URC MRX-4SEN Owner's Manual
URC MRX-4SEN Owner's Manual

URC MRX-4SEN Owner's Manual

Sensor extender
Hide thumbs Also See for MRX-4SEN:

Advertisement

Quick Links

Order Number
: GETEC-C1-13-116
Test Report Number
: GETEC-E3-13-030
APPENDIX H
: USER'S MANUAL
EUT Type: Sensor Extender
FCC ID.: OZ5URCMRX4SEN
FCC Part 15 subpart C
1 / 1
Page

Advertisement

loading
Need help?

Need help?

Do you have a question about the MRX-4SEN and is the answer not in the manual?

Questions and answers

Summary of Contents for URC MRX-4SEN

  • Page 1 Order Number : GETEC-C1-13-116 FCC Part 15 subpart C 1 / 1 Test Report Number : GETEC-E3-13-030 Page APPENDIX H : USER’S MANUAL EUT Type: Sensor Extender FCC ID.: OZ5URCMRX4SEN...
  • Page 2 MRX-4SEN Sensor Extender Owners Manual...
  • Page 3 MRX-4SEN Sensor Extender Owners Manual ©2013 Universal Remote Control, Inc. The information in this manual is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent from Universal Remote Control, Inc.
  • Page 4: Table Of Contents

    ABLE ONTENTS Introduction Features and Benefits Parts Guide Front, Rear, and Bottom Panel Descriptions Network Installation Specifications USA Limited Warranty Statement Federal Communication Commission Interference Statement Declaration of Conformity...
  • Page 5: Features And Benefits

    URC’s 2.4GHz wireless connection. • Compact Size The small size of the MRX-4SEN allows it to easily fit behind equipment or into places where a traditional base station would not. Parts Guide...
  • Page 6: Front, Rear, And Bottom Panel Descriptions

    Status LED: The Status LED color will vary depending upon its connected state: ● Connected: Illuminates green ● Low Signal: Illuminates orange ● Not Connected: Not illuminated Data LED: The Data LED flashes as the MRX-4SEN transmits data to a MRX Advanced Network System Controller. Page 2...
  • Page 7 DC 12V Power: Plug in the included 12V DC 1A power supply. Sensor Inputs: Connect the sensor’s 3.5mm plug to an available port. The following URC sensors, with their respective model numbers, are compatible with the MRX-4SEN: ● Voltage Sensor SEN-VOLT ●...
  • Page 8 Test button: Press to test the signal strength between the MRX Advanced Network System Controller and the MRX-4SEN. While testing, the Status LED will update and display its current connection setting. (Refer to page 2 for Status LED information.) Reset button: Turns the unit OFF then ON again, and reconnects to the URC 2.4GHz RF signal.
  • Page 9: Network Installation

    MRX-4SEN. Connect the 3.5mm sensor plug to the rear of the MRX-4SEN. When a change is sensor is detected, the MRX-4SEN sends a signal to the MRX Advanced Network System Controller and triggers a series of commands.
  • Page 10: Specifications

    ENSOR XTENDER Specifications Sensor : Four sensor supports Video, Current, Contact Closure, Ambient Light, Audio, Voltage Sensing via URC sensors. USB : Mini_USB for future firmware upgrade use. RF Range(radio frequency) : 50 to 100 feet, depending upon the environment RF Frequency : 2.405 ~ 2.480 GHz...
  • Page 11: Usa Limited Warranty Statement

    MRX-4SEN S ENSOR XTENDER USA Limited Warranty Statement Your Universal Remote Control, when delivered to you in new condition, is warranted against defects in materials or workmanship as follows: UNIVERSAL REMOTE CONTROL, INC. warrants this product against defects in material or workmanship for a period of one (1) year and as set forth below.
  • Page 12 MRX-4SEN S ENSOR XTENDER LIMITATION OF REMEDIES UNIVERSAL REMOTE CONTROL SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY OR CONDITION ON THIS PRODUCT. IN NO EVENT SHALL UNIVERSAL REMOTE CONTROL...
  • Page 14: Declaration Of Conformity

    MRX-4SEN S ENSOR XTENDER Declaration of Conformity Company Name OH SUNG ELECTRONICS CO., LTD. Company Address #181 GONG DAN-DONG, GUMI, GYEONG BUK, REPUBLIC OF KOREA Contact Information Phone: +82-54-468-7281, Fax: +82-54-461-8368 Brand Name UNIVERSAL remote control Product Name Sensor Extender...
  • Page 15 NOTE Page 11...
