Network Installation

WARNING!! Before proceeding, a Custom Professional is required
to install and configure your MRX-4SEN.
Connect the 3.5mm sensor plug to the rear of the MRX-4SEN. When
a change in the sensor's state is detected, the MRX-4SEN sends a
signal to the MRX Advanced Network System Controller and triggers
a series of commands.
The example below showcases a voltage sensor connected to the
home's doorbell and the MRX-4SEN. Whenever the door bell is
pressed, a signal is sent over URC's RF 2.4GHz to the MRX
Advanced Network System Controller. The MRX unit, previously
programmed by the Custom Professional, will trigger a series of
commands or an event to gain your attention. A programmed
event, such as Watch Movie/TV, may pause the movie, mute the
audio and display the front door's video camera.
Page 5
