Summary of Contents for Zenoah BCZ4000DW
- Page 1 BCZ4000DL / BCZ4000DW / BCZ4200CL 115 34 08-10 (001) OWNER’S MANUAL BRUSHCUTTERS BCZ4000DL BCZ4000DW BCZ4200CL Original Language GB-1...
- Page 2 BCZ4000DL / BCZ4000DW / BCZ4200CL EC DECLARATION OF CONFORMITY (Applies to Europe only) The undersigned manufacturer, Husqvarna Zenoah Co.,Ltd., 1-9, Minamidai, Kawagoe, Saitama, Japan, declares under sole responsibility that the following products referred to in this declaration conform with the requirement of the following COUNCIL’S DIRECTIVE.
- Page 3 BCZ4000DL / BCZ4000DW / BCZ4200CL EXPLANATION OF SYMBOLS AND SAFETY WARNINGS WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. MODEL SOUND LEVEL VIBRATION LEVEL ISO 22868 ISO 22867 (guaranteed) pAeq hv,eq BCZ4000DL Blade 40.1 cm 102 dB(A) 118 dB(A) 7.6 m/s...
-
Page 4: Table Of Contents
BCZ4000DL / BCZ4000DW / BCZ4200CL SAFETY FIRST Contents Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken 1. Parts location ..........4 into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions 2. -
Page 5: Specifications
1900 x 660 x 520 Dry weight Engine Model Zenoah GZ40N Displacement 40.1 Fuel Mixture (Gasoline 50 : Oil 1)(when using ZENOAH genuine oil) Carburetor Diaphragm type Ignition system Flywheel magneto (C.D.I.) Spark plug NGK CMR7H-10 Fuel tank capacity 0.75... -
Page 6: For Safe Operation
BCZ4000DL / BCZ4000DW / BCZ4200CL 5. For safe operation b. At night, at times of heavy fog, 1. Read this manual carefully until or at any other times when you completely understand and your field of vision might be follow all safety and operating limited and it would be diffi- instructions. - Page 7 BCZ4000DL / BCZ4000DW / BCZ4200CL 5. For safe operation BEFORE STARTING product onto the ground in a flat THE ENGINE clear area and hold it firmly in 1. The area within a perimeter of place so as to ensure that neither...
- Page 8 HANDLING FUEL 1. The engine of the ZENOAH prod- • IF SOMEONE COMES uct is designed to run on a mixed 1. Guard against hazardous situa- fuel, which contains highly flam- tions at all times.
-
Page 9: Set Up
BCZ4000DL / BCZ4000DW / BCZ4200CL 6. Set up A Package contains the items as illustrated. BCZ4000DL BCZ4000DW BCZ4200CL BCZ4200CL BCZ4000DW BCZ4000DL BCZ4000DL BCZ4000DW BCZ4200CL BCZ4000DL (1) Unit (9) Blade (2) Harness (10) Cover (3) Harness (11) Blade cover (4) Harness... -
Page 10: Loop Handle
BCZ4000DL / BCZ4000DW / BCZ4200CL 6. Set up INSTALLING HANDLE (BCZ4000DL) INSTALLING BLADE 1. Put the angled bar(1) into the side holes of the inner holder and the angle transmission. • Tighten the grip firmly. If the grip becomes loose, it 2. -
Page 11: Fuel
2. Put fuel into the fuel tank to 80% of the full capacity. 3. Fasten the fuel cap securely and wipe up any fuel • The Zenoah engines are lubricated by oil specially spillage around the unit. formulated for air-cooled 2-cycle gasoline engine use. -
Page 12: Operation
BCZ4000DL / BCZ4000DW / BCZ4200CL 8. Operation STARTING ENGINE WARNING WARNING • The product is equipped with a centrifugal clutch mechanism, so the cutting attachment begins to • The cutting head will start rotating upon the en- rotate as soon as the engine is started by putting gine starts. - Page 13 • BCZ4000DL, BCZ4000DW, BCZ4200CL : Be sure to use genuine parts made of Zenoah for blades. In par- ticular, never use special blades such as shredder BCZ4200CL 848-JL0-6914 blades.
- Page 14 BCZ4000DL / BCZ4000DW / BCZ4200CL 8. Operation CUTTING METHOD d. Keep the blade sharp. A dull blade increase the (a)Use the front left side cutting. chance of bounce. (b) Guide the blade from your right to left with it tilted e.
-
Page 15: Maintenance
• If vibration or shaking persists even after repairing, or (Be sure to install the genuine Zenoah cutting attach- if you cannot identify the cause of abnormality, con- ment guard when using the nylon line head.) tact your local authorized Zenoah dealer for repair. - Page 16 BCZ4000DL / BCZ4000DW / BCZ4200CL 9. Maintenance 9. Maintenance REFILLING TRIMMING LINE BLADE 1. For replacement line, use a diameter of 2.4mm(.095in). • Check the blade and the fasteners for looseness, The spool is capable for a line upto 6m(20ft) on the cracking, or bending.
-
Page 17: Storage
BCZ4000DL / BCZ4000DW / BCZ4200CL 9. Maintenance INTAKE AIR COOLING VENT WARNING 0.9~1.0 mm • Check the intake air cooling vent after every 25 hours of use for blockage, and remove any waste • REPLACEMENT PLUG IS A NGK CMR7H-10. -
Page 18: Troubleshooting Guide
→ clogged with dust → consult with the repair specialty store When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
