLING TRIMMING LINE BLADE (BCZ5010DL / BCZ4505DW / BCZ5010DW) • Check the blade and the fasteners for looseness, cracking, or bending. 1. For replacement line, use a diameter of 2.4mm(.095in).
-
Page 18: Storage
BCZ4505DW / BCZ4505CL / BCZ5010DL / BCZ5010DW / BCZ5010CL 9. Maintenance INTAKE AIR COOLING VENT WARNING • Check the intake air cooling vent after every 25 0.6~0.7 mm hours of use for blockage, and remove any waste • REPLACEMENT PLUG IS A NGK CMR7H. -
Page 19: Troubleshooting Guide
→ clogged with dust → consult with the repair specialty store When your unit seems to need further service, please consult with our ZENOAH service shop in your area. 12. Disposal • When you dispose of the machine, do not disas- semble the machine.
