DMX MEGA STROBE™ III
DMX Mega Strobe™ III User Manual
User Manual
th
3000 N 29
Ct, Hollywood, FL 33020 U.S.A.
(800) 762-1084 – (954) 929-1115
FAX (954) 929-5560
www.chauvetlighting.com
1
Snapshot
Use on Dimmer
Outdoor Use
Sound Activated
DMX512
Master / Slave
115 V / 230 V Switch
Resettable Breaker
User Serviceable
Duty Cycle
6/11/2009 1:02 PM
Advertisement
Table of Contents
Related Manuals for Chauvet DMX MEGA STROBE III
Summary of Contents for Chauvet DMX MEGA STROBE III
-
Page 1: User Manual
Snapshot DMX MEGA STROBE™ III Use on Dimmer Outdoor Use Sound Activated DMX512 Master / Slave 115 V / 230 V Switch Resettable Breaker User Serviceable Duty Cycle User Manual 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com DMX Mega Strobe™... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. BEFORE YOU BEGIN................................3 ..................................3 HAT IS INCLUDED ................................3 NPACKING NSTRUCTIONS AC P ....................................3 OWER ....................................3 ONTACT ................................. 4 AFETY NSTRUCTIONS 2. INTRODUCTION ..................................5 ....................................5 EATURES Additional Features ................................5 DMX C ................................ -
Page 3: Before You Begin
All fixtures must be connected to circuits with a suitable Earth Ground. Contact Us Wor l d Wi de General Information CHAUVET 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560... -
Page 4: Safety Instructions
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. DMX MEGA STROBE™ III User Manual... -
Page 5: Introduction
2. I NTRODUCTION Features 2-channel DMX-512 strobe light Variable electronic dimmer (0-100%) Variable electronic flash rate (0-20fps) Blinder / lightning effect Additional Features Includes gel frame and 4-pack of gels (RGBY) Built-in sound activated programs Built-in resettable circuit breaker (no fuses) DMX Channel Summary HANNEL UNCTION... -
Page 6: Product Overview
Product Overview DMX Out Resettable Breaker DIP switches Power indicator DMX signal indicator Hanging bracket Bracket adjustment knob Gel Frame DMX MEGA STROBE™ III User Manual 6/11/2009 1:02 PM... -
Page 7: Setup
3. S ETUP Lamp Installation When replacing the lamp, please wait 15 minutes after powering down to allow the unit to cool down! Always disconnect from main power prior to lamp replacement. Note: The DMX Mega Strobe™ III ships with a lamp preinstalled. Remove the 4 corner screws to allow the Unscrew and release... -
Page 8: Fixture Linking
Maximum recommended number of fixtures on a serial data link: 32 Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 9: 3-Pin To 5-Pin Conversion Chart
3-Pin to 5-Pin Conversion Chart Note! If you use a controller with a 5-pin DMX output connector, you will need to use a 5-pin to 3-pin adapter. CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion: IN TO... -
Page 10: Operating Instructions
4. O PERATING NSTRUCTIONS Operation Stand-Alone Mode (Sound-Active): This mode allows a single unit to run to the beat of the music. See the settings below for details on this operation. Set all DIP switches to the Off position. Stand-Alone Mode (Manual): Set Dip switch #10 to the Off position. -
Page 11: Setting The Dmx Starting Address
Setting the DMX Starting Address This DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start address" from 1 to 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. -
Page 12: Dmx Quick Reference Chart
DMX Quick Reference Chart DMX Address Quick Reference Chart Dip Switch Position DMX DIP #9 0 0 0 SWITCH SET 0=OFF #8 0 0 0 1=ON #7 0 0 1 X=OFF or ON #6 0 1 0 #1 #2 #3 #4 #5 0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480 1 0 0 0 0... -
Page 13: General Troubleshooting
Relay will not work Check reset switch Check cable connections If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support. Technical Support Address: Service Dept. 3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.) Support (Email): tech@chauvetlighting.com... -
Page 14: Appendix
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) DMX Mega Strobe™... -
Page 15: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 16: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length ..........................13 in (330 mm) Width ..........................5.8 in (147 mm) Height ..........................8.3 in (211 mm) Weight ..........................9.2 lbs (4.2 kg) POWER Input voltage ..................120 VAC, 60 Hz or 230 VAC, 50 Hz Breaker............................
