Summary of Contents for Chauvet Colordash Block
-
Page 1: User Manual
Snapshot Use on Dimmer Outdoor Sound Activated Master/Slave Autoswitching Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ............................3 ..................................... 3 HAT IS INCLUDED ..................................3 NPACKING NSTRUCTIONS ....................................3 ANUAL ONVENTIONS ........................................3 CONS ....................................4 AFETY NSTRUCTIONS LED E ..................................4 XPECTED IFESPAN 2. Introduction ............................... 5 ......................................... 5 EATURES Additional Features .............................. -
Page 3: Before You Begin
1. B EFORE EGIN What is included 1 x COLORdash™ Block 1 x Power cable with plug 1 x 6.6 ft (2 m) power linking cable 1 x Safety eyebolt 1 x Warranty Card 1 x User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that... -
Page 4: Safety Instructions
Do not open the housing or attempt any repairs unless you are one of them. In the unlikely event that your unit may require service, please contact CHAUVET at (954) 929-1115. -
Page 5: Introduction
2. I NTRODUCTION Features 3, 4, 5, 9, 11 or 12-channel DMX LED wash light (with ID addressing) Operating modes 3-channel: RGB control 4-channel: RGB, dimmer 4-channel: RGB+W control 5-channel: RGB+W, dimmer 11-channel: RGB+W, ID, dim, strobe, macro, fan control, automatic, custom 12-channel: RGB for individual block control Blackout/static/dimmer/strobe/pulse RGB+W color mixing with or without DMX controller... -
Page 6: Dmx Channel Summary
DMX Channel Summary The COLORdash™ Block has six DMX channel configurations. These are referred to as “Personalities” in this manual and in the fixture onboard control panel. The six personalities are: STAGE 1, BLOCK, ARC 1, ARC 1 + D, ARC 2, ARC 2 + D. Each of the different personalities can be accessed from the control panel. -
Page 7: Product Overview
Product Overview Control Panel Length Height Power Link Out Power Out Width Power In DMX Out Bracket Adjustment DMX In Knob COLORdash™ Block User Manual 6/19/2009 4:54 PM... -
Page 8: Setup
3. SETUP AC Power This fixture has an auto-switching power supply that can accommodate a wide range of input voltages (100 ~ 240 VAC, 50/60 Hz). Before powering on the unit, make sure the line voltage to which you are connecting it is within the range of accepted voltages. -
Page 9: Mounting
You can order “C” and “O” clamps from any CHAUVET dealer or distributor (CLP-15, CLP-06 recommended). If you are using this fixture for down lighting, you must use at least one safety cable/chain for each fixture in addition to the double-bracket yoke. -
Page 10: Fixture Linking
300 ~ 455 m (985 ~ 1,500 ft). Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable, please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 11: 3-Pin To 5-Pin Conversion Chart
3-Pin to 5-Pin Conversion Chart If you use a controller with a 5-pin DMX output connector, you will need to use a 5-pin to 3-pin adapter. CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion:... -
Page 12: Operating Instructions
4. O PERATING NSTRUCTIONS Control Options The COLORdash™ Block is addressable in the DMX range of 001 to 512. In its simplest control form, this allows for the control of up to 46 fixtures in the 11-channel Stage 1 personality; however, a secondary ID address system exists for use in a limited DMX universe and architectural environments. -
Page 13: Setting The Starting Dmx Address
Setting the Starting DMX address Each fixture requires a starting address from 1 through 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the starting address. For example, a fixture that occupies or uses seven channels of DMX and is addressed to start on DMX channel 100, will read data from channels: 100, 101, 102, 103, 104, 105 and 106. -
Page 14: Menu Map
Menu Map UNCTION UNCTION ELECTION NSTRUCTION 000 ~ 255* Green User can combine Red, Green, Blue and (0 ~ 100%) 1. STATIC White to generate a custom color Blue (Static Color) Select strobing frequency between 0 *Strobe range is White and 20 Hz 0~20 Hz Strobe... - Page 15 COLORdash™ Block User Manual 6/19/2009 4:54 PM...
-
Page 16: Dmx Channel Values
DMX Channel Values The COLORdash™ Block has six DMX channel configurations: STAGE 1, BLOCK, ARC 1, ARC 1 + D, ARC 2, and ARC 2 + D. STAGE 1 HANNEL ALUE UNCTION Dimmer 000 255 0 100% (or STEP TIME when CUS.01-10 in CH.8 is activated) 000 ... - Page 17 STAGE 1 (Cont.) ID A HANNEL DDRESSING ALUE ALUE ALUE 000 009 All IDs ID 23 ID 46 010 019 ID 1 ID 24 ID 47 020 029 ID 2 ID 25 ID 48 030 039 ID 3 ID 26 ID 49...
-
Page 18: Block
BLOCK HANNEL ALUE UNCTION HANNEL ALUE UNCTION Block 1 Red Block 3 Red 000 255 0 100% 000 255 0 100% Block 1 Green Block 3 Green 000 255 0 100% 000 255 0 ... -
Page 19: Important Notes About Stage 1 Dmx Operation
When activating the Auto/Custom programs, it is then possible to control the Step time and Fade time by using Channels 2 & 3, respectively. Contact Us W o r l d W i d e General Information Chauvet Lighting 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115... -
Page 20: Appendix
Connect fixtures using shielded two conductor twisted pair cable with three pin XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) COLORdash™... -
Page 21: General Maintenance
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 22: Photometric Data
Photometric Data COLORdash™ Block User Manual 6/19/2009 4:54 PM... -
Page 23: Colordash™ Block Service Maintenance Guide
Interference from AC wires Keep DMX cables separated from power cables or black lights. If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support. (See “Contact Us”) COLORdash™ Block User Manual 6/19/2009 4:54 PM... -
Page 24: Exploded View
Exploded View Description Part # Front black plastic Cover P111-CDBBFC LED lens (1 of 4) P200-CDBLENS Electronic Transformer 100-240 V, 50/60 Hz P140-CDBELTR Display/Master PCB P170-CDBDSY Bracket/Floor stand P110-CDBRKT Bracket Knob P111-M1KNOB P111-M1PWR(POWER) Power/signal input/output P111-M1SIG(SIGNAL) LED Driver PCB P172-DCBDRV Cooling fan 12 V, 0.16 A P130-CDBFAN Main Case Cover (X2) -
Page 25: Wiring Diagram
Wiring Diagram COLORdash™ Block User Manual 6/19/2009 4:54 PM... -
Page 26: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length ........................... 9.8 in (250 mm) Width ............................. 7.7 in (195 mm) Height ............................6 in (150 mm) Weight ..........................4.6 lbs (2.08 kg) POWER Autoswitching internal power supply ............... 100 ~ 240 VAC, 50/60 Hz Power Consumption @ 120 V, 60 Hz ................
