Virtual Wall
(optional accessory for models 570 and above)
Virtual Wall Lighthouses turn on and off automatically as Roomba is
turned on and off. When they are on, a light illuminates on the top of the
Virtual Wall Lighthouse. A Virtual Wall Lighthouse can be used in two
modes, either in Lighthouse mode or Virtual Wall mode, set by the Mode
Selector.
Power Light
Mode Selector
Range Selector

Lighthouse Mode

In Lighthouse mode, the Virtual Wall Lighthouse helps Roomba navigate
around your home and allows Roomba to clean room-to-room. Roomba
will clean the room it starts in, navigate to the next room, and then clean
the second room. When Roomba has completed cleaning, it will use the
Lighthouse to navigate back to the Home Base for recharging.
Home
Base
Start
Roomba
here
TIP: When in Lighthouse mode, do not manually move Roomba from room to
room while it is cleaning.
14 iRobot Roomba 500 Series
00054.0310.v2.Roomba500.Manual.EN.indd 14
®
Lighthouses
Room 1
With two Virtual Wall
Lighthouses in lighthouse
mode, Roomba will clean
Room 1 for approximately
25 minutes, then clean
Rooms 2 and 3 for 25
minutes each, and then
return to the Home Base.
™
Two "C" Alkaline
Batteries
(not included)
Lighthouse
Room 2
Room 3
Lighthouse
