Chauvet DMX-800 Constellation Supplementary Manual

DMX Mode

This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page 16.
1) Press <MODE/ESC> until
2) Use the <UP> and <DOWN> buttons to select the desired address.

DMX Channel Values (19-channel mode)

C
HANNEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Constellation User Manual
V F (19-
ALUE UNCTION CHANNEL MODE
000 255 Pan 1: 128 = halfway point
000 255 Tilt 1: 128 = halfway point
000 255 Pan 2: 128 = halfway point
000 255 Tilt 2: 128 = halfway point
000 255 Pan 3: 128 = halfway point
000 255 Tilt 3: 128 = halfway point
000 255 Pan 4: 128 = halfway point
000 255 Tilt 4: 128 = halfway point
000 255 Pan 5: 128 = halfway point
000 255 Tilt 5: 128 = halfway point
000 255 Pan 6: 128 = halfway point
000 255 Tilt 6: 128 = halfway point
000 255 Vector Speed: (Normal > Slow)
Dimmer/Shutter
000 099 Dimmer (0 – 100%)
100 133 Open
134 243 Strobe (Fast > Slow)
244 249 No Function
250 255 Open
000 255 Gobo 1 & 4
000 255 Gobo 2 & 5
000 255 Gobo 3 & 6
Gobo Rotate
000 016 No Function
017 135 Counter-clockwise (Slow > Fast)
136 No Rotate
137 255 Clockwise Rotate (Slow > Fast)
Mode
000 No Function
001 007 Auto 1
008 015 Auto 2
016 023 Auto 3
024 031 Auto 4
032 039 Auto 5
040 047 Auto 6
048 055 Auto 7
056 063 Auto 8
064 071 Auto 9
072 079 Auto 10
080 087 Auto 11
088 095 Auto 12
096 103 Auto 13
104 111 Auto 14
112 119 Auto 15
120 127 Auto 16
128 160 Sound 1
161 193 Lamp On (after 5 seconds)
194 226 Lamp off (after 5 seconds)
227 254 Reset (after 5 seconds)
255 No Function
13
is displayed.
)
