Page 1: User Manual
Snapshot COLORado™ Panel OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave Autoswitching Transformer Replaceable Fuse User Serviceable Duty Cycle USER MANUAL Chauvet, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ..........................3 What is included ............................3 Unpacking Instructions ..........................3 Safety Instructions ............................ 4 LED Expected Lifespan ..........................4 2. Introduction ............................5 Features ..............................5 DMX Channel Summary ..........................6 Product Overview............................8 3. -
Page 3: Before You Begin
6. Appendix ............................29 DMX Primer ............................29 General Maintenance ..........................30 Returns Procedure ..........................30 Claims ..............................30 Photometrics............................31 COLORado™ Panel Service Maintenance Guide ..................32 Blow-out Diagram........................... 33 Technical Specifications .......................... 35 1. B EFORE EGIN What is included ... -
Page 4: Safety Instructions
There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Caution! After prolonged periods of operation, the fixture chassis may reach high temperatures. -
Page 5: Introduction
2. I NTRODUCTION Features 3, 4, 5 or 9-channel DMX-512 LED bank system (with ID addressing) Operating modes 3-channel: RGB control 3-channel: HSV control (hue, saturation and value) 4-channel: RGBW control 4-channel: RGB, dimmer 5-channel: RGBW, dimmer 9-channel: RGBW, ID, dimmer, strobe, macro, auto, custom, balance, Hyper Color™ RGBW color mixing with or without DMX controller Color temperature presets (3,200ºK - 10,000ºK) or create your own Built-in automated programs via DMX... -
Page 6: Dmx Channel Summary
DMX Channel Summary The COLORado™ Panel has a total of 6 DMX channel configurations, referred to as “Personalities” in this manual and in the fixture onboard control board. The 6 personalities are [HSV, STAGE 1, ARC1, ARC1+D, ARC 2, ARC2+D]. Each of the different personalities can be accessed from the control panel. - Page 7 [ARC1+D] HANNEL ESCRIPTION Dimmer Green Blue [ARC2+D] HANNEL ESCRIPTION Dimmer Green Blue White [HSV] HANNEL ESCRIPTION Saturation Value (Intensity) COLORado™ Panel User Manual 8/19/2008 1:08 PM...
-
Page 8: Product Overview
Product Overview Power Link Out Bracket Adjustment Power Out DMX In-pin Power In DMX Out Control Panel Hanging Bracket/ Floor Stand COLORado™ Panel User Manual 8/19/2008 1:08 PM... -
Page 9: Setup
3. SETUP AC Power This fixture has an auto-switching switch-mode power supply that can accommodate a wide range of input voltages. The only thing necessary to do before powering on the unit is to make sure the line voltage you are applying is within the range of accepted voltages. This fixture will accommodate between 100V and 240V AC 50-60 Hz. -
Page 10: Mounting
It is recommended to use at least 2 mounting points per fixture. You can order “C” and “O”-clamps from any CHAUVET dealer or distributor (CLP-15, CLP-06 recommended). -
Page 11: Lens Assembly Installation/Replacement
Lens Assembly Installation/Replacement The COLORado™Panel comes with 15 lens assembly pre-installed from the factory. However, there are 2 other optional lens kits (CL18X10, CL18X30) available as accessories, which will alter the beam angle. Please follow the below instructions for proper replacement/installation. 2. -
Page 12: Fixture Linking
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 13: 3-Pin To 5-Pin Conversion Chart
Note! If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion: IN TO... -
Page 14: Control Options
4. O PERATING NSTRUCTIONS Control Options The COLORado™ Panel is addressable in the DMX range of 001 to 512. In its simplest control form, this allows for the control of up to 56 fixtures in the 9-channel Stage1 personality; however, a secondary “ID”... -
Page 15: Dmx-512 Addressing With Id Address
DMX-512 addressing with ID address Follow instructions 1 ~ 4 for DMX512 addressing. Activate ID addressing in each fixture by setting panel function {ID ON/OFF} to ON. {MENU} {Settings) {ID ON/OFF} [ON] For every DMX512 starting address the user can set 66 separate ID addresses. Set ID addresses in each fixture by setting panel function {ID address} to incremental values. -
Page 16: Colorcon™ Setup
COLORcon™ Setup FIXTURE CONTROL PANEL SETUP Activate ID addressing in each fixture by setting panel function {ID ON/OFF} to ON. {MENU} {Settings) {ID ON/OFF} [ON] Set ID addresses in each fixture by setting panel function {ID address} to incremental values. -
Page 17: Setting The Dmx Address
Setting the DMX address Each fixture requires a "start address" from 1 to 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. For example, a fixture that occupies or uses 7 channels of DMX and was addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104, 105 and 106. -
Page 18: Menu Map
Sets the operating mode for the fixture: to receive signal from a DMX controller 4. Run Mode DMX~Slave (DMX) or to receive signal from the DMX out of another COLORado Panel (Slave) 3-channel: hue, saturation, value Stage 1 9-channel RGBW+D Arc 1 3-channel RGB 5. -
Page 19: Dmx512 Channel Values
DMX512 Channel Values The COLORado™ Panel has 6 DMX512 channel configurations [HSV, STAGE1, ARC1, ARC1+D, ARC2, and ARC2+D]. STAGE 1 HANNEL ALUE UNCTION Dimmer 000 255 0 100% (or STEP TIME when CUS.01-10 is activated) 000 255 0 ... - Page 20 Auto + Custom Programs 000 009 No Function 010 019 Auto 1 020 029 Auto 2 030 039 Auto 3 040 049 Auto 4 050 059 Auto 5 060 069 Auto 6 070 079 Auto 7 080 ...
- Page 21 HANNEL ALUE UNCTION 000 255 0 100% Saturation 000 255 0 100% Value 000 255 0 100% Note: In HSV mode, Hue stands for the visible light, such as red, yellow, and cyan, etc. Saturation refers to the dominance of hue in the color; when saturation is at 100%, then the color is at its purest.
- Page 22 ARC 1 HANNEL ALUE UNCTION 000 255 0 100% Green 000 255 0 100% Blue 000 255 0 100% ARC 1 + D HANNEL ALUE UNCTION Dimmer 000 255 0 100% 000 255 0 ...
-
Page 23: Important Notes About Stage 1 Dmx Operation
Important Notes about STAGE 1 DMX Operation MASTER DIMMER Channels 1 controls the intensity of the currently projected color When the slider is at the highest position (255), then the intensity of the output is at the maximum. RED, GREEN BLUE AND WHITE COLOR SELECTION Channels 2, 3 4 and 5 control the intensity ratio of each of the Red, Green, Blue,&... -
Page 24: Colorado™ Controller
5. COLOR ™ C ONTROLLER Overview LCD Display Panel SOLD MODE SETUP DOWN SEPARATELY MODE Accesses main menu or backs out of sub-menu SETUP Selects the currently displayed menu or confirms the current function value Use to navigate upwards through menu items or increment function values DOWN Use to navigate downwards through menu... -
Page 25: Menu Map
Menu Map ELECTION ELECTION ELECTION ELECTION UNCTION Step time Wash [1] [001] [255] Wash Edit program Fade time Wash [8] [001] [255] Effect [1] Effect Speed Edit [001] [100] program Effect [8] ID address [000*] [100] (*0 = all units) Step time [000] ... -
Page 26: Custom Program
Custom Program Select from the eight existing [Custom] programs and it will instantly play. Enter the [Edit] section to create or edit program. You can create or edit up to 100 scenes. To program less than 100 scenes, set the [Step time] of the scene after your last scene to 0. -
Page 27: Activating Password Mode
[Reset to factory settings] This function will reset all the settings to the factory defaults except for [Custom] programs. Factory Default Settings Setting Default [Schedule] All times in schedule are reset to [00:00] [Wash program] Step times and fade times are reset to [001] [Effect program] Speeds are reset to [001] [DMX address]... -
Page 28: Technical Support
Support (Email): tech@chauvetlighting.com Telephone: (954) 929-1115 - (Press 4) Fax: (954) 929-5560 - (Attention: Service) Website: http://www.chauvetlighting.com Contact Us Wor l d Wi de General Information Chauvet Lighting 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084) World Wide Web www.chauvetlighting.com... -
Page 29: Appendix
Connect fixtures using shielded two conductor twisted pair cable with three pin XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) COLORado™... -
Page 30: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RMA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 31: Photometrics
Photometrics COLORado™ Panel User Manual 8/19/2008 1:08 PM... -
Page 32: Colorado™ Panel Service Maintenance Guide
This can occur if the fixture in not in “High ˆT” an ideal location for the convection cooling to be effective If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on page 28. COLORado™ Panel User Manual... -
Page 33: Blow-Out Diagram
Blow-out Diagram. Description Part Number 1 LED Plastic, Clear cover P111-CPGLSS 2 LED Lens-complete set CL18X10/15/30 3 LED Metal-Core PCB - complete P222-CPNLLED 4 LED Driver PCB P172-LEDPDVR 5 Electronic Transformer P140-CPELTR 6 Bracket Knob P111-C3HEXBLT Display/Master PCB P170-CPDSPL 8 Display/Master IC chip P177-CPMICH (not shown) 9 Bracket Assembly P111-CPBRKT... - Page 34 COLORado™ Panel User Manual 8/19/2008 1:08 PM...
-
Page 35: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length ........................... 7.5 in (191 mm) Width ............................15 in (381 mm) Height............................ 7.5 in (191 mm) Weight ............................. 18 lbs (8.2 kg) POWER AC Power Auto-switching ..................100V~240V 50/60Hz AC Power Consumption ................... 106W (0.89A) max at 120V 60Hz Power Consumption ...................
